VersiVision
FVTM4CCx / FVRM4CCx
4-CHANNELS DIGITALLY ENCODED VIDEO,
4-CHANNELS BI-DIRECTIONAL DATA
AND
4-CHANNELS BI-DIRECTIONAL AUDIO
MULTIPLEXER
USER'S MANUAL
Revision C
© April 2007
VERSITRON, Inc.
83 Albe Drive / Suite C
Newark, DE 19702
www.versitron.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VersiVision FVTM4CCx and is the answer not in the manual?

Questions and answers

Summary of Contents for Versitron VersiVision FVTM4CCx

  • Page 1 VersiVision FVTM4CCx / FVRM4CCx 4-CHANNELS DIGITALLY ENCODED VIDEO, 4-CHANNELS BI-DIRECTIONAL DATA 4-CHANNELS BI-DIRECTIONAL AUDIO MULTIPLEXER USER’S MANUAL Revision C © April 2007 VERSITRON, Inc. 83 Albe Drive / Suite C Newark, DE 19702 www.versitron.com...
  • Page 2 Purchases made prior to January 2001 are warranted for a period of one year from date of delivery. VERSITRON reserves the right to repair or, at our option, replace parts which during normal usage prove to be defective during the warranty period provided that: 1.
  • Page 3: Table Of Contents

    Table Of Contents General Information ……………………………………………. 3 Introduction ……………………………………………….… 3 Technical Specifications ………………………………….. 3 Installation Instructions ………………………………………... 6 Installation Procedure ……………………………………... 6 Indicator LEDs …………………........Syste m Terminal Block Connections ………………..8 Troubleshooting ………………………………………………… 14 www.versitron.com FVxM4CCx...
  • Page 4: General Information

    GENERAL INFORMATION Introduction: The VERSITRON VersiVision FVTM4CCx and FVRM4CCx Series video, audio and data transmitter and receiver support simultaneous transmission of four channels of 8-bit digitally encoded video, four channels of 24-bit bi-directional digitally encoded audio and four channels of bi-directional data over one single -mode or multi-mode optical fiber. The units are universally compatible with major camera systems and support RS-485 data protocol.
  • Page 5 Aluminum MTBF > 100,000 hours Operating Temp -30° C to +50° C Storage Temp -40° C to +85° C Relative Humidity 0% to 95% (non-condensing) INDICATOR Module Blue Video Sync Present Blue Data Sync Present Orange Power On www.versitron.com FVxM4CCx...
  • Page 6 FVTM FVRM Singlemode 4CCx -5 dBm 4C Cx -26 dBm 21 dB 30km Fiber Wavelength Receiver Transmitter Optical Model Output Model Sensitivity Power Distance Budget Singlemode 1310/1550nm FVRM FVTM 4CCx -10 dBm 4CCx -22 dBm 12 dB 30km www.versitron.com FVxM4CCx...
  • Page 7: Installation Instructions

    INSTALLATION INSTRUCT IONS Installation Procedure The VERSITRON VersiVision FVTM4CCx and FVRM4CCx video transmission systems series are preset for immediate use. There are indicator LEDs on the units for monitoring the real-time status of video, data and power. The following instructions describe the typical installation procedure and the function of the LED indicators located on each unit.
  • Page 8: Indicator Leds

    (No Video present on output BNC) ON: (Blue) Indicates video detected on output BNC connector (Video present on input BNC) Data: OFF: Indicates no data detected on the receive data cable Blinking: (Blue) Indicates data received at the rate of the operation data. www.versitron.com FVxM4CCx...
  • Page 9: Syste M Terminal Block Connections

    NOTE: Only the upper row of RJ-45 ports is used for these units. The lower row of ports is for expanded models and is not used on these units. In addition, the two ports above the label “TD” are used for VERSITRON testing. Data RS-485 Connection (Transmitter):...
  • Page 10 Terminal No.2—— Ground Channel 2 Terminal No.3—— Audio Input 2 Terminal No.4—— Ground Channel 3 Terminal No.5—— Audio Input 3 Terminal No.6—— Ground Channel 4 Terminal Block for Audio Connections Terminal No.7—— Audio Input 4 Terminal No.8—— Ground www.versitron.com FVxM4CCx...
  • Page 11 Terminal No.2—— Ground Channel 2 Terminal No.3—— Audio Output 2 Terminal No.4—— Ground Channel 3 Terminal No.5—— Audio Output 3 Terminal No.6—— Ground Terminal Block for Audio Connections Channel 4 Terminal No.7—— Audio Output 4 Terminal No.8—— Ground www.versitron.com FVxM4CCx...
  • Page 12 NOTE: Only the upper row of RJ-45 ports is used for these units. The lower row of ports is for expanded models and is not used on these units. In addition, the two ports above the label “TD” are used for VERSITRON testing. Data RS-485 Connection (Receiver):...
  • Page 13 Terminal No.2—— Ground Channel 2 Terminal No.3—— Audio Input 2 Terminal No.4—— Ground Channel 3 Terminal No.5—— Audio Input 3 Terminal No.6—— Ground Terminal Block for Audio Connections Channel 4 Terminal No.7—— Audio Input 4 Terminal No.8—— Ground www.versitron.com FVxM4CCx...
  • Page 14 Terminal No.2—— Ground Channel 2 Terminal No.3—— Audio Output 2 Terminal No.4—— Ground Channel 3 Terminal No.5—— Audio Output 3 Terminal No.6—— Ground Terminal Block for Audio Connections Channel 4 Terminal No.7—— Audio Output 4 Terminal No.8—— Ground www.versitron.com FVxM4CCx...
  • Page 15: Troubleshooting

    TROUBLESHOOTING Optical Fiber The VERSITRON VersiVision FVTM4CCx and FVRM4CCx Series is available with most applications using multi-mode or single-mode optical fibers. Please be certain that the correct size and type of the fiber is being used for the particular mode transmitter/receiver combination.
