Installation and Operation Manual DVD-9101-201-x Serial Digital Video Disc Player Document # 540339 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.decraneaerospace.com... - Page 2 23-24 INFORMATION NOTICE: Despite any other copyright notice, this document and information disclosed herein contains confidential, proprietary designs owned by DeCrane Aerospace Audio International. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of DeCrane Aerospace Audio International.
-
Page 3: Table Of Contents
DeCrane Aerospace Audio International DVD-9101-201-x Installation & Operation Manual Table of Contents Section Description Page General Information....... . -
Page 4: General Information
This manual contains information for the proper installation and operation of DeCrane Aerospace Audio International’s (DAAI) Digital Video Disc Player, Model # DVD-9101-201-x. The “-x” suffix in the model number designates the type of connector utilized; “-1” = Positronic and “-2” = D-Subminiature. -
Page 5: Optional Equipment
Menu and Set-Up. While the DVD-9101-201-x is a complete and fully functional standalone DVD Player, it is strongly recommended that a remote control device also be employed for thorough enjoyment of the unit. -
Page 6: Display
Media and Format Compatibilities DVD-9101-201-x is compatible with standard commercial audio CD and video DVD. Note that since DVD disc format standards are constantly evolving, some DVD discs may not play properly or may cause the unit to malfunction. -
Page 7: Installation
• Length of cable runs • Location of other aircraft systems (oxygen delivery) 3.1.2 The DVD-9101-201-x shall be installed to conform to the standards designated by the customer, installing agency, and existing conditions as to the unit location and type of installation. -
Page 8: Unpacking And Inspection
3.8 are the responsibility of the installing agency. Unpacking and Inspection 3.2.1 Carefully open the packaging and remove the DVD-9101-201-x. Verify that all components have been included in the package per the packing list. Inspect the unit for shipping damage. -
Page 9: Wiring Requirements
DeCrane Aerospace Audio International DVD-9101-201-x Installation & Operation Manual 3.3.9 DO NOT expose unit to sun or bright light. 3.3.10 The chassis material and structural design of this unit is such that the unit is not capable of containing fire within the unit. This unit does not provide for waterproof operation. -
Page 10: Physical Characteristics
22 AWG (minimum) and shall be in accordance with NEMA WC 27500. 3.4.6 RS-485 Data Bus Wiring The DVD-9101-201-x is designed to interface with other DeCrane Aerospace Audio International equipment via DAAI’s proprietary RS-485 serial data bus. The data bus shall be implemented using a twisted shielded pair cable in accordance with NEMA WC 27500. -
Page 11: Clearance And Separation Requirements
-4° to +176° F Storage Temperature -20° to +80° C 3.7.2 The DVD-9101-201-x utilizes one (1) 25-pin connector for electrical connections, which provides power, data bus control, infrared input, and four (4) address strapping pins and a strapping common for unit identification on the RS-485 data bus and for IR control. -
Page 12: Mating Connector Information
DeCrane Aerospace Audio International DVD-9101-201-x Installation & Operation Manual Mating Connector Information Model # Mating Connector CBC25W3F140000 or equivalent DVD-9101-201-1 (Positronic Industries) Size 8 Contacts: 110236 (x3) (PIC Wire & Cable) 3025W3SXK99A1OX Female Plug w/ male jackscrews or equivalent DVD-9101-201-2 (American Conec Corporation) Size 8 Contacts: 110236 (x3) (PIC Wire &... -
Page 13: 3.10 Post Installation Test
DeCrane Aerospace Audio International DVD-9101-201-x Installation & Operation Manual 3.10 Post Installation Test This section is designed to assist the user in determining whether the DVD Player has been properly installed. First, before applying power, ensure the unit is connected correctly, especially concerning Power and Ground wiring. -
Page 14: Operation
If sound cannot be immediately heard through speakers or headphones, it may be that the volume is too low and should be increased appropriately. Note that there are no audio controls on the DVD-9101-201-x. Any desired adjustments must be performed through other audio distribution devices. -
Page 15: Control Functions
DeCrane Aerospace Audio International DVD-9101-201-x Installation & Operation Manual Control Functions: EJECT BUTTON The EJECT Button allows the user to eject the DVD. Pressing the EJECT Button will allow the user to gently pull the DVD out of the mechanism. - Page 16 DeCrane Aerospace Audio International DVD-9101-201-x Installation & Operation Manual Pressing the REVERSE Button a third time will place the DVD Player in FAST REVERSE x8 Mode with no audio output. Pressing the REVERSE Button a fourth time will place the DVD Player in FAST REVERSE x32 Mode with no audio output.
