5 Watt
Solar Powered
Battery Charger
Installation Manual
Compatible with all Mighty Mule and GTO/PRO DC Powered Slide and Swing Gate Operators
the Mighty Mule 250 (FM250).
except for
All dual gate installations require a minimum of 10 Watts of solar charging power.
C
A
For more information on Mighty Mule's full line of automatic gate openers and access controls visit our website at www.mightymule.com
RB905
Rev. 11/5/07
Printed in China for GTO, Inc.
®
G
F
E
H
Parts Included:
A. Solar Panel
D
B. Lag Screws (4)
C. Pipe Clamp (4)
D. Curved Pipe
E.
C
F.
G. Wire Nuts
B
H. Compass
Tools Required :
• Slotted (flat blade) Screwdriver
7
•
/
" open end wrench
16
1
/
" Nuts (4)
4
1
/
" x
1
/
" Bolt (4)
4
2
FM121
©2007 GTO, Inc.
Advertisement
Table of Contents
Related Manuals for Mighty Mule FM121
Summary of Contents for Mighty Mule FM121
-
Page 1: Battery Charger
Solar Powered Battery Charger Installation Manual Compatible with all Mighty Mule and GTO/PRO DC Powered Slide and Swing Gate Operators the Mighty Mule 250 (FM250). except for All dual gate installations require a minimum of 10 Watts of solar charging power. - Page 2 Solar Panel Installation Step 1: Slide the " bolts (F) through the bottom of each channel so threaded part of each bolt comes through top of frame, position the pipe (D) between the bolts and place two clamps (C) over the curved pipe onto the bolts. The clamp at the top of the solar panel should fit over the pin on the curved pipe.
- Page 3 Step 3: All Mighty Mule and GTO/PRO DC powered gate operators have a POWER IN terminal on their control boards marked SOLAR for connecting the solar panel wires. Below are various types of terminals on GTO/PRO and Mighty Mule control boards, if your control board doesn't have this terminal, please call the GTO's Technical Service Department at (800)543-1236 or (850)575-4144 for assistance.
- Page 4 Solar Zones and Gate Activity Use the table and map to determine the number of operational cycles* per day to expect in your area, using 5 to 30 Watts of charging power. Figures are shown for winter (minimum sunlight) and do not account for the use of any accessory items.
- Page 5 Other Mighty Mule and GTO/PRO Access Controls and Accessories Push Button Control (FM132) Unlit doorbell button for remote entry or exit control. Wires directly to the control board and uses 16 gauge multi-stranded, dual conductor low voltage wire (sold separately).
- Page 6 GTO Technical Service: 1-800-543-1236 or (850) 575-4144 • Fax (850)575-8950 The contents of all material available on this installation manual are copyrighted by GTO, Inc. (“GTO”), unless otherwise indicated. All rights are reserved by GTO, and content may not be reproduced, downloaded, disseminated, published, or transferred in any form or by any means, except with the prior, written permission of GTO.
