Sim Seats iRacing Pro Package
Thank you for purchasing the iRacing Pro package from Sim Seats! Please use the following
guide to get started.
Monitor stand setup:
Step 1: Check package contents to make sure all parts are enclosed:
Single monitor stand:
-
Monitor stand legs (2)
-
Monitor stand cross bar
-
Single monitor mount
-
Mounting hardware
Triple monitor stand:
-
Monitor stand legs (2)
-
Monitor stand cross bar
-
Triple monitor mount assembly
-
Side monitor mounting plates (2)
-
Side monitor mount clamps (2)
-
Mounting hardware
Step 2: Slide the cross bar into the left and right monitor stand legs. The long end of the
stand goes towards the driver to support angled triple monitor setups. Level the cross bar
and tighten the adjusting bolts
Step 3: Mount the single monitor mount or triple monitor mount assembly to the cross bar.
Step 4: Install the center monitor with the enclosed hardware. Assembly is complete for
single monitor mounts.
Step 5: Triple monitor mounts - Make your height adjustments before installing the side
monitors. This will make life slightly easier due to the lesser weight. Install the left and
right monitor mounting plates to your left and right monitors.
Note: The VESA mounts are offset mounted. Spin the mount 180 degrees to provide
approximately ½" of up/down adjustment of the monitor. Typically the mounts should be
installed with the bolt offset down, so that the monitor mounts slightly higher to
accommodate sag from large/heavy monitors.
Owner's Manual
Advertisement
Table of Contents
Related Manuals for Sim Seats iRacing Pro
Summary of Contents for Sim Seats iRacing Pro
- Page 1 Sim Seats iRacing Pro Package Owner’s Manual Thank you for purchasing the iRacing Pro package from Sim Seats! Please use the following guide to get started. Monitor stand setup: Step 1: Check package contents to make sure all parts are enclosed:...
- Page 2 Swing the monitor mount arms into their approximate final locations (this is important to prevent the monitor stand from tipping backwards once the side monitors are installed). Slide the monitor mounting plate with the monitor installed through the swing arm, install the rear clamp, and tighten the rear clamp bolt.
- Page 3 These are included if applicable. It is a good idea now to start working on wire management for the monitors and speakers along the Sim Seats triple monitor mount. After the monitors are powered and plugged in, place the Logitech sub-woofer to the far right corner of the setup area and plug in the front channels and into the computer.
- Page 4 create your triple screen display group. After the display groups are set, you can configure bezel compensation. If you need assistance, there are many how-to’s online. Search for “eyefinity configuration” and you’ll find plenty of web help. We highly recommend downloading anti-virus software for your new PC. There are many options available, both freeware and mainstream pay per month software.
- Page 5 have the same settings as shown below. Volume levels and balance can also be adjusted in the mixer. The rear speakers are closer to your ears, therefore will need to be turned down. We recommend turning up the front, center, and sub channels to maximum level while leaving the rear speakers at ~80%.
- Page 6 resistance that measure brake force rather than distance, will use a lower setting. Use somewhere between 3 and 4 for standard G27 pedals. Lock-to-lock adjustment at speed – For cars that seem to be too touchy at speed making them hard to keep stable, try increasing this setting. For example, I like the Miata turned up to 950 at speed.
