Page 1: Media Converter
Model LTM-5500FS User Manual LTM-5500FS Blue Flame Pro IEEE 1394 Bidirectional ® FireWire Media Converter © 2001 Laird Telemedia. - Page 2 Balanced audio signals are also converted to unbalanced signals for standard amplifier monitoring. The LTM-5500FS delivers broadcast ana- log signals to the world of DV, and can add new life to older technology that is not DV compatible. The LTM-5500FS is housed in a 1RU cabinet.
- Page 3 LTM-5500FS Blue Flame Pro IEEE 1394 (DV) Bidirectional Media Converter PECIFICATIONS INPUTS ANALOG VIDEO IN: Component Video: R-Y, B-Y, Y (YUV) - 3 BNC Composite Video: 1Vp-p into 75 - BNC YC (S-Video): 1Vp-p Y into 75 - 4-Pin Din .7Vp-p C into 75...
- Page 4 LTM-5500FS Blue Flame Pro IEEE 1394 (DV) Bidirectional Media Converter RONT ANEL ONNECTIONS Y/C Video Input/Output Balanced Audio Inputs, 600 Line Level Composite Video Input/Output Unbalanced Audio MONITOR OUTPUTS for use with monitoring equipment (ie. amplifiers) THIS IS NOT DV Mode Switch (Reset)
- Page 5 Composite to DV mode. A second push selects the COMPONENT/YC mode. There is a Toggle switch located to the right of the ANALOG switch that is labeled YUV. If this switch is in the down position, then the LTM-5500FS will input the YC sig- nals for DV conversion.
- Page 6 OUTING QUIPMENT The LTM-5500FS provides a professional interface for the demanding multimedia environment of modern telecommunica- tions facilities. Indicated below are a few application diagrams, which display the flexible and cost effective use of the LTM- 5500FS with other LTM products.
-
Page 7: Safety Precautions
9. A trained qualified technician should perform all servicing of the unit. There are no serviceable compo- nents within the unit for user access. All Laird Products are Manufactured in the USA by Laird Telemedia, Mount Marion, NY FireWire, Apple and G4 are registered Trademarks of Apple Computer, Inc. - Page 8 2000 Sterling Road • Box 720 Mount Marion, NY 12456 800-898-0759 • 845-339-9555 Fax: 845-339-0231 www.lairdtelemedia.com...
