Page 1: Installation And Operation
Installation and Operation Manual DVD-5x2-01-x Dual Digital Video Disc Player Document # 540356 (Model DVD-502-01-x shown) 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.decraneaerospace.com... - Page 2 DeCrane Aerospace Audio International. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of DeCrane Aerospace Audio International. Document # 540356, Rev C, 12/2008...
-
Page 3: Table Of Contents
DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Table of Contents Section Description Page General Information....... . -
Page 4: General Information
Introduction This manual contains information for the proper installation and operation of DeCrane Aerospace Audio International’s Dual Digital Video Disc Player, Model # DVD-5x2-01-x. The “x” in the “-5x2” designates the differences between units. The DVD-502-01-x is a base dual DVD unit. -
Page 5: Optional Equipment
Optional Equipment The DVD-5x2-01-x can be optionally controlled by infrared remote or DeCrane Aerospace Audio International’s touch screen panels, and it is important to remember that some remote controls possess functions not duplicated by the Unit’s front panel buttons, such as Menu and Set-Up. -
Page 6: Operating Parameters
DVDs. Note that since DVD disc format standards are constantly evolving, some DVD and CD discs may not play properly or may cause the unit to malfunction. DeCrane Aerospace Audio International does not guarantee the DVD-5x2-01-x is compatible with all media or formats. -
Page 7: Typical System Block Diagram
Typical System Block Diagram 2.4.1 This unit is fully compatible with DeCrane Aerospace Audio International’s proprietary RS-485 digital data bus system. It can be configured for IR remote control utilizing DeCrane Aerospace Audio International’s remote control unit AI-RC5-7xxxx and IFR-485. -
Page 8: Installation
Inspect the unit for shipping damage. 3.2.2 If damage has occurred during shipping, a claim should be filed with DeCrane Aerospace Audio International WITHIN 24 hours and a Return Request Authorization Number shall be obtained from DeCrane Aerospace Audio International by contacting the Repair Department at 501-801-8101. -
Page 9: Cautions & Warnings
DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual cover of this manual for address. If no return is necessary, retain the packing list and the packing materials for storage. 3.2.3 Return only the core unit for replacement or service. Remove and retain for reuse the bezel, installed rails and pigtail (if used) as well as any mounting hardware. -
Page 10: Wiring Requirements
3.4.3 Video Lines Composite video connections shall be shielded coaxial cable in accordance with the military specifications of M17/94-RG179. 3.4.4 DeCrane Aerospace Audio International’s Proprietary RS-485 Data Bus 3.4.4.1 The DVD-5x2-01-x is designed to interface with other DeCrane Aerospace Audio International equipment via DeCrane Aerospace Audio International’s proprietary RS-... -
Page 11: Physical Characteristics
650007 for RS-485 Serial Data Bus design architecture. 3.4.5 Analog Audio Lines DeCrane Aerospace Audio International recommends that all audio wire connections be twisted shielded cable with the shield properly grounded at the source (ideal practice). If shield cannot be grounded at the source, then ground at the load end with opposite end floating. -
Page 12: Clearance And Separation Requirements
DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual and structures except the mounting surface for which the unit should be in direct contact. 3.5.4 The cover bezel snaps easily on the DVD Player’s faceplate without the need of special tools. The cover bezel does not require mounting bracket attachments. - Page 13 DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual 3.7.3 Infrared input provides a ground reference connection (-). For optimum infrared signal transmission, this ground reference should connect to the IFR-9A or IFR-485 module being utilized. 3.7.4 The three (3) address strap pins are able to be connected to the strap common.
-
Page 14: Mating Connector Information
DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Mating Connector Information 3.8.1 Mating Connector assignment as follows: J1 and J2 Connectors Model # Unit Connector Mating Connector RD15M10JV30 or RD15F10JVL0 DVD-502-01-1 equivalent (Positronic Industries) (Positronic Industries) DAMA-15P or equivalent... -
Page 15: Pinout Assignments And Descriptions
DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Pinout Assignment and Descriptions DVD-5x2-01-x J1 and J2 Pinouts Pin # Description + 28 VDC Power Input Ground R+ Audio Output R- Audio Output L+ Audio Output L- Audio Output RS485 Data Bus A (HI) -
Page 16: Operation
DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual if the DVD has a sticker, it should be loaded with the sticker facing up! Gently push the DVD into the slot. The disc should begin loading, which will be indicated on the monitor screen. -
Page 17: Front Panel Control Functions
DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual From left to right, the buttons are: CHANGE REVERSE FORWARD EJECT STOP PAUSE PLAY Front Panel Control Functions: CHANGE BUTTON The Change Button causes the front panel to alternate control between DVD 1 and DVD 2. - Page 18 DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual functionally dependent on the current mode of the DVD Player, and the media type played. Pressing and holding the Forward Button once will place the DVD Player in Fast Forward x8 Mode with no audio output. Play will resume when the Forward Button is released.
