0403-1
E N T E R T A I N M E N T
E N T E R T A I N M E N T
MADE IN KOREA
S Y S T E
S Y S T E M S
DVD PLAYER
Owner's Manual
MODEL : R5600
RECORD YOUR MODEL NUMBER (Now, while you can see it)
The model and serial number of your new DVD player are located on the back of the DVD player cabinet.
For your future convenience, we suggest that you record these numbers here:
MODEL NO.
SERIAL NO.
(TV tuner built-in)
R5602
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rosen R5600
Summary of Contents for Rosen R5600
-
Page 1: Dvd Player
E N T E R T A I N M E N T S Y S T E M S DVD PLAYER Owner's Manual MODEL : R5600 (TV tuner built-in) R5602 RECORD YOUR MODEL NUMBER (Now, while you can see it) The model and serial number of your new DVD player are located on the back of the DVD player cabinet. -
Page 2: Important Information
Important Information Important Safety Instructions CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER(OR BACK). MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE NO USER-SERVICEABLE PARTS ARE INSIDE. -
Page 3: Important Safety Instructions
Important Safety Instructions Important Safety Instructions 18. Sound Distortion Do not allow the product to output distorted sound for a longtime. It may cause speaker overheating 8. Power-Cord Protection and fire. Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, playing particular attention to cords at plugs, convenience receptacles, 19. -
Page 4: Information About Disc
Information about Disc How to care and store disc DVD(Digital Versatile Disc) can record 135 minutes’ picture, 8 languages ● Be careful in handling the disc, because the slight flaw in disc might affect picture on the screen. sound and maximum 32 languages sub-titles. You can enjoy cinema-like live picture and crystal clear sound with MPEG-2 compression technology How to handle disc and dolby digital surround. -
Page 5: Table Of Contents
Contents Contents Important Information Playing a DVD disc(DVD/VCD/CD) ..................2 ..............23 Important Safety Instructions Playing a MP3 file ................. 3 ....................24 Information about Disc Disc Menu ..................6 ........................25 How to care and store disc Setting DVD ................ -
Page 6: Description
Description Description Front Panel VFD Display ① POWER ① DVD/SVCD/VCD/CD/PBC/MP3 Turns the power on/off. Illuminates the type of the disc loaded on the disc tray ② Disc In A Disc is inserted here. ② Rotation Rotates when the disc is spinning. ③... -
Page 7: Rear Panel
IR Sensor L.bracket 2ea television for a higher quality picture. controller cable ⑩ ANTENNA INPUT JACK Connect TV Antenna to DVDplayer. ※ Contact the store where you have purchased if you want to obtain other accessory. * option for R5600... -
Page 8: Remote Controller Button
Change from DVD mode to TV mode. Erase TV channel under TV mode. (DVD TV AUX1(Rear input) * option for R5600 AUX2(Front input) ) * option for R5600 13. PLAY, SAVE 27.NTSC/PAL, AIR/CABLE Begin disc play. Use to choose broadcasting methods (only Memory TV channel under TV mode. -
Page 9: Installing Batteries In The Remote Controller
Description Connection Installing Batteries in the Remote controller Connecting to a TV 1. Slide and open the battery cover. 2. Insert new batteries and ensure 3. Slide and close the battery cover. that the polarities are correct when inserting. You can connect auxiliary devices in this port, such as VCR. -
Page 10: Connecting To A Tv/Audio System
Description Connection Connecting to a TV/AUDIO System Connecting to a Dolby Digital Amp Rear Panel Rear Panel 75 ohm Coaxial Cable FM Antenna Video Cable Audio Cable Audio Cable To digital audio output Video Cable Receiver equipped with a Dolby digital decoder Front Front Center Speaker... -
Page 11: Enjoying 2 Channel Digital Stereo Sound
Connection Connection Enjoying 2 Channel Digital Stereo Sound Connecting TV antena / TV cable (option for R5600) Rear Panel To DIGITAL Audio Output Video Cable Receiver equipped with a Dolby digital decoder Front Front Speaker Speaker (left) (right) 1. Prepare TV antenna or TV cable to see TV. -
Page 12: Before Playing Your Dvd Disc
Before playing Your DVD Disc Playing a DVD disc(DVD/VCD/CD) When connecting to output componets, refer to "Connection" Chapter and output components’ manual,. Turn on the power of the Amplifier, if it is connected. First, turn on the power of TV, and press TV/Video button. Insert the DVD disc ●... -
Page 13: Playing A Mp3 File
Playing a MP3 file Disc Menu You can select the following menu when menu are recorded in discs. To display recorded menu in disc DVD/VCD 2.0 Insert the MP3 disc. ● Make sure that the disc's label is facing up. ●... -
