Notes on This Manual Keep these instructions with your computer at all times. The proper setup, use and care can help extend the life of your computer. In the event that you transfer ownership of this computer, please provide these instructions to the new owner. This manual is divided into sections to help you find the information you require.
Page 3
Quality Medion has selected the components in this computer for their high level of functionality, ease of use, safety and reliability. Through balanced hardware and software design we are able to provide you with an innovative personal computer useful for applications relating to both work and leisure.
Table of Contents Safety and Maintenance ................ 1 Safety Instructions ..................3 Data Security ....................4 Setup Location .................... 4 Ambient Temperature................. 5 Working in Comfort ..................6 Connecting ....................7 Power Supply ..................7 ...
Page 5
Display ......................34 Opening and Closing the Display ............. 34 Screen Resolution ..................34 Appearance and Personalisation ............... 35 Connecting an External Monitor ............... 36 Duplicate the Desktop ................. 38 Extend the Desktop ................38 ...
Page 6
Windows® 7 - User Account Control ............ 64 Windows® 7 – Control Panel ............... 65 Windows Media Center ................66 Installation of Software ................69 How to Install your Software ............... 69 Software Uninstallation ............... 70 ...
Chapter 1 Safety and Maintenance Subject Page Safety Instructions ............. 3 Data Security ..............3 Setup Location ..............4 Ambient Temperature ............5 Working in Comfort ............6 Connecting ................. 7 Information about the Regulatory Compliance according to R&TTE ............9 Touchpad ................
Safety Instructions Please follow the instructions in this section for the safe operation of your notebook: Do not allow small children to play unattended with electrical equipment.. Keep the packing materials, such as plastic away from children. The danger of suffocation could arise in the case of misuse.
Data Security Attention! Every time you update your data make back-up copies on an external storage medium. The supplier does not assume liability for data loss or damage to data storage units, and no claims can be accepted for damages resulting from the loss of data or consequential losses.
Ambient Temperature The notebook is most reliably operated at an ambient temperature between +41° F (5° C) and +95° F (35° C) and at a relative humidity between 20% and 80% (without condensation). When powered off, the notebook can be stored at temperatures between +32°...
Working in Comfort Sitting in one position for long periods can be uncomfortable. To minimise the potential for physical discomfort or injury, it’s important that you maintain proper posture. Back – While sitting at your work station, make sure your back is supported by the chair’s backrest in an upright position or angled slightly backwards.
Connecting Pay attention to the following information in order to connect your notebook correctly: Power Supply Do not open the power adapter housing. When the housing is open there is a danger of severe electric shock. It contains no user-serviceable parts. ...
Cabling Arrange cables so no one can walk on or trip over them. Do not place objects on any of the cables. Do not allow any large forces to be exerted on the plug-in connections, from the side, for example.
The company declares herewith that these devices are in agreement with the fundamental requirements and the other relevant terms of the 1999/5/EG Guideline. Complete declarations of conformity are available under www.medion.com/conformity. Touchpad ...
“Charging the Battery” on page 31 for instructions on checking the battery level. Only change the battery when the unit is switched off. Batteries are classified as special waste and should always be disposed of properly. Contact the MEDION Help Desk for more details. Safety Instructions...
Chapter 2 Views & Handling Subject Page Included with Your Notebook ..........13 Views .................. 14 Open Notebook ............14 Front View ..............15 Left Side ................ 15 Right Side ..............16 Device Indicators ............17 Getting Started ..............18 How to start ..............
Included with Your Notebook Please check that the contents are complete and notify us within 7 days of purchase if any of the following components are missing: Notebook Battery Power adapter with connection cable OEM version of operating system ...
Right Side - USB Port 2.0 ................( p. 58) - Microphone port* ..............( p. 51) - Audio Out* / Digital Audio Out (S/P-DIF, optical) ........( p. 51) - Multimedia Card Reader ............( p. 56) - Optical Drive ................. ( p. 45) - Disc Eject Button ..............