-
Page 17: Pause Button
DeCrane Aerospace Audio International DVD-9101-201-x Installation & Operation Manual PAUSE BUTTON DVD VIDEO – PAUSE: Press the PAUSE Button once to place the DVD Player in PAUSE Mode. Several functions become available when the DVD Player is in PAUSE Mode: The user can enter SLOW REVERSE Mode by pressing the REVERSE Button. -
Page 18: Supported Rs-485 And Ir Commands
DeCrane Aerospace Audio International DVD-9101-201-x Installation & Operation Manual Supported RS-485 and IR Commands EJECT This button functions exactly as the front panel EJECT Button: The EJECT Button allows the user to eject the DVD. Pressing the EJECT Button will allow the user to gently pull the DVD out of the mechanism. - Page 19 DeCrane Aerospace Audio International DVD-9101-201-x Installation & Operation Manual PREFERENCES TV DISPLAY: The user can choose to display the video they are watching in one of the following aspect ratios: WIDE (16:9) – Displays video using a 16:9 aspect ratio recommended for widescreen TVs.
- Page 20 DeCrane Aerospace Audio International DVD-9101-201-x Installation & Operation Manual AUDIO LANGUAGE SELECT This option allows the user to change the preferred AUDIO LANGUAGE if available on the DVD. SEARCH PREV (REW) During movie or audio play, press to “scan” backward through media. Material will scan while the button is held, and, depending on media, video input will be available.
-
Page 21: Instructions For Continued Airworthiness
REPEAT CHAPTER Mode. REPEAT TITLE: The DVD-9101-201-x will repeat the current title until the user exits REPEAT TITLE Mode. REPEAT DISC: The DVD-9101-201-x will repeat the disc until the user exits REPEAT DISC Mode. A-B REPEAT Use to continuously repeat all material between two points in time (designated A and B). - Page 22 DeCrane Aerospace Audio International DVD-9101-201-x Installation & Operation Manual • Verify +28 VDC power is applied to the proper pins on the unit. Use a voltmeter to verify correct level. • Reset by removing power from the unit for at least one (1) minute and reapply power.
-
Page 23: Troubleshooting Chart
6.83" x 6.00" x 2.09" (l x w x h) 17.35 cm x 15.24 cm x 5.30 cm * Dimensions provided are for the base unit, DVD-9101-201-x. They do not include cover bezel information. Document # 540339, Rev B, 06/2009... -
Page 24: Reference Drawings
DeCrane Aerospace Audio International DVD-9101-201-x Installation & Operation Manual Reference Drawings The following diagrams show the unit dimensions, mounting locations, and connector locations for the DVD-9101-201-x. Cover bezel not depicted. Document # 540339, Rev B, 06/2009 Page 23 of 25... - Page 25 DeCrane Aerospace Audio International DVD-9101-201-x Installation & Operation Manual Document # 540339, Rev B, 06/2009 Page 24 of 25...
-
Page 26: Environmental Qualification Data
DeCrane Aerospace Audio International DVD-9101-201-x Installation & Operation Manual Environmental Qualification Data Manufacturer’s Specification and/or applicable Specification: AI Document 620370 D-9460 ETL Revision & Change Number of DO-160: E Date Tested: 3/16/2007 Document # 540339, Rev B, 06/2009 Page 25 of 25...
