Sim Seats iRacing Pro Package V5 Owner's Manual

Sim Seats iRacing Pro Package
Thank you for purchasing the iRacing Pro package from Sim Seats! Please use the following
guide to get started.

Monitor stand setup:

Step 1: Check package contents to make sure all parts are enclosed:
Single monitor stand:
- Monitor stand legs (2)
- Monitor stand cross bar
- Single monitor mount
- Mounting hardware
Triple monitor stand:
- Monitor stand legs (2)
- Monitor stand cross bar
- Triple monitor mount assembly
- Side monitor mounting plates (2)
- Side monitor mount clamps (2)
- Mounting hardware
Step 2: Slide the cross bar into the left and right monitor stand legs. The long end of the
stand goes towards the driver to support angled triple monitor setups. Level the cross bar
and tighten the adjusting bolts
Step 3: Mount the single monitor mount or triple monitor mount assembly to the cross bar.
Step 4: Install the center monitor with the enclosed hardware. Assembly is complete for
single monitor mounts.
Step 5: Triple monitor mounts - Make your height adjustments before installing the side
monitors. This will make life slightly easier due to the lesser weight. Install the left and
right monitor mounting plates to your left and right monitors.
Note: The VESA mounts are offset mounted. Spin the mount 180 degrees to provide
approximately ½" of up/down adjustment of the monitor. Typically the mounts should be
installed with the bolt offset down, so that the monitor mounts slightly higher to
accommodate sag from large/heavy monitors.