-
Page 19: Supported Rs-485 And Ir Commands
DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual The Play Button can be used to access the DVD Root Menu at any time, by pressing and holding the Play button. The Play Button is active when the DVD Player is powered on and not in Standby Mode. - Page 20 DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual • To navigate Up hold the Reverse Button, until the desired selection is highlighted. • To navigate Down hold the Forward Button, until the desired selection is highlighted. • To turn items On or Off, select the options then hit Play or Forward.
-
Page 21: Setup Menu Navigation
DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Setup Menu Navigation Main Page Menu MAIN PAGE General Speaker Audio Play Mode Preferences Enter General Menu GENERAL Angle Mark OSD Language Enter Document # 540356, Rev C, 12/2008 Page 20 of 38... - Page 22 DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Angle Mark Selections The ANGLE Mark allows the User to change angles on DVD Videos that offer angle selection. GENERAL Angle Mark OSD Language Enter OSD Language Selections The OSD Language allows the user to change the language displayed in the Setup Menu.
- Page 23 DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Speaker Setup Menu MAIN PAGE General Speaker Audio Play Mode Preferences Enter Downmix Speaker Setup The Lt/Rt mode is not supported by the DVD-5x2-01-x and must not be selected. The Stereo mode must be made active for the DVD-5x2-01-x. Correct audio playback from the DVD-5x2-01-x may not occur if this mode is not selected.
- Page 24 DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Bass Speaker Setup SPEAKER SETUP SubWoofer Center Delay Rear Delay Test Tone Bass Enter Audio Setup Menu MAIN PAGE General Speaker Speaker Audio Audio Play Mode Preferences Enter OP Mode Audio Setup The Line Out mode is the recommended setting.
- Page 25 DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Compression Audio Setup The Compression Audio will compress or expand the dynamic range of the signal depending on its content. This can be adjusted to the user’s preference. AUDIO SETUP Full...
- Page 26 DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Play Mode Selection Menu Shuffle mode enables the playable tracks or chapters to be played in a random order. Repeat mode allows selection of chapter or title to repeat. MAIN PAGE...
- Page 27 DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Preferences Menu MAIN PAGE General Speaker Audio Play Mode Preferences Enter TV Display Preferences The User can choose to display the video they are watching in Normal /Pan Scan, Normal/Letter Box, or Wide Screen.
- Page 28 DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Audio Preferences This option allows the User to change the preferred audio language if available on the DVD. There are nine (9) language selections. PREFERENCES TV Display English Audio Spanish Subtitle...
- Page 29 DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Subtitle Preferences This option allows the User to change the preferred displayed subtitle if available on the DVD. There are nine (9) language selections. PREFERENCES TV Display English Audio Spanish Subtitle...
- Page 30 DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Disc Menu Preferences This option allows the User to change the preferred DVD menu language if available on the DVD. There are nine (9) language selections. PREFERENCES TV Display English Audio...
- Page 31 DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Locale Preferences This option allows the User to specify the end user market. There are seven (7) language selections. PREFERENCES Locale China Parental France Defaults Hong Kong Password Japan System Info...
- Page 32 DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Parental Preferences PREFERENCES Locale Parental 6 PG-R Defaults 7 NC-17 Password 8 Adult System Info No Parental Password Enter Note: Default password “3308” needs to be entered before navigation of Parental Preferences is allowed.
-
Page 33: Troubleshooting
DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual System Info Preferences PREFERENCES Baseline: DVDV4a Locale Date: 12.05.06 Parental MPEG Sw: i06.19.00 Boot Sw: b05.47.00 Defaults Engine Sw: E1.10.25 Password DataPath Sw: V11.23 System Info EXIT Enter Troubleshooting In addition to the cautions and warnings provided in Section 3.3, the following guidelines and instructions will help ensure proper functionality and performance from the DVD-5x2-01-x. -
Page 34: Troubleshooting Chart
DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual status to see if it is now functioning properly. Once you have removed the piece or pieces of offending equipment, disconnect power and then reconnect everything but the suspect component, reapply power and test the functionality of the unit. -
Page 35: Instructions For Continued Airworthiness
DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Instructions for Continued Airworthiness Other than a routine cleaning (instructions listed above in Section 5.1), no periodic scheduled maintenance or calibration is required for continued airworthiness of the DVD-5x2-01-x. If the unit fails to perform to specifications, it must be removed and serviced by a qualified service facility. - Page 36 DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Document # 540356, Rev C, 12/2008 Page 35 of 38...
- Page 37 DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Dimensions and Connections: DVD-512-01-x The following diagrams show the unit dimensions, mounting locations, and connector locations for the DVD-512-01-x. Note: This measurement is of the front cover bezel. Document # 540356, Rev C, 12/2008...
-
Page 38: Dimensions And Connections: Dvd-502-01-X
DeCrane Aerospace Audio International DVD-5x2-01-x Installation & Operation Manual Document # 540356, Rev C, 12/2008 Page 37 of 38...