Device Indicators LED's indicate the power and operating system states of the notebook. The meaning of each LED is: Power Indicator This LED lights blue, when the notebook is turned on. Capital Lock This LED lights when CAPS-Lock has been activated.
Getting Started Before you get started using your notebook, first take a few moments to read the important section on Safety. This notebook comes with software fully pre-installed. You do not have to install software from any of the discs supplied. How to Start: Step 1 ...
Page 26
Connect the supplied power adapter to the notebook at the notebook power socket (11) (). Connect the power adapter () via a power cord to a free AC power outlet (). Push the display latch to the right with your thumb and then open the display to the desired position () with your thumb and index finger.
Page 27
Please ensure that the battery is inserted and the power adapter is connected when operating the notebook for the first time. If you fail to do this, Windows® 7 will not be able to calculate the performance index correctly. Note The initial installation may take up to 30 minutes to complete.
Step 2 The greeting procedure will guide you through a series of dialogue boxes. The information in each dialogue box will explain the steps that need to be taken. Should you have any questions just click on License Agreement The greeting procedure also displays the license agreement.
Short Description of the Windows® Desktop Start Button Clicking the Start button brings up a menu where you can access help, software programs, files, and settings All Programs All of the software programs installed on your notebook are ordinarily listed here. Click All Programs to reveal an extensive menu.
Page 30
Control Panel You can use the icons in the Control Panel to change the appearance and functionality of Windows®7. These icons represent options for configuring your notebook. You should, however, consult “Help and Support“ on the potential effects of certain changes. ...
Chapter 3 Main Components Subject Page Power Supply ..............27 Display ................34 Data Entry ................39 The Hard Drive..............43 The Optical Drive ..............45 The Sound Card ..............49 The Network ............... 53 The Multimedia Card Reader ..........56 Webcam ................
Power Supply On/Off Button Power on or off your notebook by pressing the on/off button briefly. The power indicator will inform you about the operational status of the notebook. The notebook will always be switched off if the main switch is pressed for more than 4 seconds.
Power Adapter Your notebook is supplied with a universal AC power adapter, which automatically adjusts to the available power source. The following levels are supported: AC 100-240V~/ 50-60 Hz. Please follow the power supply safety instructions found on page 3. The power adapter is connected via a power cord to an power outlet.
Battery Operation Note Please charge and discharge the new battery completely two to three times in succession. Only then will it achieve its full performance level! Batteries store electrical energy in their cells and then deliver it when needed. The useful life and performance of your battery will depend on careful handling. The battery should be completely discharged before a charging process and completely charged again in order to optimise its useful life and its performance.
Removing the Battery Push the Safety Lock () to the ‘Unlock’ position, push and hold die eject button ( in order to remove the battery pack, then slide the battery out of the compartment (). Warning! Do not remove the battery while the notebook is running on battery power, this will very likely cause data loss.
Charging the Battery The battery is charged via the power adapter. If the power adapter is connected, it charges the battery automatically, no matter if the notebook is turned on or off. If the notebook is switched on, the charging process takes a significantly longer time. Note The charging process will be interrupted if the temperature or the voltage of the battery is too high.
Checking the Battery Level In order to check the current level of the battery, move the cursor over the power symbol in the taskbar. The symbol of a battery is displayed during battery operation. You will receive additional information about settings if you double click on this symbol. Note If you ignore the warning signal when the battery level is low, your notebook goes into hibernate mode.
Power Management Your notebook offers automatic and modifiable power saving functions that you can use to maximise battery life and reduce overall operating costs. The power saving modes are known as sleep mode and hibernate mode. Sleep Mode When in sleep mode, the contents of the RAM of your notebook are preserved while practically all other components of your notebook are shut down, reducing your power consumption to a minimum.
Display Opening and Closing the Display The display is locked by means of a special construction of the display hinge so that an additional lock is not necessary. 1. To open, lift the display with your thumb and index finger and position it as desired.
