Euroset 2035 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
euroset 2035

User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2035 and is the answer not in the manual?

Questions and answers

Related Manuals for Euroset 2035

Summary of Contents for Euroset 2035

  • Page 1: User Manual

    2035 User Manual...
  • Page 2 Instruction Keys Answering machine on/off key Quiet key Repertory keys Loud key Recall key OK key Last number redial key Play/Stop key Delete/Mute key Up key Loudspeaker key (handsfree) Down key Display symbols Ready for use Microphone off Recall key pressed No memory content Handsfree...

  • Page 3: Safety Precautions

    Never open up the telephone yourself.  Do not touch the plug contact with pointed or metallic objects.  Do not carry the telephone by the leads.  If you give your 2035 to someone else, make sure you also give them the user guide.

  • Page 4: Setting Up The Telephone For Use

    Setting up the telephone for use Recommended installation of telephone  Do not expose the telephone to direct sunlight or other sources of heat.  Operate at temperatures between +5°C and +40°C.  Maintain a distance of at least one metre between the telephone and radio equipment, e.g.

  • Page 5: Using The Phone

    Using the phone Many of your telephone's functions are accessed using a menu that is organised in several levels. The functions of the main menu and submenus are displayed in lists. Main menu (first menu level) To access a function in the main menu: Use the Down/Up key to scroll to the function and press the OK key.

  • Page 6: Making Calls

    Making calls Dialling a number Lift handset, dial number. Dial a phone number. If you enter an incorrect number, press to delete it and proceed as normal. Press the OK key or After 2 seconds the number is dialled. Lift the handset if you want to hold the conversation via the handset.

  • Page 7: Last Number Redial

    Making calls Last number redial The last 10 numbers dialled (up to 32 digits) are saved automatically. You can retrieve these numbers from the redial list and dial them again: Redialling the last number dialled Lift the handset and press the last number redial key. Then last dialled phone number is dialled immediately.

  • Page 8: Saving Numbers

    Saving numbers Different telephone settings must be completed with the OK key so that they are available permanently. In order to (e.g. after an incorrect entry) cancel without saving, replace the handset instead of pressing at the end. The original setting is then retained. Pressing allows you to save pauses (not for the 1st digit).

  • Page 9: Editing Directory Entries

    Saving numbers Saving from the calls list In the calls list (see page 16), press the Down/Up key until the desired number appears in the diaplay. At the selected entry, press the OK key. In the menu, select Save number and press OK key. Then save the phone number in the directory or as a repertory number, as described above.

  • Page 10: Adjusting The Telephone

    Adjusting the telephone Setting the date and time Phone setup Date/time Enter the date and time in YY/MM/DD HH:MM format, e.g. 09/08/31 14:59. Use the Down/Up key to select the digit position. Press the OK key. Use the Down/Up key to select 12h or 24h display mode. Press the OK key.

  • Page 11: Adjusting The Loudspeaker

    Adjusting the telephone Setting the handset volume The volume on the handset can be set to one of 2 levels and saved (default setting: level 1). Audio setup Handset VOL Press the Down/Up key. Press the OK key. Adjusting when the handset is lifted Press the Loud/Quiet key (only possible with main supply connection).

  • Page 12: Changing The Pin

    Adjusting the telephone Activating/deactivating the waiting melody You can activate and deactivate the waiting melody for the mute (default setting: on). Initiate function. 0: deactivate; 1: activate. Press the OK key. Changing the PIN You need a PIN to lock and unlock the telephone, to protect the answering machine, to save an emergency number and to turn off the baby call funciton.
  • Page 13 Adjusting the telephone Activating/deactivating call duration display The telephone can show the approximate call duration in the display (up to 99 min. 59 sec.). If the call duration display is activated, the time display begins 8 seconds after the last digit is dialled. Initiate function.

  • Page 14: Operation On A Pabx

    Operation on a PABX Entering/deleting an external line prefix If you are using your telephone on a PABX, you may have to save one or more external line prefixes. A dialling pause is set automatically with the external line prefix. You can save up to three (3) external line prefixes. Phone setup PABX code If no external line prefix has been set in a storage location, "-"...

