Linkbox 8000HD User Manual

Hd satellite receiver
Hide thumbs Also See for 8000HD:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
User's Guide
Linkbox 8000HD
HD Satellite Receiver
LinkTV Media
Sun Valley, California, U.S.A.
© Copyright 2012, LinkTV Media

Advertisement

Table of Contents
loading

Related Manuals for Linkbox 8000HD

Summary of Contents for Linkbox 8000HD

  • Page 1 User’s Guide Linkbox 8000HD HD Satellite Receiver LinkTV Media Sun Valley, California, U.S.A. © Copyright 2012, LinkTV Media...
  • Page 2 © Copyright 2012, LinkTV Media Page 1...

  • Page 3: Table Of Contents

    CONTENTS GETTING STARTED ..................... 4 Introduction ......................4 Caution ....................... 4 What’s inside the box ..................5 Control and Displays ..................... 6 Operation ....................... 8 Initial Setup ......................8 Installation ......................8 3.2.1 Antenna Connection ..................8 3.2.2 Satellite List and Antenna Setup ..............8 3.2.3 Single Satellite Search ..................
  • Page 4 3.7.3 PVR Setting ....................18 3.7.4 Media Player ....................18 PVR ........................20 3.8.1 Recording ..................... 20 3.8.3 Timeshift ....................... 20 3.8.4 Jump ......................21 Channel List ..................... 21 3.10 Program Guide (EPG) ..................21 3.11 Audio Change ....................21 3.12 Favorite Channels ....................

  • Page 5: Getting Started

    This manual will show you how to setup and operate the Linkbox 8000HD. You will find the operation of the Linkbox 8000HD to be simple and easy to handle. Any problems not addressed in this manual should be handles by qualified personnel.

  • Page 6: What's Inside The Box

    1.3 What’s inside the box Please confirm that the following items are enclosed in the box when you open it:  1- Remote Control  2- AAA Batteries  HDMI Cable NOTE: If any of the items are missing, please contact the vendor where this product was purchased.

  • Page 7: Control And Displays

    2. Control and Displays  Remote Control Function Power on/off Mute PAUSE Holds the picture or releases the pause INFO Shows channel information AUDIO Selects audio mode, Selects audio language LAST Returns to previous channel MENU Enter/Exit main menu screen EXIT Move to previous menu Page down...

  • Page 8: Front Panel

     Front Panel Name Fuction POWER Switches the unit between standy and on VOL ▼ Change volume up VOL ▲ Change volume down CH ▼ Change CH down CH ▲ Change CH up MENU Moves to MENU Select in menus DISPLAY Segment LED Display IR Receiver...

  • Page 9: Operation

    3. Operation 3.1 Initial Setup When the receiver is powered on for the first time, the main menu will appear. When first powering on the unit, please do the following: 1) Select the System Setup 2) Switch the language using the ◀ ▶ buttons.

  • Page 10: Motor Diseqc

    You can Edit, Add, or Delete entries in Select Tune LNB1 or LNB2, Satellite, the Satellite List LNB Type, transponder and DiSEqC(1.0 and 1.1). 3.2.2.1 Motor DiSEqC 3.2.2.1.1 DiSEqC 1.2 “Local Longitude”/”Local Latitude” is disabled for DiSEqC 1.2 3.2.2.1.2 Motor Setting ...

  • Page 11: Single Satellite Search

    3.2.2.1.3 USALS  Set the satellite’s longitude and local longitude / local latitude. USALS can move the dish automatically.  Local Longitude: Please input the Local Longitude using the numeric keys. Adjust East/West using the ◀ ▶ buttons  Local Latitude: Please input the Local Latitude using the numeric keys and adjust South/North using the ◀...

  • Page 12: Edit Channel

    3.3 Edit Channel 3.3.1 TV Channel List  Press [OK] key to preview the highlighted program in the right side window.  Use ◀ ▶ buttons to switch the “Program Group”.  Press [Menu] or [Exit] keys to go back to the “Edit Channel” menu. ...
  • Page 13  This will place a “move” marker on the right side of the highlighted channel.  Press the ▲▼ buttons to movethe channel to the desired position.  Press [OK] when finished. 3.3.1.5 Edit  Pressing the blue button will open the Edit menu 3.3.1.5.1 Sort ...

  • Page 14: Radio Channel List

    channel(s) will be deleted. 3.3.2 Radio Channel List Operation of the Radio Channel List is similar to operation of TV Channel List. Please refer to the “TV Channel List” section. 3.3.3 Delete Channel 3.3.3.1 Deleting a satellite channel  Use the ◀ ▶ buttons to navigate. ...