Appearance and Personalisation This program offers you the possibility of adjusting the presentation on your display. This includes the background image, the screensaver, Active Desktop (web) and additional settings of your display and your graphics card, for example. The program can be started in the following way: ...
Connecting an External Monitor The notebook has a VGA port (13) for connecting an external monitor. 1. Shut down your notebook. 2. Connect the video signal cable of the external monitor to the VGA port of the notebook (13). Alternatively, you will be able to use the digital HDMI (High Definition Multimedia Interface) connection (15) for the transmission of image and sound signals, provided that your output device (a monitor or LCD TV) has a corresponding input.
Page 44
The external screen will be determined after the operating system has been loaded. Several possibilities will be available to you. You will call them up as follows: 1. A right click on the display. 2. Select the Screen Resolution option in the selection window. 3.
Duplicate the Desktop This Mode duplicates the display of the notebook on an external monitor. Information The same screen resolution must have been set on both devices in the case of this mode. Extend the Desktop An empty Desktop will be shown on the second (external) monitor in this mode. Windows from the first screen can be pushed to the second screen and vice versa.
Data Entry The Keyboard By dual assignment of certain keys you have the same range of functions available to you as with a normal Windows® keyboard. Some functions are input using the Fn key, which is normal on notebook computers. Notebook-Specific Key Combinations Combination Description...
Page 47
Combination Description WLAN Fn + F7 Enables or disables the wireless LAN function. Webcam Fn + F9 Enables or disables the webcam. Fn + Increases the volume. Fn + Decreases the volume. Fn + Enhances screen brightness. Fn + ...
Touchpad The touchpad is positioned in front of the keyboard. The mouse pointer (cursor) follows the direction determined on the touchpad by the movement of your finger in the normal mode. Caution! Do not use a ball-point pen or other object on the touchpad as this could damage or cause a malfunction of your touchpad.
Two-Finger Control Your touchpad supports a two-finger control which can be applied to customized functions. The controls and their functions are described as follows: Illustration Gesture Function Zoom out object / Expand / Narrow Zoom in object Rotation Counter clock-wise rotate object Flick from the left to the right/ Forward / Backward Flick from the right to the left...
The Hard Drive The hard drive is the main storage medium combining large storage capacity and rapid data access. The hard drive contains the operating system of the computer, other application programs and backup files. These programs and files are pre-installed on your notebook, so you may note that some of the space on your hard drive is already taken.
Important Directories In the following we have listed the most important directories and described their content. Attention! Do not delete or modify these directories or their contents since data could be lost or the functionality of the system could be at risk. The master directory of drive C: includes important files required to start Windows®.
The Optical Drive Loading a Disc Unlike optical drives of desktop PC’s optical drives of notebooks retain discs with the help of a locking mechanism. When inserting the disc, you should take care to push the disc right onto the locking mechanism so that it can lock in position.
Page 53
1. Press the eject button at the optical drive to open the tray. 2. Remove the disc from its case without touching the unprinted side if possible. 3. Place the disc on the tray so that it lays flat with the label facing upward and gently push the tray in to close it.
Emergency Ejection of a Blocked Disc If the tray fails to open automatically, the tray can be opened manually provided there is an opening for emergency ejection. Restart your notebook and if the tray is still locked proceed as follows: 1.
Subjects Concerning the CD/DVD-Rewriter This Section only relates to devices that have been supplied with a CD-RW, a combination drive or a DVD-RW drive. First of all, you receive information on the so-called blank discs. Recordable/Rewriteable Discs Normal Discs are pressed from a digital, glass master and then sealed. In the case of blank disc, the information is burnt onto the disc with the laser of the Rewriter.
The Sound Card Your notebook has an integrated stereo sound card (on-board) with 16-bit and 3D spatial sound effects (3D). The sound card is compatible with the industry standard Sound Blaster and Microsoft Sound System Version 2.0. This guarantees optimal support for all popular programs and games.
External Audio Ports Your notebook has a loudspeaker so you can always playback sounds without additional equipment. The use of the external connections gives you the opportunity to connect your notebook to external audio devices. Caution! The use of headphones/earphones with a high volume can lead to lasting damage to your hearing.
