- Page 1 VersiVision FVTM880x / FVRM880x 8-CHANNEL DIGITALLY ENCODED VIDEO WITH RETURN DATA MULTIPLEXER USER’S MANUAL Revision B © February 2006 VERSITRON, Inc. 83 Albe Drive / Suite C Newark, DE 19702 www.versitron.com FVxM880x...
- Page 2 January 2001 are warranted for a period of one year from date of delivery. VERSITRON reserves the right to repair or, at our option, replace parts which during normal usage prove to be defective during the warranty period provided that: 1.
-
Page 3: Table Of Contents
Data Cable Connections ..................Wiring Diagrams ………………………………………………………………. 10 Troubleshooting …………………………………………………………………… 11 NOTE: VERSITRON uses the same front panel for multiple products. Not all features are available on all models; therefore you should verify the features of your specific model. ２... -
Page 4: General Information
GENERAL INFORMATION Introduction: The VERSITRON VersiVision FVTM880x and FVRM880x Series video and data transmitter and receiver support simultaneous transmission of 8-channels of 8-bit digitally encoded video and return data over one multi-mode or single-mode optical fiber. The units are universally compatible with major camera systems and support the RS-485 data protocol. - Page 5 Power Supply： 110/220VAC Size： 18.98 x 9.76 x 2.68 Inches Construction： Aluminum MTBF： > 100,000 hours Operating Temp： -30° C to + 50° C Storage Temp： -40° C to + 85° C Relative Humidity： 0% to 95% (non-condensing) ４ www.versitron.com FVxM880x...
- Page 6 Direct viewing of this LED should be avoided at all times. Fiber Wavelength Transmitter Receiver Optical Power Distance Model Model Budget Singlemode 1310 nm 1490 nm FVTM880x FVRM880x 15 dB 20km 1550 nm ５ www.versitron.com FVxM880x...
-
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS Installation Procedure The VERSITRON VersiVision FVTM880x and FVRM880x video transmission systems series are preset for immediate use. There are indicator LEDs on the units for monitoring the real-time status of video, data and power. The following instructions describe the typical installation procedure and the function of the LED indicators located on each unit. -
Page 8: Indicator Leds
ON: (Blue) Indicates video detected on output BNC connector (Video present on output BNC) DATA1: OFF: Indicates no data detected on the receive data cable Blinking: (Blue) Indicates data received at the rate of the operation data. ７ www.versitron.com FVxM880x... -
Page 9: Rear Panel Diagrams
８ www.versitron.com FVxM880x... -
Page 10: Data Cable Connections
Data Cable Connections The various input and output connections for the VERSITRON VersiVision FVTM880x and FVRM880x video transmission systems series are as follows: Video Input or Output: BNC Connectors Data RS-485 Connection: Red Wire = (+) Signal being transmitted or received over fiber. -
Page 11: Wiring Diagrams
FVTM880x FVRM880x Video Transmitter Video Receiver Simplex Multi-Mode or Single-Mode Fiber Optic Cable Cameras are daisy-chained together to create one data input Video into the Controller Monitors FVTM880x. Video Cameras Return PTZ Control RS-485 (+) RS-485 (-) １０ www.versitron.com FVxM880x... -
Page 12: Troubleshooting
TROUBLESHOOTING Optical Fiber The VERSITRON VersiVision FVTM880x and FVRM880x video transmission systems series is available for most applications using multi-mode or single-mode optical fibers. Please be certain that the correct size and type of the fiber is being used for the particular transmitter/receiver combination.
