Specifications - BELINEA o.book 2.1 User Manual

Specifications

Processor and Platform
• AMD Turion X2 Processor up to TL -56
TM
• µFC-PGA package (Socket S1g1)
• ATI RS690MC + ATI SB-600
RAM
• Main memory expandable to 2 GB DDR2 SDRAM
(Only allow qualified service personnel to expand the main memory)
• Two PC2500 SODIMM sockets (DDR2667 ,  MHz)
Display and Video
• 15,4 inch WXGA TFT display
Supported resolution 1280 × 800 with up to 16.7 million colors
• Integrated graphics adapter: ATI Radeon
• Simultaneous LCD/external monitor
• External monitor:
Supports up to 1600 × 1200, 16.7 million colors
• Webcam with 1. megapixel
Storage Capacity
• One SATA hard disk (2.5" , 9.5 mm)
• One internal optical drive
• One memory card slot for MultimediaCard (MMC), SecureDigital Card (SD),
Memory Stick (MS), and MS Pro
Audio
• Realtek High Definition Audio
• Built-in stereo loudspeakers
Belinea o.book 2.1
Xpress 1200
TM
5
