Page 1: Dual Streaming
Dual Streaming H.264 Multiplex 4CH/8CH Network DVR Support 3G/3.5G mobile phone/PDA (Symbian/Windows Mobile/iPhone/iPad/Blackberry/Android) Support 2xSATA User Manual V1.1... - Page 2 CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE. PLEASE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. NOTE: This equipment has been tested and found to comply with the limits for a Class “A”...
-
Page 3: Limitation Of Liability
LIMITATION OF LIABILITY This users’ manual is supplied ‘as is’, with no warranties, be it expressed or implied, including, but not limited to, the implied warranties of merchantability, suitability for any exact purpose, or non-infringement of any third party’s rights. This publication may include technical inaccuracies or typos. - Page 4 PRECAUTIONS Please refer all work related to the installation of this product to qualified service personnel or system installers. Do not operate the appliance beyond its specified temperature, humidity or power source ratings. Use the appliance at temperatures between 0 C (32 F) and humidity below 85%.
-
Page 5: Table Of Contents
5.3.6 OSD Setting ................................. - 29 - 5.3.7 Record Resolution ............................... - 30 - 5.3.8 Dual Streaming for Network(Record-Advanced Setting) ................. - 30 - 5.4.1 Camera Channel ..............................- 31 - 5.4.6 Motion Detection Setting ............................ - 31 - ... -
Page 6: Starting
6.6.1 Video Files Playback ............................- 48 - 6.6.2 Download Video Files ............................- 49 - 6.6.3 Device Log ................................- 49 - 6.6.4 Water Mark Verification ............................. - 50 - ....................- 50 - 6.7 C HANNELS ALLOCATION IN AMERA VIEW WINDOW... -
Page 7: Dvr Network Setup And Web Browser
Please refer to Chapter 4.5, Chapter 4.6, Chapter 4.7 to search, playback, and archive the recorded video/audio. Please refer to Chapter 5.4.6/5.4.8 for motion Detection, Chapter 5.4.7 for Privacy Mask(Mosaic), and Chapter 5.6 for Alarm setting Please refer to Chapter 3.3 for PTZ camera connection, Chapter 4.8 Chapter 5.4... -
Page 8: Product Overview
1.2.2 Remote Access -> IE Operations Please note that the PC user must have system administrator password for the PC; otherwise, the process will fail, and an error dialog will be shown. For the Windows 7/Vista, please turn off the UAC function – Chapter Turn Windows... -
Page 9: Front Panel
1 or 2 SATA Interface (2TB/4TB) Storage Capacity 4 Inputs, 1 Output (NC, NO relay Alarm RJ-45 10/ 100 Base T Ethernet connector (PPPoE, DHCP, DDNS, Static IP), Network UPnP and FTP IE Browser Live Monitor, Configuration, Download Video, Playback, and Network Function Mobile Phone Surveillance Mouse/Potable Mobile HDD/Flash Drive/DVD Burner/Firmware Upgrade... - Page 10 2. MENU: Press this button to display the main menu. 3. ESC: Exit window or switch the tool bar(main menu) and status bar 4. REC: Start or Stop manual record function. 5. Backup: Open video search and backup menu 6. Play/Pause ( ): Open video search and playback menu.
