Thank You
Thank you for choosing the Definitive Technology Mythos XTR-50 Loudspeaker
System. Our engineers spent many years developing this product. In order to ensure
that you experience the finest performance possible, we encourage you to take a
moment to fully read this owner's manual and familiarize yourself with the proper
installation and set-up procedures for your Mythos XTR-50 speakers.
Specifications
Mythos XTR-50
Driver complement:
2 each 3-1⁄2" (90mm) XTDD dome mid/bass drivers pressure-coupled
to 4 each 3-1⁄2" (90mm) dome low-bass radiators, 1 each 1" (25mm)
Pure Aluminum Dome Tweeter
Frequency response:
(overall on wall) 92Hz – 30kHz; (+/- 3dB on wall) 120Hz – 20kHz
Sensitivity:
92dB
Impedance:
8 Ohms nominal
Dimensions:
(mounted on wall without bracket) 27" H x 6" W x 1-1⁄2" D
(686mm x 152mm x 38mm)
Dimensions:
(mounted on wall with bracket) 27" H x 6" W x 1-9⁄16" D
(686mm x 152mm x 40mm)
Dimensions:
(on table stand) 30" H (762mm)
Table-stand base dimensions:
8-11/16" W x 4-3/4" D (222mm x 136mm)
Product Weight:
5.1 lbs. (2.3kg)
Specifications subject to change without notice.
Notes:
MYTHOS
XTR
®
Unpacking Your Mythos XTR-50 Speakers
Please Inspect For Shipping Damage
Each loudspeaker leaves our plant in perfect condition. Any visible or concealed
damage most likely occurred in handling after it left our plant and should be reported
at once to your Definitive dealer or the delivery company that delivered your loud-
speaker. Please unpack your speaker carefully. Save all cartons and packing materials in
case you move or need to ship your speaker. Record the serial number found on the
back of the Mythos XTR-50 on this manual.
VERY IMPORTANT: Accessories
Various parts and accessories that you will need to use your Mythos XTR-50 are in
the carton but are easy to overlook. Open both ends of the shipping carton. Carefully
examine the contents of the shipping carton and packing material to find the plastic
bags with accessories.
OWNER'S MANUAL
-50
®
Mythos XTR-50 Loudspeakers