Page 14: Setting Dvd
Setting DVD Setting DVD The picture which you can set up various menu in advance appears after pressing the button(SETUP) Setting up Language with the unit in Stop mode. The information about the picture is as follows. You can display OSD, subtitles or listen audio by language you want. Press the SETUP button with the unit in Stop mode. -
Page 15: Setting Up Video Item
Setting DVD Setting DVD Setting up Video item You can set up about screen as following. Press the … † buttons to move to Language Press the SETUP button with the unit in Stop mode. Item and press the ENTER button. ●... -
Page 16: Setting Up Audio Item
Setting DVD Setting DVD Setting up Audio item You can set up as following depending on the connected Audio speaker. Press the … † buttons to set up item and press Press the SETUP button with the unit in Stop mode. the ENTER button. -
Page 17: Setting Up The Parental Control
Setting DVD Setting DVD Setting up the Parental Control This setting prohibits children from watching violent, voluptuous disc by classifying grade on disc. You can grade by 8 rating levels. It works with DVD discs that have been assigned a rating. Press the …... - Page 18 Setting DVD Selecting Audio languages with the unit in play mode. To select Audio Language Press the LANGUAGE button to change Audio Language(DVD). Enter pass word with Numeric buttons. Memorize the password. In case you forget the password, this function is not working.
-
Page 19: Selecting Audio Languages With The Unit In Play Mode
Selecting Audio languages with the unit in play mode. Confirming Screen Display Screen display may not operate depending discs. To selct Subtitles Language Press the S-TITLE button to change subtitles. Press the DISPLAY button. The first screen shows present lapsing time and total running time of present track. -
Page 20: Confirming Screen Display
Confirming Screen Scanning Screen or Song Display To Skip Screens or Songs (DVD/VCD/CD) Press the DISPLAY button once more. Press the button (BACK, NEXT). The screen shows all information about disc. When you press the BACK button ● Moves to beginning of present chapter/track. - If you press once more, it moves to previous chapter/track. -
Page 21: Slow/Divided Motion
Slow/Divided motion Repeating Playback To playback Slow motion. To repeat a chapter, title, or track (DVD/VCD/CD) Use this button to repeat a chapter, title, or track Press the SLOW button. Press the MODE button. When you press the SLOW button Play mode Menu appears on the screen. -
Page 22: Repeating Playback
Repeating Playback Enjoying magnified screen and Changing Camera Angles To repeat a particular section To enjoy the magnified screen.(DVD/VCD) You can magnify the screen with 3 phases Press the A-B button at the position from which you want to repeat. Press the ZOOM button in Play or Pause state. -
Page 23: Enjoying Magnified Screen And Changing Camera Angles
Enjoying magnified screen and Searching to the Desired Screen/Song Changing Camera Angles You can find the desired screen or song by lapsing time, title, chapter, track. To changing Angle (DVD) To scan by lapsing time (for example by 1 hour 5 minutes 15 seconds) When a DVD contains multiple angles of a particular scene, you can select the Angle fuction. -
Page 24: Searching To The Desired Screen/Song
Searching to the Desired Playing JPEG file Screen/Song To scan by title, chapter(for example third chapters at first titles) Insert the Disc. Press the GOTO button. ● Make sure that the disc's label is facing up. ● Slide show begins from first picture automatically Press the …... -
Page 25: Setting Tv
Setting TV Setting TV TV Channel : Air channel range 2~69ch Cable channel range 01~125ch Press the Play button shortly to memory channel Watching TV press the stop button to erase channel. TV/AUX Press the TV/ Aux button. Press the Pause button or stay pressing the Play button on front of set to memory channel automatically. -
Page 26: Specification
Specification Is DVD Player something wrong? Contact the service center if same phenomenon appears, after taking following measures. Power Requirements DC 12V 2A Power Consumption � Ensure that TV is turned on. Weight 1.33Kg � Ensure that the power cord is plugged completely. General Dimension 178(D) X 175(W) X 50(H) - Page 27 Is DVD Player MEMO something wrong? � Aren't you playing with the unit in slow or "Scanning each scene" mode. (You can not listen sound at changing speed mode). � Check if it is connected and it is set up properly. No sound �...
