- Page 1 AT-8600 Series Switch Installation and Safety Guide AT-8624T/2M AT-8624PoE AT-8648T/2SP...
- Page 2 AT-8600 Series Installation & Safety Guide AT-8624T/2M AT-8624PoE AT-8648T/2SP Download the complete document set from www.alliedtelesis.com/support/software...
- Page 3 AT-8600 Installation & Safety Guide Document Number C613-000083 REV H © 2006-2011 Allied Telesis Inc. All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesis Inc. Allied Telesis Inc. reserves the right to change specifications and other information in this document without prior written notice.
-
Page 4: Table Of Contents
Installation & Safety Guide Table of Contents Models Covered by this Guide ..................4 Package Contents ......................4 Selecting a Site ........................5 Installing the Switch ......................6 Connecting the Switch ....................10 Checking LEDs ........................ 13 Obtaining Documentation and Resources ............... 18 Standards .......................... -
Page 5: Models Covered By This Guide
One serial cable for connecting the switch to a terminal or PC ■ One 19-inch rack-mount kit ■ One AT-8600 Series Installation & Safety Guide (which includes statutory and safety information) ■ One warranty card Preinstalled AT -A65 expansion modules You can order the AT-8624T/2M or AT-8624PoE switches with two AT-A65 expansion modules included. -
Page 6: Selecting A Site
Installation & Safety Guide Selecting a Site Before you install the switch, review the following considerations about its location. ■ The switch requires an ambient temperature range of 0 º C to 40º C (32º F to 104º F). ■ There should be adequate airflow around the switch and its vents. -
Page 7: Installing The Switch
AT -8600 Series Switch Installing the Switch Ports on the switch are suitable only for connections within buildings (intra- building) and with cables unexposed to the outside. Before you begin ■ Read the safety information. For your well-being and that of the equipment, read the safety information in this document. - Page 8 Installation & Safety Guide Procedure If you have any optional expansion modules, install them first. The AT-8600 Series switches support the AT-A45/xx, AT-A46, AT-A47, and AT-A65 expansion modules. Install them by following the instructions in the relevant guide: • AT-A65 Expansion Module Installation and Safety Guide for the AT-A65 module only.
- Page 9 10/100/1000T port is once again active. Check the supply voltage and the switch’s rated voltage AT-8600 Series switches are fitted with a universal main power supply that functions from100–240 VAC and 50–60 Hz. Specific power supply requirements for the model are on the rear or underside of the switch.
- Page 10 50R MODE MODE Check that the PWR LED on the switch’s front panel is green. If the PWR (power) LED fails to light, refer to the AT-8600 Series Hardware Reference for troubleshooting information. Connect the data cables. Make sure each cable connection is secure. The switch can now process...
-
Page 11: Connecting The Switch
AT -8600 Series Switch Connecting the Switch Some configuration is necessary to enable the switch’s advanced switching capabilities. This is achieved via the Command Line Interface (CLI). On the AT-8624T/2M, you can also use the Graphical User Interface (GUI). Using the CLI to configure a switch Connect a terminal or PC to the terminal port (ASYN0). - Page 12 Save your configuration to a new file by using the command: create config=<filename>.cfg Then set the switch to load this file when it restarts by using the command: set config=<filename>.cfg For information about configuring the software, see the AT-8600 Series Software Reference. Using the GUI to configure the switch...
- Page 13 AT -8600 Series Switch switch. Connect the PC to the Use an Ethernet cable to connect an Ethernet card on the PC to any one of the switch ports. You can browse to the router through any VLAN, as long as you give that VLAN an IP address.
-
Page 14: Checking Leds
Installation & Safety Guide Checking LEDs The following tables outline how the switch and expansion modules report faults and operational activities. Expansion modules are optional and can be purchased separately. System LEDs State Description FAULT Switch operation is normal. The switch or management software is malfunctioning. - Page 15 AT -8600 Series Switch Link and Mode LEDs for the AT -8624T/2M switch State Description LINK There is no link between the port and the end-node. Green A valid link has been established between the port and the end-node. Mode - COL No data collisions are occurring on the port.
- Page 16 Installation & Safety Guide Link and Mode LEDs for the AT -8624PoE switch State Description L/A Status There is no link between the port (Top LED) and the end-node. Green The port is operating at 100 Mbps. Flashing Green There is activity on the port. It is transmitting and/or receiving data at 100 Mbps.
- Page 17 AT -8600 Series Switch Link and Mode LEDs for the AT -8648T/2SP switch State Description LINK There is no link between the port and the end-node. Green A valid link has been established between the port and the end- node. Mode - COL No data collisions are occurring on the port.
- Page 18 Installation & Safety Guide SFP and 10/100/1000Base-T LEDs for the AT -8648T/2SP switch State Description LINK There is no link between the port and the end-node. Green A valid link has been established between the port and the end- node. Mode - COL No data collisions are occurring on the port.