-
Page 11: Back Panel
Key buttons 2 ~ 12 are same as 4CH DVR, except: 1. Complex keys - CH1/CH5, CH2/CH6, CH3/CH7, CH4/CH8, Channel 1/Channel 5, Channel 2/Channel6, Channel 3/Channle 7, Channel 4/Channel 8 toggle switch button, and also button switch between 1/9 camera windows Start and Stop time setting of playback or back up in schedule record(Chapter 4.5 Video Playback), or... -
Page 12: Hardware Installation
Alpha-numeric Buttons (1-9, 0, 10+):Press these buttons for camera selection in most circumstances. These buttons can also be used to enter text and number DEL Button (DEL): In text editing mode, this button is used as “del” key. Alarm Reset Button: Press this button to cancel alarm activation; click this button will pop a message to show the present alarm information. -
Page 13: Ptz Control Connections
connect to our DVR as follows(right): Power Cable Data Cable Data Cable Power Cable Internal DVD Burner message appears only in Video Backup with MPEG4 format, please refer to Chapter 4.6 Video Backup For the internal fixed HDD installation, there is no HDD bay for it, there are 4 screw holes underneath housing bottoms, where you can secure them as below: 3.3 PTZ Control Connections Connect the PTZ control interface to RS485 T... -
Page 14: Live View Screen (Status Bar)
Status Bar Tools Bar DVR system status bar at the bottom of the screen. Right-click mouse key or press 【Enter】at front panel will open【Tools Bar】for system setting and operating. 4.1 Live View Screen (Status Bar) Single Channel display: When in 4/9 split view modes, the window with highlight green border is the current selected one. -
Page 15: Main Menu(Tools Bar)
The The last icon (4/8CH) indicates alarm output. When happened, it changes into red color. HDD normal(blue) HDD Failure(red) Network connected(blue) Network disconnected(gray) HDD percentage recorded No. of cameras network connected Hard Disk Overwrite 4.2 Main Menu(Tools Bar) Right click mouse or press 【Enter】 button in preview mode, the Tool Bar shown as below will appear: : Hide the tool bar. -
Page 16: Video Record
HDD information will display on the windows if DVR detection HDD correctly. Click 【Formatting】to start HDD format. 4.4 Video Record There are two methods to precede record in DVR, manual record and schedule record. If the record schedule is conflict with manual The priority of manual record is higher than schedule. -
Page 17: Video Playback
The video recorded manually is named “common recording” Schedule Record Please select <Tool Bar> → < Setting > → <Record> → < Record Schedule> to set. The setting screen is shown as the figure below: ①． The current recording channel number ②．... - Page 18 record types. Date & time search by Panel or remote control In order to playback a certain video feed from a particular camera, you first need to indicate what time and which camera you wish to receive this information from. Move highlight icon to relevant selection box using 【...
-
Page 19: Video Backup
have a vertical line show up , second left-click will mark 【stop time】. Mouse right-click will clear all marked time. Playback Control ：Back backwards, the available speeds are 8X, 16X ：Fast forward, the available speeds are 2X, 4X, 8X, 16X, 1/8X, 1/4X and 1/2X. ：Pause ：Stop playing. -
Page 20: Play Backup Video On Pc
Click [Backup] to enter into the backup screen. System will detect all the backup devices available and display them. Backup device can use USB flash drive, USB portable HDD and USB DVD Burner. Only support FAT32 file system for USB flash and HDD Please select the suitable device and record type according to requirement first, and click [Backup] to start save audio/video. -
Page 21: Ptz Control
playback MPEG4 file by Windows Media Player. Please note you don’t have to install this component for playback every time, it is one time installation; or you can use the “MP4Player” to play back MPEG4 format, please refer to Utility inside the CD of this package(Appendix H264 video format playback, you may go to... - Page 22 Click to zoom in/zoom out (it is disabled for cameras with ○ 3 Zoom automatic focus). Click to make the image brighter or darker (it is disabled ○ 4 Iris for cameras with automatic iris adjustment). Click to focus-in and focus-out (it is disabled for cameras ○...
-
Page 23: Dvr Setting
5. DVR Setting 5.1 Menu Tree & Operate - 22 -... -
Page 24: System Setting
General Operations Press 【MENU】 button to enter into system setting screen. Press 【●】 button to start/stop recording manually. Press 【 】 button to play record file. Press【PTZ】 button to enter into PTZ control screen. Menu Selection The highlight menu is the current active one. User can move highlight icon to the menu needed using 】... -
Page 25: Password Setting And What If Forgotten
**Take effect immediately ** 5.2.5 Time Setting Select time display way and adjust date/time of DVR, you can choose “AM”/”PM” display if Time Format is “12-Hours”, which will change the Chapter 5.7.1 Log View time display format **Take effect immediately ** In order to avoid record files’... - Page 26 Add User Account Enter “ADD USER” to add user account, most 7 users accounts can be produced, and there will be warning message if exceed. Delete User account Enter “DEL USER” to delete user account Authority Manage Operation authority of DVR for “User” account can be defined by system. There are two conditions to apply restriction, Local operation and Remote access.
