Tycon Power Systems TP-SCPOE-1212 User Manual

Tycon tp-scpoe-12xx series solar & poe battery charger
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

TYCON
TP-SCPOE-12XX Series
Solar & PoE Battery Charger
USER'S MANUAL
TYCON POWER SYSTEMS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TP-SCPOE-1212 and is the answer not in the manual?

Questions and answers

Related Manuals for Tycon Power Systems TP-SCPOE-1212

Summary of Contents for Tycon Power Systems TP-SCPOE-1212

  • Page 1 TYCON TP-SCPOE-12XX Series Solar & PoE Battery Charger USER’S MANUAL TYCON POWER SYSTEMS...
  • Page 2 User’s Manual TP-SCPOE-12XX Series Features: Battery Polarity Reverse Protection Battery Over Charge Protection Battery Over Discharge Protection Solar Panel Polarity Reverse Protection Solar Panel Over Charge Protection Output Short Circuit Protection Output Over Voltage Protection POE Output Short Circuit Protection POE Output Support 802.3af Function (TP-SCPOE-1248D) Two Input method: (1)Solar Panel (2)PoE Power source (Always Solar First.)
  • Page 3 User’s Manual TP-SCPOE-12XX Series Panel Description: Item Name Descriptions PoE power input indicator: the LED lights when the PoE input jack POE : (the lower jack) has 18V~57V input. Solar power input indicator: the LED lights when SOL terminal is SOL : connecting to a solar panel and the solar panel input voltage is over 12V.
  • Page 4 User’s Manual TP-SCPOE-12XX Series Operation Guide NOTICE: 1. Connect the battery to the BAT terminal. Make sure the polarities are correctly connected. Sequentially connect the solar panel to SOL terminal and connect POE source to PoE input (lower) jack. (If solar panel or PoE source is installed before the battery, and if the polarities of the battery be reversed, then the fuse will be burnt.) 2.

  • Page 5: Electrical Specifications

    TP-SCPOE-12XX Series Electrical specifications 1.0 INPUT 1.1 Input Source types: A. Solar Panel B. POE 1.2 Input Voltage: A. Solar Panel: 18V~36Vmax B. POE: 18V~57V 2.0 OUTPUT Model TP-SCPOE-1212 TP-SCPOE-1218 TP-SCPOE-1224 TP-SCPOE-1248 TP-SCPOE-1248D 12V/1.5A 12V/1.5A 12V/1.5A 12V/1.5A 12V/1.5A Output 1* (at rear terminal) (as Bat.
  • Page 6 The output voltage on the rear terminal normally is the same as battery, if the battery voltage higher than 12.5V, the output voltage on the terminal will be clamped at 12.5V. The PoE output of TP-SCPOE-1212 with the same limit. 6. GENERAL DESCRIPTION 6.1 Operation Temperature:...

This manual is also suitable for:

Tp-scpoe-1218Tp-scpoe-1224Tp-scpoe-1248Tp-scpoe-1248d
