- Page 1 TYCON TP-SCPOE-24xx-HP Series Solar & PoE Battery Charger USER’S MANUAL TYCON POWER SYSTEMS...
- Page 2 User’s Manual TP-SCPOE-24XX-HP Series Features: Battery Polarity Reverse Protection Battery Over Charge Protection Battery Over Discharge Protection Solar Panel Polarity Reverse Protection Solar Panel Over Charge Protection Output Short Circuit Protection Output Over Voltage Protection POE Output Short Circuit Protection POE Output Support 802.3af Function (TP-SCPOE-2448D-HP)
- Page 3 User’s Manual TP-SCPOE-24XX-HP Series Panel Description: Item Name Descriptions PoE power input indicator: the LED lights when the PoE input jack POE : (the lower jack) has 36V~57V input. Solar power input indicator: the LED lights when SOL terminal is SOL : connecting to a solar panel.
- Page 4 User’s Manual TP-SCPOE-24XX-HP Series Operation Guide NOTICE: 1. Connect the battery to the BAT terminal. Make sure the polarities are correctly connected. Sequentially connect the solar panel to SOL terminal and connect POE source to PoE input (lower) jack. (If solar panel or PoE source is installed before the battery, and if the polarities of the battery be reversed, then the fuse will be burnt.)
-
Page 5: Electrical Specifications
User’s Manual TP-SCPOE-24XX-HP Series Electrical specifications 1.0 INPUT 1.1 Input Source types: A. Solar Panel B. POE 1.2 Input Voltage: A. Solar Panel: 30V~36V B. POE: 36V~57V (94w Min. For Only Charge, 160w Min. For Full Load.) 2.0 OUTPUT Model... - Page 6 User’s Manual TP-SCPOE-24XX-HP Series 5.3 Battery Over Charge Protection: Fuse control, over 10A, the fuse will be burnt. 5.4 Solar Panel Polarity Reverse Protection: When solar panel polarities be reversed, the charger stop output, it won’t damage the charger or end device 5.5 Solar Panel Over Charge Protection:...