  • Page 15: Display Settings

    o Set the TV aspect mode (4:3 Letter Box, 16:9, Auto, 4:3 Pan & Scan) by using the ◀ ▶ buttons.  Video Output o Use the ◀ ▶ buttons to switch between CVBS and RGB.  Digital Audio Out o Set Digital Audio Out mode ( BS out, LPCM Out) 3.4.3 Display Settings Use the ◀...

  • Page 16: Parental Lock

     The current time information will be displayed on the first column. If the current time is incorrect, please modify the time information using the Time item.  Timer Mode: There are several modes for Timer setting available. These include Off, Once, Daily. ...

  • Page 17: Osd Setting

    3.4.7 OSD Setting  You can adjust the OSD timeout and transparency by using the ◀ ▶ buttons. 3.4.8 Favorite  Press [OK] to rename the favorite group. o Press the red button to switch to capital. o Press the green button to delete the character. o Press the yellow button to save the modification.

  • Page 18: Upgrade Via Usb

     Connect the master receiver to the TV and select transfer mode.  Power on the slave receiver.  Select “Start on the master receiver screen and press [OK] to start the upgrade.  When finished, press [Exit] button to save the parameters and exit WARNING! Do not disturb the data transfer by pressing any remote control buttons or disconnecting the RS232 cable, IF cable, RCA cable, etc.

  • Page 19: Record Manager

    3.7.1 Record Manager To play recorded content;  Press [Play] to preview the content.  Press [OK] to play the content in full screen.  Press [Pause] once to pause the content.  Pressing [Pause] repeatedly will utilize the step function. ...
  • Page 20  Use the [Yellow] button to select all files in the folder.  Use the [Blue] button to enter Edit Mode o EDIT MODE  [Red] button: Use to change selected filename or folder name  [Green] button: Use to copy selected file or folder into other folders or storage.

  • Page 21: Pvr

    3.7.4.3 Video Player Use the ▲▼ buttons to navigate through video files. A video preview will be displayed in the preview window. Press [OK] to select a file and start playback. 3.8 PVR 3.8.1 Recording While watching a channel, pressing the [REC] button will start recording for a set duration of 2 hours.

  • Page 22: Jump

    3.8.4 Jump  In the Jump menu, the user can choose between 30sec/1min/5min/10min/30min jump increments.  During playback of HDD recorded program, pressing [PREV]/[NEXT] buttons will skip backward or forward the increment set by the user. 3.9 Channel List Press [OK] during playback to open the channel list.

  • Page 23: Favorite Channels

    To change the audio mode (L-Left, R-Right, L/R-Stereo)  Press [Audio] and use the ◀▶ buttons to switch modes 3.12 Favorite Channels  Press the [FAV] button to recall a stored favorite channel.  Favorite Channels are programmed and stored using the Favorite Edit Menu.

  • Page 24: Specifications

    4. SPECIFICATIONS Satellite Tuner Input Connector F-type,IEC169-24 Frequency Range 950MHz to 2150MHz Input Level 65 dBm~-25 dBm LNB Power 14V/19V (400mA Max) Symbol Rate 1 to 45Msps.(SCPC,MCPC) DiSEqc Diseqc 1.2 & USALS Compatible Band Switch 22KHz tone Demodulation QPSK/8PSK/APSK Viterbi Decoding Rate 1/2,2/3,3/4,5/6,7/8 Reed Solomon Decoding FEC 204,188,t=8...
  • Page 25 Front Features PWR,CH Up/Down, Volume Up/Down, 7 Key Menu,Exit Display 4 Digit 7 Segment Display 1 Host USB2.0 Remote Control Type IR RCU Battery 2x1.5V AAA Type Power Supply Input Voltage AC 90-250V, 50/60Hz Type AC Plug Physical Specification Dimension (WxDxH) 260mm x 180mm x 45mm Weight 1.2Kg...

  • Page 26: Troubleshooting

    5. TROUBLESHOOTING If the unit is not functioning properly, use this guide to identify and troubleshoot some common causes. If your problem cannot be solved using this guide, please contact your vendor to resolve the issue. Problem Possible causes Remedy 1.
  • Page 27 LIMITED WARRANTY LinkTV Media warrants to the original purchaser that this product shall be free from defects in workmanship and material for two years from the date of original purchase. During this warrant period LinkTV Media will provide free of charge both parts and labor necessary to correct defects in workmanship or material.
