Rosen OVA10 Quick Start Manual
Rosen OVA10 Quick Start Manual

Rosen OVA10 Quick Start Manual

10.1” smarttv overhead in-vehicle entertainment system

Advertisement

Quick Links

FIRST TIME SETUP
Powering up the System
When vehicle power is applied to the system, the POWER and HOME buttons on the
1.
monitor will flash RED/BLUE for approximately 12 to 15 seconds and then the buttons
will remain solid RED. This is normal and a notification that the system is booting up.
Once the POWER and HOME buttons are solid RED, you can press the POWER
button to turn on the monitor.
Wi-Fi
1.
Press the
Setup icon to open the Settings Menu.
2.
Toggle the WIFI to "ON".
3.
Press WIFI to show available networks.
4.
Select the WIFI network you would like to connect to and use the touchscreen key-
board to enter the password.
5.
Press the green check mark to connect. The system will remember and automatically
reconnect to any saved available networks (maximum of 10).
NOTE:Your System was produced with the latest version of firmware available at the time.
To ensure optimal performance, please check to see if an UPDATE is available:
Setup>About Device>Check for Update. (Wi-Fi connection Required)
Wireless Headphones
1.
To use the wireless headphones, press the
2.
Select "IR TRANSMITTER" and toggle the switch to "ON".
Downloading Apps on the System Monitors
1.
Select the
apps icon from the main menu.
2.
Open the "Play Store" application, preloaded on the system. You will need to create or
sign in with your Google account.
3.
Browse the Google Play Store and download the applications you wish to the system
monitor.
Voxx Link
1.
Go to the Google Play Store or iTunes Store and download the free Voxx Link
application for your Smart Device.
Your Smart Device must be connected to the same WIFI network as the System
Monitors for the Voxx Link app to function.
2.
Press the
Setup icon to open the settings menu.
3.
Select "VOXX LINK" from the menu on the left. This will enable the feature.
4.
Open the application on your mobile device and select the monitor you wish to control
(example: OVA10_xxx). Once selected, the Monitor's screen will display on your
mobile device, allowing full control of the Monitor.
NOTE: This Voxx Link application is designed to allow a remote user (ie. Parent) that
does not have direct visibility to control the monitor.
Scan the QR Codes below to download the Voxx Link application.
iTunes Store
4
Setup icon to open the settings menu.
Google Play Store
QUICK START GUIDE
10.1" SmartTV Overhead In-Vehicle
Entertainment System
Congratulations on the purchase of your In-Vehicle Entertainment System!
This Quick Start Guide is a brief tutorial allowing you quick access to enjoying your new
system. You will find the system very user friendly and intuitive but in the event you need
further information on how to operate your system, please go to the following URL to review
or download the complete Operation Manual:
Advent:
http://sc.voxxintl.com/docs/common/ADVA10/ADVA10 OM.pdf
Audiovox: http://sc.voxxintl.com/docs/common/VODA10/VODA10 OM.pdf
Rosen:
http://sc.voxxintl.com/docs/common/ROSA10/ROSA10 OM.pdf
Invision:
http://sc.voxxintl.com/docs/common/INVA10/INVA10 OM.pdf
SYSTEM FEATURES:
DVD Player – Plays DVDs, CDs, MP3 discs
HDMI Input – Connect HDMI Devices such as Smart Phones or Game Consoles
Micro SD Input – Media Playback of Videos, Music, Photos
USB Input – Media Playback of Videos, Music, Photos, and Charging Support for
USB based devices
Apps – Download apps from the Google Play Store (Google Play Store, Google
Chrome, and Netflix preloaded)
Setup:
Wi-Fi - Connect to an In-Vehicle Wi-Fi Hotspot or other Wi-Fi Hotspot
(ie. Smart Phone) for full functionality of the system
Voxx Link - Allows Wi-Fi pairing of an Android or iOS based Smart Device to
the System Monitors allowing full system remote control and monitoring of the
System Monitors from anywhere in the vehicle. *Voxx Link app required
WFMM - Built-In 100 Channel Wireless FM Transmitter to broadcast Audio from
a System Monitor to a Vehicle's Audio System. *Must choose 1 monitor
IR Transmitter - 2 Channel Wireless Headphone Transmitter
Language - Select system language: English, Spanish, French, Chinese, or
Japanese
About Device - System Info and Update Tools
Reset - Resets the System Monitor to Factory Default