Page 58
Microphone In For recording via an external microphone. (17) For sound reproduction with an external surround Audio Out / decoder via an optical cable (available separately at Digital a specialist shop). Audio Out For sound reproduction via external stereo (S/P-DIF optical) equipment such as loudspeakers (active) or (18) headphones.
Setting the Recording Level To set the desired recording level, go to System control Sound Recording and select the source. The button Digital Mic is intended for the integrated microphone. If you want to use an external microphone or another recording source (Line In), select the relevant option. ®...
The Network What is a Network? A network means connecting your notebook to one or several other computers. Users can transfer data between computers and share resources such as printers and hard drive drives. Here are some practical examples: You can exchange E-mail and manage appointments in an office.
Wireless LAN Wireless LAN is an optional feature. This function allows you to create a wireless network link with an access point or directly with another wireless-enabled notebook or PC. Using the Quick launch key combination Fn+F7 you can enable or disable the wireless LAN function.
Conditions An access point is a wireless transmitter that communicates with your notebook and controls access to the network connection (e.g., a home network or a broadband connection such as DSL). Wireless access points are often found in offices, airports, universities or Internet cafés.
The Multimedia Card Reader Memory cards are media that are being used for a variety of purposes, especially in digital photography. The form and capacity of a memory card can vary according to the manufacturer. Your notebook supports the following formats: ...
Webcam (optional) Various services like calling online can be used with the built in webcam. Using the Quick launch key combination Fn+F9 you can enable or disable the webcam. Actual Example Using Windows Messenger 1. Start Windows Messenger and create a user account if you do not already have one.
Universal Serial Bus (USB) Port On the USB it is possible to connect up to 127 devices which correspond to the USB standard (1.1 and 2.0 supported). The data transfer speed is 1.5 Mbit/s or 12 Mbit/s, depending on the device connected. USB 2.0 can reach up to 480 Mbit/s 3.0 USB connections are completely backwards compatible with 2.0 and 1.1 USB.
Securing the Notebook Your new notebook has software and hardware solutions preventing unauthorized access. Startup Password You can protect your notebook against unauthorized use by setting a start-up password. You will then have to enter a password during the notebooks start-up. The password will be set up in the BIOS.
Software This section concerns itself with software. We make a distinction between the operating system, the software (application program), Windows activation, BIOS and the security package BullGuard, which is delivered with the device. Getting to Know Windows® 7 Windows® 7 is the new operating system and successor to Vista®. Windows®...
Improved Desktop Windows® 7 simplifies working with the windows on the Desktop. This provides you with more intuitive possibilities for opening and closing, as well as for changing the size and for rearranging. Windows® 7 makes the performance of everyday tasks even simpler. For example, the Snaps function makes it easier than ever to compare two open windows.
Homegroup With homegroups, a new function of Windows® 7, the linking of home computers is really simple. A home network group is created automatically, for example, when you link the first notebook under Windows® 7 with the home network. The addition of additional notebooks or PCs with Windows®...
Windows® 7 – Getting Started Learn everything you need to know about the features of the notebook. It is the aim of this feature to enable both beginners and experienced users to make additional setting for the optimal use of Windows®7 after first bringing the Notebook into operation.
Getting Started has been subdivided into many small groups of subjects, so that the user will have the possibility of adjusting the content optimally to his or her knowledge. There are some of the links in the following: Go online to find out what’s new in Windows®7 ...
Windows® 7 – Control Panel You can change Windows settings using the control panel. The settings control almost everything relating to Windows displays and functionalities, and they enable you to organise Windows according to your requirements. When you first open the Control Panel, a few of the most frequently used elements of the Control Panel are displayed by category.
Windows Media Center The Windows Media Center is the platform for your individual home entertainment in Windows®7. You will be able to record television, TV broadcasts, DVDs and music, look at photos and much more by a remote (not included) or by a click of the mouse, with the Windows Media Center.
