- Page 1 OWNER’S MANUAL...
- Page 2 Thank you for the purchase of your new Diamond Amplification Spitfire II 100watt guitar amplifier. This amplifier is of the highest quality and will give you years of enjoyment if it is well maintained. Before you begin, remember, learn your amp and you’ll be in the best position to achieve the tones...
-
Page 3: Table Of Contents
TONE/VOLUME CONTROLS ..................8 CHANNEL 1 ......................10 CHANNEL 2 ......................11 SWITCHING ........................12 FRONT PANEL SWITCHING ................... 12 SPITFIRE II CONTROLLER ..................12 ALTERNATE SWITCHING METHODS ..............13 TUBES ..........................14 TUBE LAYOUT ......................14 CHANGING/REPLACING TUBES ................14... -
Page 4: Features
Diamond Amplification’s Spitfire II. This manual will walk you through the features, controls and tonal possibilities available to you. -
Page 5: Front Panel
If you are using one speaker cabinet, you can plug into either speaker jack. Make sure your impedance selector is set to the same impedance as the speaker cabinet. If you are unsure of the impedance of your speaker cabinet, please find out before making your connection. SPITFIRE II OWNER’S MANUAL PAGE 2 OF 17... - Page 6 When the amp is used in this manner, the particular channel volume control becomes that channel’s “master” volume, which is functionally operating as the loop “send” level. SPITFIRE II OWNER’S MANUAL PAGE 3 OF 17...
-
Page 7: Before You Begin
1. Dial Channel 1 like this: a. Gain 2 b. Volume 5 c. Treble 5 d. Middle 5 e. Bass 5 f. Presence 5 SPITFIRE II OWNER’S MANUAL PAGE 4 OF 17... -
Page 8: Power/Standby
You should always return the amp to standby before turning off to allow the amp to “discharge” voltage. Doing this habitually will extend the life of your amp. SPITFIRE II OWNER’S MANUAL PAGE 5 OF 17... -
Page 9: Half Power
HALF POWER Your Spitfire II also comes equipped with a Half Power switch, which switches your output stage to triode rather than pentode operation. This cuts your 100w amp to effectively half- power allowing you to open it up without the ear splitting 100watts of power! It is preferable that you operate this switch only when the amp is off, but failing to do so will not likely damage your amp. -
Page 10: Effects Loop
4. Gently bring the E. Return knob up. When you get to about 2 or 3, you should be at a normal, listenable level for home practice, and tonally the amp should be about the same. SPITFIRE II OWNER’S MANUAL PAGE 7 OF 17... -
Page 11: Tone/Volume Controls
When the volume hits around 6 or 7, you’ll really hear a difference from the tone when the volume was on 3. Now let’s reverse it somewhat. Bring the gain down to 2 or 3 and set the volume at 3. Rinse and repeat. SPITFIRE II OWNER’S MANUAL PAGE 8 OF 17... - Page 12 So, forget what amp(s) you’ve used before. Here is how they work on this amp. SPITFIRE II OWNER’S MANUAL PAGE 9 OF 17...
-
Page 13: Channel 1
NOTE: Work your guitar’s volume knob and listen to how well the amp cleans up. Try a setting with more gain, then roll off your guitar’s volume to clean it up, rolling the volume back up for grittier passages or leads. SPITFIRE II OWNER’S MANUAL PAGE 10 OF 17... -
Page 14: Channel 2
Here’s a few sample settings to give you some idea of what you can do: Tight and Punchy Lower Gain setting: Presence: Bass: Middle: Treble: Volume: Gain: Heavier, but vintage-type and Higher Gain setting: Presence: Bass: Middle: Treble: Volume: Gain: SPITFIRE II OWNER’S MANUAL PAGE 11 OF 17... -
Page 15: Switching
Two rhythms and a boost for lead? You got it. One rhythm and one lead, forget the boost? All within your control on this amp. SWITCHING Your Spitfire II provides you a number of ways to switch your amp. Let’s get familiar with all of them! FRONT PANEL SWITCHING Your amp’s front panel comes equipped with 3 small toggle switches. -
Page 16: Alternate Switching Methods
“insert” cable (available at most music stores and generally used in PA’s), which is TRS at one end (connect this to the amp) and “Y’s” out to two mono jacks at the other end (connect to your switching device). SPITFIRE II OWNER’S MANUAL PAGE 13 OF 17... -
Page 17: Tubes
It is still good, however, to verify bias. If you feel competent to check or adjust bias, call DA for instruction. But generally, bias should average between 33 and 39 milliamps SPITFIRE II OWNER’S MANUAL PAGE 14 OF 17... -
Page 18: Diagnosing Tube Problems
If you can tell that it is in both channels (even if only slightly on one channel), it is most likely V1, which is common to both channels. A noisy SPITFIRE II OWNER’S MANUAL PAGE 15 OF 17... - Page 19 NOTE: It is always advisable to change preamp tubes one at a time. It is a good idea to keep at least one known good preamp tube for this purpose. Then you will know for sure if you have found the problem. SPITFIRE II OWNER’S MANUAL PAGE 16 OF 17...
- Page 20 DIAMOND AMPLIFICATION, INC. 5261 LANGFIELD RD. HOUSTON, TEXAS 77040 713.934.0100 (TEL) 713.934.0155 (FAX) www.diamondamplification.com...
