Model Numbers: PT-18W-DDF-A, PT-20F-DDF-A,
PT-20S-DDF, PT-24O-DDF, PT-24-DDF, PT-24-DDF-F,
PT-30-DDF, PT-30P-DDF-A, PT-30P-DDF-AF
IMPORTANT: Read and understand all of the instructions in this manual before assembling,
starting, or servicing the fan. Improper use of this fan can cause serious injury. Keep this manual for
future reference.
For General Ventilating Use Only. Do Not Use To Exhaust Hazardous Or Explosive
CAUTION
Materials And Vapors. Never use the fan in spaces which contain products such as
gasoline, solvents, paint thinners, dust particles, volatile or airborne combustibles, or any unknown
chemicals.
This product meets and exceeds the requirements of OSHA 1910.212(a)(5), the standard which
regulates electric fan blade safety, and is certified under UL# E355088.
Please note the serial number of your fan, and write it on the back of this User's Manual for future reference.
668 Stony Hill Road #302 Yardley, PA 19067 USA Toll Free: (800) 641-6996
Fax: (215) 891-8461 • Web: www.protemp.us • Email: info@pinnacleint.com
READ AND SAVE THESE INSTRUCTIONS
© 2013, Pinnacle Products International, Inc.
User's Manual and
Operating Instructions
9500450290-13
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Protemp Protemp PT-18W-DDF-A
Summary of Contents for Protemp Protemp PT-18W-DDF-A
-
Page 1: Operating Instructions
Please note the serial number of your fan, and write it on the back of this User’s Manual for future reference. © 2013, Pinnacle Products International, Inc. 668 Stony Hill Road #302 Yardley, PA 19067 USA Toll Free: (800) 641-6996 Fax: (215) 891-8461 •... - Page 2 30” Pedestal Fan 18” Wall Fan PT-30P-DDF-A PT-18W-DDF-A PT-24-DDF PT-30P-DDF-AF PT-24-DDF-F 12-13 20” Floor Fan 24” Omni Fan PT-20F-DDF-A PT-24O-DDF 8-10 14-16 20” Shop Fan 30” Floor Fan PT-20S-DDF PT-30-DDF © 2013, Pinnacle Products International, Inc. HVF Air Circulator User’s Manual...
-
Page 3: Safety Information
Shock, Do Not Expose To Water from heat, oil, and sharp edges. Inspect cords Or Rain. This unit is designed for indoor use periodically and replace if damaged. only. © 2013, Pinnacle Products International, Inc. HVF Air Circulator User’s Manual... - Page 4 __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ © 2013, Pinnacle Products International, Inc. HVF Air Circulator User’s Manual...
-
Page 5: Exploded View
95-003-0606 Cord Bushing 95-026-0160 Pivot Washer 95-024-0300 Upper Bracket 95-061-0100 Swivel Spacer 95-050-0185 Rear Guard 95-032-0250 Pivot Screw 95-024-0310 Motor 95-030-0515 Capacitor 95-004-0215 Switch Holder 95-031-0300 Power Cord 95-026-0230 © 2013, Pinnacle Products International, Inc. HVF Air Circulator User’s Manual... - Page 6 * On Page 7 tioned against a flat surface will result in damage to the fan. Figure 3: Wall Mount Installation - Close Up Figure 2: Wall Mount Installation © 2013, Pinnacle Products International, Inc. HVF Air Circulator User’s Manual...
- Page 7 Main Circle Tube 95-024-0280 Swivel Spacer 95-050-0180 Top Washer 95-024-0290 Lower Support Frame 95-024-0245 Rear Guard 95-032-0260 Power Cord 95-026-0240 Motor 95-030-0525 Capacitor 95-004-0225 Switch Holder 95-031-0310 Wall Mount Kit 95-078-0100 © 2013, Pinnacle Products International, Inc. HVF Air Circulator User’s Manual...
- Page 8 3. Be Certain that the Safety Pin lines up with the groove * On Page 10 on the Connector Bracket (Item #4). (See Figure 6**) ** On Page 9 © 2013, Pinnacle Products International, Inc. HVF Air Circulator User’s Manual...
- Page 9 SOURCE 20” SHOP FAN CONTINUED - OPTIONAL CEILING MOUNT Figure 5: Figure 6: Optional Ceiling Mount Optional Ceiling Mount Figure 7: Figure 8: Optional Ceiling Mount Optional Ceiling Mount © 2013, Pinnacle Products International, Inc. HVF Air Circulator User’s Manual...