-
Page 27: Resource Management
SEQ Display(Preview Cruise) Set up the SEQ display (Cruise Way) for 4CH(1/4CH) and 8CH(1/4/9CH), and the time interval(Cruise Way) in seconds between them, also choose the channels for Preview Cruise DVR ID NUMBER It is future growth, to set up the same ID number with RS422 Keyboard if you want to control DVR from keyboard. - Page 28 Please refer to following Resource Management table for 4CH and 8CH, these DVR have different Record and Playback mode as below: 4CH Resource Management and Maximum Record/Playback resolution and frame rate for each channel) Recording/Playback mode Set up Mode Record and Function Note Playback mode...
-
Page 29: Record Setting
8 Channel 8 Channel HD1 Any channel can Record/Playback maximum Just press “OK” to finish set Encode + 8 NTSC: 15FPS(HD1), 30FPS(CIF); PAL: up, no need click channel no. Channel HD1 12.5FPS(HD1), 25FPS(CIF), can not set up Playback D1 in 5.3.7 Record Resolution 1 Channel D1 1 Channel D1... -
Page 30: Video Quality
Low 384kbps or user define. User can manually input bit rate for recording. (Kbit/s). The higher video bit rate would impact network remote viewing if you don’t open the sub code(sub streaming) for dual streaming, please refer to 5.3.8 Dual Streaming. -
Page 31: Record Resolution
Please note 4CIF=2 Half D1=D1, so that “Record Frame Rate” would be reduced automatically even you set up as “Full” for D1 and Half D1. 5.3.8 Dual Streaming for Network(Record-Advanced Setting) SUB CODE By default, DVR use recording streaming for IE Browser viewer and mobile streaming. Enable sub code can customize the frame rate and bitrate for IE client viewer and mobile streaming in case of limited upload bandwidth, and they can be setup independently for every channel. -
Page 32: Camera Channel
5.4.1 Camera Channel Select camera channel for apply camera setting. Select [ALL] for apply to all channels 5.4.2 PTZ Protocol Select PTZ device protocol. Support CLT-618, JY2000, Philip, Pelco-D, Pelco-P, Panasonic, Samsung, SYYT, TD500, Tiandy, VIDO, VTS, YAAN, Yiboer and etc. 5.4.3 PTZ Baud Rate Select PTZ device baud rate. -
Page 33: Motion, Video Lost And Channel Name(Video- Advanced Setting)
To cancel the privacy region, by use mouse/ left-click, or press (faceplate button), or press [FN] (remote control) to move to the privacy region, and press [ECS] or mouse/right-click to confirm; by mouse right-click or press [ESC] again to finish the setting and return back to manual. Each privacy region will show only gray color in live view windows and being recorded. -
Page 34: Net Setting
Motion Detect Video Loss Channel Name Setting – at most 16 characters, but only can display 11 characters 5.5 Net Setting 5.5.1 Network (Static IP/DHCP) DVR support two methods to acquire IP address, Automatic acquire IP address by DHCP client model. Manual assign IP address by Static IP model. - Page 35 If DVR installed behind a Router to share a single public IP address. Be sure to configure the “Port Forwarding” or “Virtual Server” for those three network port and Mobile surveillance Port:7050; you may surf http://portforward.com for more information. Http port:80, Command port:5050, Media port:6050 and mobile surveillance port:7050 must open/allow to upload to WAN interface if DVR installed behind a Firewall server;...
-
Page 36: Email Server Set Up For Email Notify
update.ods.org www.easydns.com www.justlinux.com www.dyns.cx www.hn.org www.zoneedit.com members.3322.org members.3322.org(static) members.dyndns.org members.dyndns.org(static) www.EZ-IP.net www.penguinpowered.com members.dhs.org cgi.tzo.com Auto Register DVR can configure to automatically register to CMS, input CMS Server IP address, Server Port: 8003(default) and register time interval in seconds(register to CMS server if failed); it is not necessary setup because you can add this DVR in CMS server manually. -
Page 37: Upnp And Mobile Port(3 Rd Page In Net Setting)
The Email To field indicates the recipients of alarm emails, and the Email From field indicates the email account from which the message will be sent. You can input the Email To field and [ADD] it into the list of recipients. You can [VIEW] the list of recipients in the Email to list, where you can delete if no need any more. - Page 38 Click the , it will appear “Query port mapping status” message, and you will find the following screen shot if successful in UPnP mapping Mobile PORT By default is port: 7050, user can specify different port number, please refer to Chapter 7.
