Grizzly H7778 Instruction Sheet

Cast iron meat grinder

Download this manual

You MUST clean, thoroughly rinse, and sani-

tize all components of this product BEFORE

and BETWEEN uses. Failure to follow this

warning may lead to sickness or death!

NOTICE

The Model H7778 is NOT dishwasher safe!

Introduction

The Model H7778 is great for grinding meat and

stuffing sausage. Built with sturdy cast iron, the

meat grinder comes with two grinding plates and

three sausage stuffing attachments. The cast iron

components are double plated to make cleaning

easier and prevent rusting.

Disassembly for Cleaning

You must completely disassemble the grinder as

shown in Figure 2 to properly clean and sanitize

all of its parts.

Cleaning the grinder without first disassembling

it will not be effective and could lead to illness or

death. See the next page for more details about

cleaning and sanitizing.

WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE

OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

#TR7717 PRINTED IN CHINA

MODEL H7778

CAST IRON

MEAT GRINDER

INSTRUCTION SHEET

Figure 1. Model H7778.

Figure 2. Grinder disassembled for cleaning.

Page 1 NOTICE The Model H7778 is NOT dishwasher safe! Introduction The Model H7778 is great for grinding meat and stuffing sausage. Built with sturdy cast iron, the meat grinder comes with two grinding plates and three sausage stuffing attachments. The cast iron components are double plated to make cleaning easier and prevent rusting.
Page 2 Bacteria from raw meat has been frequently linked to illness and even death! Describing proper meat handling techniques outside of cleaning the meat grinder is beyond the scope of these instructions. If you are unclear about sanitary meat handling practices, con- tact your local Board of Health or the USDA to research the proper methods.
Page 3 Operating The Model H7778 is great for grinding hamburger or stuffing sausage. To setup the meat grinder, bolt it to a base plate that can be clamped to the work surface, or bolt it directly to the work surface. Whichever method you use, keep in mind that it must be designed to make cleaning easy.
Page 4 H7778 Parts Breakdown and List � � � � PART # PH7778001 PH7778002 PH7778003 PH7778004 PH7778005 PH7778006 PH7778007 PH7778008 PH7778009 PH7778010 PH7778011 PH7778012 � � � � DESCRIPTION HOUSING STUFFING FUNNEL CRANK HANDLE THUMBSCREW GRINDING BLADE AUGER LOCK RING FINE PLATE...