Page 74
Main menu Sub-menu Tasks Settings Adapt the Windows Media Center to your requirements and needs here. For example, make the settings for the protection of children here. Stand by You will not only close the Windows Media Center but you will be able to put the whole operating system in stand-by through this sub-menu.
Page 75
Main menu Sub-menu Music Music library All the music titles stored in your notebook will be located in the music library. You will be able to start the selected playback of an album, an artist or a selected title here. Play back everything You will start the playback of all the files stored in your music library by means of this sub-menu.
Installation of Software Note If your operating system is configured so that the installation procedure accepts only signed drivers (default) and software an information screen will appear. The software included in delivery is already pre-installed in the factory. Attention! You may find that during the installation procedure important files may be changed or even cancelled.
An example for the manual installation without the autorun function: 1. Click on Start 2. Click on All Programs. 3. Open the Accessories program point. 4. Select the item Run. 5. Now enter the letter of the CD-ROM drive followed by a colon and the program name setup: 6.
Windows Activation Microsoft is committed to the protection of intellectual property rights and the reduction of software piracy. Therefore Windows® 7 contains software-based product activation technology. Your copy of Windows® 7 has already been activated for your notebook. Product activation is needed if some components of your notebook have been replaced or you use a non-authorized BIOS.
The BIOS Set-up Program In BIOS setup (Basic Configuration) there are a number of configurable parameter settings available for your notebook. For example, you can change the operating mode of the interfaces, security features or power management. Warning! The notebook is factory pre-set to guarantee optimum operation. Only modify the parameters if necessary and if you are familiar with the configuration options.
Chapter 4 Help Subject Page Data and System Security ........... 75 System Restore ..............76 FAQ ..................81 Customer Service ............... 82 Errors and Possible Causes ..........83 Upgrades and Repairs ............87 Recycling and Disposal ............88...
Data and System Security The programs described below are part of your Windows operating system. You can find additional information on these programs in the Windows Help file. Please also read the notes on page 3. Data Security Back up data regularly on external media such as a CD-R(W), DVD-R(W) or external hard drive.
System Restore Windows® 7 provides a useful function (System Restore) enabling the storage of the so- called Recovery points. The system remembers the current configuration as a snapshot and returns to this, if necessary. The advantage is that an unsuccessful installation can be cancelled. Recovery points are created automatically by the system, but they can also be set manually.
Windows® Update Windows Update is the online updating of Windows. Use Windows Update to download elements such as security updates, important updates, the newest help files, drivers and Internet products from the Internet. The website is regularly updated with new content, so that you can download the newest updates and error corrections at any time, to protect the notebook and guarantee its functioning.
Windows Update Information for Data Security Windows Update needs certain information about the respective notebook, so that a suitable list with updates can be provided for you. This information will include the following: Version number of the operating system ...
System Restore If your system is not functioning properly, you should use the Application Support Disc to restore your system. Limits of the Recovery Changes made to the original configuration (RAS, Desktop or Internet settings) and installed Software will be ignored by this Recovery and will not be reloaded. ...
Carrying out a Restore 1. Remove any mass storage devices you may be using (memory cards, USB sticks, etc.). 2. Switch on the notebook. 3. Press the corresponding key when you see the message "Press F11 to run recovery" or "Press F12 to run recovery". After a few seconds, the message "Windows is loading files"...
FAQ – Frequently Asked Questions Do I still have to install the enclosed discs? No. Basically all programs are already preinstalled. The discs are only intended as backup copies. Where can I find the drivers necessary for my Notebook? The drivers are on the second partition of the hard drive, in the Drivers and Tools directories.
Customer Service Localise the Cause Errors can have simple causes, but sometimes they are caused by faulty equipment. We would like to give you some tips to help solve common problems. Should these instructions not lead to success, please feel free to contact us. Check Cables and Connections Visibly check all cables and connections.