-
Page 39: Alarm Input Type
Select alarm input channel for apply record setting. Select [ALL] for apply to all channels. 5.6.2 Alarm Input Type The alarm input attribution includes N/O. and N/C. Each camera has one input pin on Terminal Block at the real panel. User must use voltage output type sensor to connect alarm input interface. -
Page 40: Alarm Setting(Schedule), Zoom Out And Hard Disk Full Actions
5.6.4 Alarm Setting(Schedule), Zoom Out and Hard Disk Full actions ALARM SETTING - Alarm Schedule Click 〖>>〗to open sub window for alarm schedule setting. User can enable/disable by weekly schedule, the unit is hour, enable is red, disable is alarm output white. -
Page 41: Log View
5.7.1 Log View Select the type of log to be searched: All/ Operation/ Exception/ Alarm. Select the time scope to be searched(it will display AM/PM if select correct Time Display format) Click Search to display the detail information of log. Note: The maximum number of logs supported currently is 3000. -
Page 42: Show Dvr Current Hdd Capacity Status
5.7.4 HDD Capacity Show DVR current HDD capacity status. 5.7.5 Hardware Version Show DVR current hardware version. 5.7.6 Software Version Show DVR current software version. 5.7.7 Software Release Date Show DVR current software release date. 5.8 Save Setting 5.8.1 Save & Exit Save all setting and exit menu. -
Page 43: Web Browser Operation(Ie Browser Only)
6. Web Browser Operation(IE Browser only) 6.1 Enable Download Un-singed ActiveX Control if necessary User’s computer need download ActiveX components for web access at the first time connect to DVR. If user’s Internet explorer prohibits the download action(the DVR software is unsigned) then please manually enable the download of un-signed ActiveX in IE. -
Page 44: Alarm Notification
Check “Automation Open All Preview” to watch all cameras after login. Camera view window: Full Screen /1 camera / 4 cameras / 8 cameras /9 cameras Camera view is previewing Camera view tools ：Adjust image contrast up/down. ：Adjust brightness up/down. ：Start/stop voice monitoring(Chapter 5.3.5). -
Page 45: Device Parameters Settings
When alarms of remote notification occur, the alarm notification with alarm input number contained such as “Device alarm: IO alarm, IO input x” will be displayed in the right up side of the main screen. Enable this function in Device Parameters setting. When alarms of motion detection with remote notification occur, the alarm notification with the alarm channel number contained such as “Device alarm: motion detection, channel X”... - Page 46 Channel Camera setting, Sub Bitstream, Subcode – please refer to 5.3.8 Dual Streaming for Network(Record- Advanced Setting) as well For limited upload bandwidth of internet that DVRs connect, or limited streaming capability of some mobile phone/PDA, you have to adjust bandwidth of DVR to internet: [Enable Subcode] ->[Sub Bitstream] ->[Video Bitrate]...
- Page 47 Serial PTZ Setting Alarm alarm input / output setting and HDD full action Device Firmware upgrade , time synchronize and E-mail Notify setup - 46 -...
- Page 48 User User account and authority setting State – HDD capacity, Channel and Network status - 47 -...
-
Page 49: Video Files Playback & Download
6.6 Video Files Playback & Download 6.6.1 Video Files Playback Click , the playback screen will appear. It includes video files search, playback and video files download. Video Files Search The file search part is on the right upper side of the screen, please set target, type, start time and end time there. -
Page 50: Download Video Files
Video File Playback The play control screen is on the left side of the screen. It includes image display area, play control bar, and channel information. Click , the record files selected will be displayed in time order. The progress of playing is shown as the figure below: The playing control bar is shown as the figure below. -
Page 51: Water Mark Verification
For limited upload bandwidth of internet that DVRs connect, or limited streaming capability of some mobile phone/PDA, you have to adjust bandwidth of DVR to internet, please refer to 5.3.8 Dual Streaming for Network(Record- Advanced Setting) 6.5 Device Parameters Settings - Channel... -
Page 52: Windows Mobile
Note: Prior to using this feature, you should apply for the Internet connection service for your mobile phone, such as 3G or 3.5G. Please contact your mobile service provider for details. You can only watch one live feed channel at a time with your mobile phone. - Page 53 IP address line Camera info. Camera view Status information line Control buttons Functional buttons Play/Stop Snap Next Full Mode Setting Exit In order to navigate between the buttons, please use the directional keys of your Symbian mobile phone. Explanation of the menu buttons and program interface: Status information line.
