American Standard 4453 Specification Sheet

4453 Shown
127mm
(5)
(7/8)DIA.
51mm
(2)MAX.

GENERAL DESCRIPTION:

Cast brass body and swivel spout. Metal lever handle.
Washerless 47mm ceramic disc valve cartridge with Hot Limit
Safety Stop. Braided flexible supply hoses with 3/8"
compression connections. 2.2 gpm/8.3L/min. maximum flow
rate. Brass mounting shank with brass fixation ring (for
installation on counters up to 2"). Can be mounted with or
without supplied escutcheon plate (escutcheon size 10-7/8"L
x 2-1/2"W). Color-matched hand spray. Cap provided for less
spray applications.
SUGGESTED SPECIFICATION:
Single control kitchen faucet shall feature a cast brass body and cast brass swivel spout. Metal lever handle. Shall also
feature washerless ceramic disc valve cartridge with integral hot limit safety stop and flexible supply hoses. Faucet shall be
American Standard Model # 4453.
© 2008 AS America, Inc.
22mm
276mm
(10-7/8)
SINGLE CONTROL KITCHEN FAUCET
MODEL NUMBER:
4453 Single Control Kitchen Faucet
Color-matched spray thru escutcheon.
Deck plate (use is optional). Polished Chrome finish.
240mm
(9-1/2)
127mm
(5)
216mm
(8-1/2)
35 to 38mm
(1-3/8 to 1-1/2)
555mm
DIA. MOUNTING
(21-7/8)
HOLE

PRODUCT FEATURES:

Easy to Install:
Flexible supply hoses are factory-installed for
fast hook-up
Ideal for Granite and Other Solid Surfaces:
without deck plate for single hole installation
Cast Brass Spout:
For durability and long life
Ceramic Disc Valve Cartridge:
smooth handle operation and drip-free performance
Adjustable Hot Limit Safety Stop:
water allowed to mix with cold to reduce the risk of accidental
scalding
Lifetime Warranty:
On function & finish
HD-69
ELITE
192mm
(7-1/8)
165mm
(6-1/2)
41mm
(1-5/8) MAX.
Mounts
Provides a lifetime of
Limits the amount of hot