  • Page 15: Changing The Dialling Mode

    Operation on a PABX Delete all external line prefixes Initiate function. Press the OK key. Changing the dialling mode Phone setup Dial mode In the menu, select Tone or Pulse . Press the OK key twice. Changing dialling modes during a call If your telephone is set to pulse dialling and you want to use functions that require tone dialling (e.g.

  • Page 16: Recall Key (In Public Telephone Systems )

    Network services for public telephone systems Note: Network services are functions that your network provider makes available to you. You have to request these services from your network provider. They may be available or not depending on your county (e.g. "Immediate emergency call" on page 18 or "Automatic callback" on page 19). If you require assistance, please contact your network provider.

  • Page 17: Calls List

    Network services for public telephone systems Picking up a waiting call If you receive a call during another call, you will hear the call waiting tone in the handset. Depending on your network provider the number of the waiting call is displayed.
  • Page 18 Network services for public telephone systems Deleting entries in the calls list Delete individual entries CLIP Scroll through the calls list. At the selected entry, press the OK key. In the menu, select Delete . Press the OK key. Delete all entries at the same time CLIP In the calls list, press the OK key.

  • Page 19: Activating/Deactivating The Call Waiting Tone

    Network services for public telephone systems Immediate emergency call An emergency number stored in the network service is automatically dialled when the handset is lifted, without pressing a key. CLASS Hotline To activate: Select Activate . Press the OK key. Enter the emergency number.

  • Page 20: Deactivating Call Forwarding

    Network services for public telephone systems Activating call forwarding CLASS Divert Activate Call forwarding when busy: Select CFB . Press the OK key. Call forwarding when the call is not answered: Select CFNR . Press the OK key. Immediate call forwarding: Select CFU .

  • Page 21: Answering Machine

    Answering machine Operating the answering machine Activating/deactivating the answering machine Press the AM key to activate and press again to deactivate. or... Voice mail Status Select On or Off Press the OK key twice. When the answering machine is activated the AM key lights up on the base.
  • Page 22 Answering machine Recording your personal announcement The telephone is supplied with standard announcements for both announcement modes. You can record your personal announcement for both modes. Voice mail Announce Select Record anc. or Record only depending on the announcement mode. Press the OK key.

  • Page 23: Saving Number

    Answering machine Playing messages New unplayed messages are indicated by the flashing AM key Press to start playing new messages. Playback starts with the first new message. The number and the name of the caller are not displayed. The date and time and the number of messages are shown in the display. During message playback Go to the previous or next message.
  • Page 24 Answering machine Message context menu You can use message functions from the context menu during playing back messages. Press during playing back message. The playback is paused. Select the function. Press the OK key. Functions: Continue Continue with playing back messages. Delete msg.
  • Page 25 Answering machine Recording memos You can record your own notes (memos) locally, e.g. for your family. Voice mail Record memo Press the OK key to start recording. After the short tone speak your memo. Cancel recording with Press the OK key to end recording. After recording, the AM key flashes to indicaste, that a new memo is available.

  • Page 26: Setting Up The Answering Machine

    Answering machine Setting up the answering machine The answering machine is supplied set up ready to use. You can also make personal settings. Setting the ring delay You can set when the answering machine should be start recording. Voice mail Ring delay Select 0s / 10s / 18s / 30s / Auto .

  • Page 27: Operating The Answering Machine While Away From Home (Remote Operation)

    Answering machine Setting time control You can set a time control (3 time periods) for the answering machine. Then the answering machine is activated or deactivated depending on the time and date. You can also set which announcement should be used. To use this function you must activate the answering machine.
  • Page 28 Answering machine Calling your answering machine Dial your own phone number. While listing your own announcement, press and enter your PIN (default: 0000). If the PIN is incorrect, the connection is interrupted. The answering machine tells you whether you have new messages. You can operate the answering machine with the keypad.

  • Page 29: Entering Characters

    Appendix Entering characters Key Assignment in Edit Mode 10x 11x 12x 13x 14x ¤ € £ ¥ Blank ä á à â ã ç ë é è ê ï í ì î ö ñ ó ò ô õ ß ü ú...
  • Page 30 Appendix If you telephone is not working perfectly No signal tone: The tone volume might be set to 0. Lift handset, no dialling tone: Is the connecting lead correctly plugged into the telephone and the telephone socket? Dialling tone audible but telephone will not dial: The connection is OK.