- Page 54 Back to the main window, and press the button to connect to the DVR. After your device successfully logs in to the DVR, you can watch the remote video feed on your Symbian mobile phone. Mobile phone reference list for OS S60 3rd: LG-KT610 S60 3rd_FP1 10-Feb-08...
-
Page 55: Iphone/Ipad Series
7. 3 iPhone/iPad Series Please use 2 generation iPhone3GS/iPhone4 or iPad , this Apple application, like all iPhone/iPad application, needs to be downloaded directly from the iPhone/iPad AppStore. Open Apple iTunes Search for “KWeye” from our third party supplier. It will be a free application. Download and install onto iPhone as per iPhone installation procedures. -
Page 56: Blackberry Series
7. 4 Blackberry Series 1) Program installation 1. Open accessory CD and copy the setup software “KWeye.cod” and “KWeye.alx” to your PC. 2. In order to be able to install applications and themes via BlackBerry Desktop Manager, firstly the PC should install Blackberry Desktop Manager. - Page 57 7. Once you click “Browse” you will see a file search screen like the one below. Go to and locate where you saved the application files. Make sure you saved both the “.alx” file and “.cod” file in the same folder.
- Page 58 2) System explanations KWeye phone port has the following capabilities and functions: live video surveillance, channel switch, full screen display, PTZ control, including zoon/focus/iris, image capture, save as favorite and exit function. ① System main interface After the installation, press “KWeye”...
-
Page 59: Android Mobile (Google Phone Compatible)
Network Info. Network Type: Network through which you connect to the internet, like 3G, WiFi or others Click after setting to connect, or click to choose other DVR that ever set up for streaming. ③ Function buttons Click icon to connect DVR immediately, after login DVR successfully, user can watch the remote video from mobile phone;... - Page 60 System Settings: As the right photo for last page, you may set up the parameters as below: Devices Info.: Address: DVR IP address or DDNS Port : Mobile Port [6003 by default] DeviceName: Description of this DVR User Name: Login User Name〖Admin〗by default Password: Password [888888 by default] Click after setting to connect, or click...
-
Page 61: Appendix
8. Appendix Appendix A-HDD Capacity/Recording Time Estimate Calculate the maximum capacity of the build-in hard disk. Timing Recording: Step 1: Calculate the maximum capacity of the hard disk needed in selected channel per hour, suppose as Si (MByte) (i is the channel number), and suppose the bit rate of the channel selected as D (Kbit/s). The formula of calculation is: Si =（D*3600）/（8*1024）= D * 0.439453125 MB Step 2: Confirm the storage time length, suppose as T hours. -
Page 62: Appendix B- Compatible Hdd List
Appendix B– Compatible HDD List The other brand or model, please test by yourselves Item Model Number Size(GB) Drive WD5001ABYS, WD5000AADS SATA WD5000AVVS, WD5000AVDS SATA WD7500AACS SATA WD10EADS, WD10EVDS, WD10EALS 1000 SATA WD15EADS 1500 SATA WD20EVDS, WD20EADS 2000 SATA HITACHI HDS721050CLA362 SATA HITACHI... - Page 63 Samriddhi Automations Private Limited Corporate Office: B - 118, Sector - 10, Noida, U.P. (India) Tel : + 91 - 120 - 4518 900 (20 Lines) Works: Plot No. : 75, Sector - 7, I.I.E., SIDCUL, Haridwar (India) Tel : + 91- 01334 - 645 011, 239 396 Service Center: A - 1 / 15, New Kondli, New Delhi.
