Honda Civic Hybrid 2009 Owner's Manual page 113

Ventilation
The flow-through ventilation system
draws in outside air, circulates it
through the interior, then releases it
through vents near the rear window.
Set the temperature to the lower
1.
limit.
2. Make sure the A/C is off.
Select and fresh air mode.
3.
4. Set the fan to the desired speed.
Using the Heater
The heater uses engine coolant to
warm the air. If the engine is cold, it
will be several minutes before you
feel warm air coming from the
system.
1. Select .
When you select , the system
automatically switches to the fresh
air mode.
2. Set the fan to the desired speed.
3. Adjust the warmth of the air with
the temperature control dial.
Using the A/C
Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page
66 ). If it moves near the red zone,
turn off the A/C until the gauge
reading returns to normal.
1. Turn on the A/C by pressing the
button. The indicator in the button
comes on when a fan speed is
selected.
Make sure the temperature is set
2.
to maximum cool.
3. Select .
If the outside air is humid, select
4.
recirculation mode. If the outside
air is dry, select fresh air mode.
Set the fan to the desired speed.
5.
If the interior is very warm, you can
cool it down more rapidly by partially
opening the windows, turning on the
A/C, and setting the fan to
maximum speed in fresh air mode.
Climate Control
Dehumidify the Interior
Air conditioning, as it cools, removes
moisture from the air. When used in
combination with the heater, it
makes the interior warm and dry and
can prevent the windows from
fogging up.
1. Turn the fan on.
2. Turn on the air conditioning.
3. Select and fresh air mode.
4. Adjust the temperature to your
preference.
This setting is suitable for all driving
conditions whenever the outside
temperature is above 32°F (0°C).
107