Errors and Possible Causes The screen is black: This error can have different causes: 1. The operational display (On /Off switch) does not shine and the notebook is busy with 'file swapping'. Solution: Press the On /Off switch. 2. The sleep LED is flashing. The notebook is in the sleep mode. Solution: Press the On /Off switch.
Additional Support If the suggestions in the above section have not solved your problem, please contact customer care and we will attempt to help you solve the problem. Before you call, however, please have the following information available: How is your computer configured? ...
Transporting the Notebook Please use the following guidelines when transporting the notebook: Switch off the notebook. This will prevent damage to the hard drive. When the notebook is turned off, the hard drive heads are moved into a safe area. ...
Maintenance Warning! There are no user-serviceable or user-cleanable parts inside the notebook housing. Never open the notebook housing. Following these measures can extend the lifetime of your notebook: Before cleaning, always remove the power adapter plug and all connecting cables. ...
Upgrades and Repairs Only a qualified Service Engineer should perform upgrades and repairs to your notebook. If you do not have the necessary qualifications, go to an appropriate Service Engineer. Please contact the Service Centre if you are experiencing technical problems with your notebook.
Recycling and Disposal Device At the end of its life, the appliance must not be disposed of in household rubbish. Enquire about the options for environmentally-friendly disposal. Batteries Do not dispose of used batteries in the household rubbish! They must be deposited at a collection point for used batteries.
Information about Conformity The device fulfils electromagnetic compatibility and electricity safety requirements. Your device complies with the basic requirements and the relevant Australian EMC guidelines [electromagnetic compatibility] and the Australian electrical safety guidelines. This device fulfils the basis requirements and the relevant regulation of the Ecodesign Guideline 2009/125/EG (Commission Regulation 1275/2008).
Page 99
Pixel structure Rows Blue Green Types of Pixel Failures: Type 1: A constantly lit pixel (a bright, white spot), even though it is not addressed. A white pixel is caused when all three sub-pixel are lit. Type 2: A pixel that does not light up (dark, black spot), although it is addressed ...
FCC Compliance Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
This warranty covers defects relating to workmanship and manufacture in MEDION products. The period during which this warranty is valid and during which claims against the warranty can be made to MEDION must be in accordance with the following terms in order to be considered eligible: ...
Page 102
MEDION will return the product to you. If so and you would still like MEDION to repair or replace the product, MEDION may do so but you will be charged MEDION’s standard rates for repair and replacement for this service.
Page 103
You are entitled to seek independent advice or consultation relating to your product or any of MEDION’s findings. MEDION will not be liable for any costs incurred to you when doing so. 3. Exclusion from warranty...
Page 104
100% accuracy of the maps provided with the Navigation device. It may be necessary to delete all data in the product in order to repair the MEDION product. PLEASE MAKE SURE THAT YOU HAVE A BACKUP COPY OF ALL DATA ON THE PRODUCT BEFORE RETURNING THE PRODUCT TO MEDION.
Page 105
You are responsible yourself for restoring the application software after the repair services have been carried out by MEDION or its authorised personnel. You must take all other necessary steps to enable MEDION or its authorised personnel to carry out your order properly. ...
Index Opening and Closing the Display ... 34 A Screen Resolution ......34 All Programs ........22 ® ® Dolby Advanced Audio ..... 52 Ambient Temperature......5 Driver Support ........84 Appearance and Personalisation ..35 DVD-Drive .......... 45 Autorun ..........69 E ...
Page 107
L S Laser radiation ........87 Safety and Maintenance ....... 1 License Agreement ......21 Safety Instructions ........ 3 Ambient Temperature ...... 5 M Battery Operation ......10 Cabling ..........8 Main Components ......25 Care of the Display ......86 Card Reader ........
Page 108
VGA ..........15 V Webcam ......... 15 Views Audio Out ........16 W Device Indicators ...... 15, 17 Webcam..........57 Disc Ejet Button ......16 Windows Activation ......71 Emergency Ejection ......16 Windows Media Center ...... 66 e-SATA/USB Port ......15 Windows®...
