Telular Wi PATH SX7 EVDO Quick Start Manual

Hide thumbs Also See for Wi PATH SX7 EVDO:
1
2
3
4
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual

Unpack the Box

Your Wi PATH
TM
SX7
2 TNC Antennas
Power Supply Adapter
Power Line Cord
Rechargeable Battery Pack
Ethernet Cable
(RJ-45)*
USB
Cable*
RJ-11 Phone Cable
(SX7T
only)*
Quick Start Guide (this
CD (contains User Guide and support
Make sure you have everything listed before continuing. If any items are missing or
damaged, please contact your authorized distributor for assistance.

Set Up the SX7

1. Install the Rechargeable Battery Pack into the battery compartment.
Remove the battery compartment door, insert the battery connector into
the battery terminal, arrange the battery pack in the compartment, and
replace the battery compartment door. (As pictured below, the rounded
corner of the battery connector will be on the left side.)
Battery
Compartment
(open)
01/02/08
Wi PATH
TM
Quick Start Guide
TNC Antennas
guide)*
Battery Terminal
SX7 Bottom View
SX7 EVDO
Power Line Cord
materials)*
Rechargeable
Battery Pack
Wi PATH
SX7
TM
Rechargeable
Battery Pack
Power Supply Adapter
*
(
– not pictured)
Battery
Connector
Part Number: 56038402

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wi PATH SX7 EVDO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Telular Wi PATH SX7 EVDO

Summary of Contents for Telular Wi PATH SX7 EVDO

  • Page 1: Quick Start Guide

    Wi PATH SX7 EVDO Quick Start Guide Unpack the Box Your Wi PATH Wi PATH 2 TNC Antennas Power Supply Adapter Power Line Cord Rechargeable Battery Pack Rechargeable Ethernet Cable (RJ-45)* Battery Pack Cable* RJ-11 Phone Cable (SX7T only)* TNC Antennas Power Line Cord Power Supply Adapter Quick Start Guide (this...
  • Page 2 2. Connect and hand-tighten the TNC Antennas. TNC Antennas Once they are installed, arrange the antennas so they point upward (vertical orientation). Power 3. Connect the Power Supply Adapter to Input the unit’s Power Input and connect the Power Line Cord to the Power Supply Adapter.
  • Page 3 Password (“1234”). The Telular Device Manager will start and display the Home screen. Bookmark the Telular Device Manager access page ( http://192.168.1.1 ). 2. From the Home screen, click Activation (1) and wait 5–10 minutes to see if your unit will auto-register iteself on the wireless network. If the Activation Status field (2) displays ACTIVE, your SX7 is ready for use.
  • Page 4 Set Up a Wireless WAN Data Connection 1. From any page in the Telular Device Manager (see previous step 1), click Setup (1) > Wireless WAN (2). 2. If required by your wireless service provider, enter your Username (3a) and Password (3b).