- Page 10 95-026-0180 Frame 95-001-0500 Switch Cover 95-031-0540 Tripod 95-040-0100 Rear Guard 95-032-0285 Wing Nut 95-075-0400 Motor 95-030-0525 Switch Holder 95-031-0335 Base Knob 95-015-0220 Ceiling Mount Kit 95-078-0300 Power Cord 95-026-0270 © 2013, Pinnacle Products International, Inc. HVF Air Circulator User’s Manual...
- Page 11 Barrel 95-001-0300 Pipe Frame L/R 95-009-0500 Handle 95-006-0210 Frame Bracket A 95-009-0510 Rear Guard 95-032-0270 Frame Bracket B 95-009-0520 Motor 95-030-0530 Wheel Bolt 95-008-0310 Switch Holder 95-031-0320 Wheel 95-008-0110 © 2013, Pinnacle Products International, Inc. HVF Air Circulator User’s Manual...
- Page 12 95-032-0275 Small Base 95-024-0500 Front Leg 95-009-0600 Small Base Cap 95-024-0510 Horizontal Adj. Knob 95-015-0150 Wheel 95-004-0155 Spacer 95-050-0200 Lower Mount 95-024-0325 Outer Ring Frame 95-024-0320 Logo Plate 95-043-0331 © 2013, Pinnacle Products International, Inc. HVF Air Circulator User’s Manual...
- Page 13 Wall Mount (Item #17*) Figure 12: Wall Mount installation Close Up Handle Arm (Item #20*) Wall Large Base (Item #23*) Wall Mount (Item #17*) Figure 13: Wall Mount installation © 2013, Pinnacle Products International, Inc. HVF Air Circulator User’s Manual...
- Page 14 10 Swivel Latch Pin 95-050-0131 22 Power Switch 95-025-0500 11 Frame Cap 95-011-0300 23 Rear Motor Cover 95-048-0100 12 Wheel 95-008-0165 24 Power Cord 95-026-0150 25 Guard Screw 95-033-0225 © 2013, Pinnacle Products International, Inc. HVF Air Circulator User’s Manual...
- Page 15 95-060-0100 Top Washer 95-060-0120 Nut for Ceiling Swivel Pin 95-060-0180 Lower Ceiling Bracket 95-060-0160 95-060-0125 Tapping Screw 5-15mm 95-060-0195 Upper Ceiling Bracket 95-060-0110 Ceiling Swivel Pin 95-060-0170 U-Bolt 95-060-0120 © 2013, Pinnacle Products International, Inc. HVF Air Circulator User’s Manual...
- Page 16 5. Repeat on other side of fan so there are two safety cables. Figure 16: Safety Cable Installation Figure 17: Safety Cable Installation - Close Up © 2013, Pinnacle Products International, Inc. HVF Air Circulator User’s Manual...
- Page 17 Rear Guard edge. Continue until all hooks are completely attached to the Rear Guard edge. NOTE: This model CAN NOT be wall mounted * On Page 18 Figure 19: Attaching Rear Guard to Motor © 2013, Pinnacle Products International, Inc. HVF Air Circulator User’s Manual...
- Page 18 Motor Assembly 95-030-0545 Tilt Adjustment Knob 95-015-0210 Rear Guard 95-032-0281 Height Adjust. Knob Nut 95-015-0215 Upper Support Pole 95-010-0305 Power Cord 95-026-0260 Pipe Ring 95-017-0215 Capacitor 95-004-0240 Pipe Support 95-017-0220 © 2013, Pinnacle Products International, Inc. HVF Air Circulator User’s Manual...
-
Page 19: Troubleshooting Guide
1. Fan is not on level ground Turn off fan, and move unit to smooth level surface. Excess Noise (vibration, squealing) 2. Guard is not secure Check guard screws to be sure all are tight. © 2013, Pinnacle Products International, Inc. HVF Air Circulator User’s Manual... - Page 20 DEFECTIVE. Register Online at: www.protemp.us/Product_Registration.php ALWAYS BE SURE TO SPECIFY MODEL NUMBER AND SERIAL NUMBER WHEN MAKING ANY CLAIM WITH PINNACLE PRODUCTS INTERNATIONAL, INC. FOR YOUR CONVENIENCE USE THE SPACE PROVIDED BELOW TO LIST THIS INFORMATION: Model #: ____________________ Serial #: ______________________ Date of Purchase: _________________ ©...
