2 ERROR CORRECTION: V.42ANDMNP2,3,4.
3 DATA COMPRESSION: V.42bisANDMNP5.
4 ENHANCED "AT" COMMANDSET .
5 ASYNCHRONOUS COMMUNICATION
SPECIFICATION BAUD RATE:
(1)DTETOMODEMDATARATE: UP TO 300, 1200, 2400,
4800, 9600, 14400, 19200, 28800, 38400, 57600, 115200,
230400BPS
(2)LINEDATARA TE: NORMAL MODE: 300/1200/2400/4800/
9600/14400/16800/19200/21600/24000/26400/28800/
31200/33600 bps and 1200/75 bps, 56K download Upload.
6 EMI & SAFETY DESIGN STANDARD: Compliance
with FCC PART 15 and PART 68.
7 TEMPERATURE & HUMIDITY -TEMPERATURE
RANGE:
Transit: -40 Degree C to 70 Degree C. (Withstand
72 hrs of transit period)
Storage: -40 Degree C to 65 Degree C. (Withstand
6 months of storage)
Operating:0 Degree C to 40 Degree C.
-HUMIDITY:20-80%. (Non-Condensing Relative
Humidity)
8 DIALING CAP ABILITY-T ouch-Tone.
9 MODEM FEATURES:
1)Command buffer support 40 characters.
2)Auto dial and auto answer.
3)Connector to sound board for speaker
4)Wake up on ring.(option Function)
10 TESTANDDIAGNOSTICSFACILITIES
-Remote digital loop and remote digital loop self test.
-Analog loop and analog loop self test.
-Digital loop test.
Optional port replicator
Environment
Temperature
* Operating: 5(C~35(C
* Non-operating: -20(C~60(C
Humidity
* Operating: 30%~90% (non-condensing)
* Non-operating: 5%~95% (non-condensing)
Altitude
* Operating: -200~10000ft
* Non-operating: -200~30000ft
Shock
* Operating: 10G, 11ms
* Non-operating: 50G, 11ms
Vibration
* Operating: 10~27Hz, 0.01"
* Non-operating: 5~62Hz, 0.02"
Drop
* 900mm with packing
Acoustic Noise
* 35dB(max.) at 1 meter
ESD
* Follow IEC 801-2 standard level 3
* 0~8KV: no erro allowed
P .L.T.
* 1KV: no any error
A.2 Regulation
Safety:
* UL 1950, CSA, TÜV
EMI
* FCC class B, Part 15
* CE mark
MTTR
* 30 min.
Physical Dimension
* Dimension: 210mmx326mmx87.52mm (with base)
137.10mmx326mmx87.52mm
* Weight: 2.5 kg.