-
Page 19: Obtaining Documentation And Resources
You can download it from www.adobe.com. Other resources How-To Notes describe a range of standard Allied Telesis solutions, and include technical tips and guides to configuring specific hardware and software features. You can download the latest How-To Notes from www.alliedtelesis.com/resources/literature/howto.aspx. -
Page 20: Standards
Installation & Safety Guide Standards Where applicable, the products in this document meet the following standards: Category Approval Agency and Requirement UL60950-1 CAN/CSA-C22.2 No. 60950-1-03 EN60950-1 EN60825-1 Electromagnetic Compliance FCC CFR47 Part 15 Class A EN55022 Class A EN61000-3-2 EN61000-3-3 VCCI Class A AS/NZS CISPR22 Class A Immunity... -
Page 21: Safety
AT -8600 Series Switch Safety WARNING: In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. WARNING: Class 1 Laser product. WARNING: Do not stare into the laser beam. CAUTION: Use of controls or adjustments of performance or procedures other than those specified herein may result in hazardous radiation exposure. -
Page 22: Sicherheit
CAUTION: The surface-mount fuses F1 to F24 on the Power over Ethernet daughterboard in the AT-8624PoE switch are 60V, max 2A fuses. These fuses are not field-replaceable, and should only be serviced by a trained Allied Telesis service technician. Sicherheit WARNUNG: Bei Verwendung zu Hause kann dieses Produkt Funkstörungen... - Page 23 AT -8600 Series Switch VORSICHT: DAS NETZKABEL DIENT ZUM TRENNEN DER STROMVERSORGUNG. ZUR TRENNUNG VOM NETZ, KABEL AUS DER STECKDOSE ZIEHEN. GERÄTE DER KLASSE 1 DIESE GERÄTE MÜSSEN GEERDET SEIN. Der Netzstecker darf nur mit einer vorschriftsmäßig geerdeten Steckdose verbunden werden. Ein unvorschriftsmäßiger Anschluß...
-
Page 24: Sikkerhed
Installation & Safety Guide Sikkerhed ADVARSEL: I et hjemligt miljø kunne dette produkt forårsage radio forstyrrelse. Bliver det tilfældet, påkræves brugeren muligvis at tage tilstrækkelige foranstaltninger. ADVARSEL Laserprodukt av klasse 1. ADVARSEL Stirr ikke på strålen. ELEKTRISKE FORHOLDSREGLER ADVARSEL: RISIKO FOR ELEKTRISK STØD For at forebygge ELEKTRISK stød, undlad at åbne apparatet. -
Page 25: Veiligheid
AT -8600 Series Switch Lithium batteri - Bør kun udskiftes af uddannet og kvalificeret tekniker. ADVARSEL : Eksplosionsfare, hvis batteriet udskiftes ukorrekt. Udskift kun med samme eller en tilsvarende type der anbefales af producenten. Kassér brugte batterier i overensstemmelse med producentens instruktioner. ALLE LANDE: Installation af produktet skal ske i overensstemmelse med lokal og national lovgivning for elektriske installationer. -
Page 26: Sécurité
Installation & Safety Guide BEDRIJFSTEMPERATUUR: De omgevingstemperatuur voor dit produkt mag niet meer bedragen dan 40 graden Celsius. ELEKTRISCH: OVERBELASTING VAN WISSELSTROOM HOOFDCIRCUIT Tijdens de installatie van het produkt dient men rekening te houden met de gecombineerde waarden op de naamplaatjes bij het aansluiten van het toestel op de wisselstroom-voedingsdraden. -
Page 27: Turvallisuus
AT -8600 Series Switch ÉQUIPEMENT DE CLASSE 1 ÉLECTRIQUE CE MATÉRIEL DOIT ÊTRE MIS A LA TERRE. La prise de courant doit être branchée dans une prise femelle correctement mise à la terre car des tensions dangereuses risqueraient d’atteindre les pièces métalliques accessibles à l’utilisateur. - Page 28 Installation & Safety Guide SÄHKÖÖN LIITTYVIÄ HUOMAUTUKSIA VAROITUS: SÄHKÖISKUVAARA Estääksesi SÄHKÖISKUN älä poista kantta. Sisällä ei ole käyttäjän huollettavissa olevia osia. Tämä laite sisältää VAARALLISIA JÄNNITTEITÄ ja sen voi avata vain koulutettu ja pätevä teknikko. SALAMANISKUVAARA HENGENVAARA: ÄLÄ TYÖSKENTELE laitteiden tai KAAPELEIDEN KANSSA SALAMOINNIN AIKANA.
-
Page 29: Norme Di Sicurezza
AT -8600 Series Switch Norme di Sicurezza AVVERTENZA: in ambiente domestico questo prodotto potrebbe causare radio interferenza. In questo caso potrebbe richiedersi all’utente di prendere gli adeguati provvedimenti. AVVERTENZA Prodotto laser di Classe 1. AVERTENZA Non fissare il raggio con gli occhi. AVVERTENZE ELETTRICHE ATTENZIONE: PERICOLO DI SCOSSE ELETTRICHE Per evitare SCOSSE ELETTRICHE non asportare il coperchio. -
Page 30: Sikkerhet
Installation & Safety Guide ATTENZIONE: CARICAMENTO MECCANICO - Il montaggio del dispositivo sul supporto va effettuato in maniera tale da evitare qualsiasi potenziale condizione di pericolo eventualmente dovuta al montaggio irregolare. Batteria al litio - Va sostituita solo da un tecnico specializzato e qualificato. ATTENZIONE: l'errata sostituzione della batteria può... -
Page 31: Segurança
AT -8600 Series Switch FORSIKTIG: Lufteventilene må ikke blokkeres, og må ha fri tilgang til luft med romtemperatur for avkjøling. DRIFTSTEMPERATUR: Dette produktet er konstruert for bruk i maksimum romtemperatur på 40 grader celsius. ELEKTRISK OVERBELASTNING PÅ AC HOVEDKRETSLØP Når produktet installeres, må de samlede navneplateverdiene kontrolleres nøye når strøm påsettes. - Page 32 Installation & Safety Guide ELÉTRICO - EQUIPAMENTOS DO TIPO CLASSE 1 DEVE SER FEITA LIGAÇÃO DE FIO TERRA PARA ESTE EQUIPAMENTO. O plugue de alimentação deve ser conectado a uma tomada com adequada ligação de fio terra. Tomadas sem adequada ligação de fio terra podem transmitir voltagens perigosas a peças metálicas expostas.
-
Page 33: Seguridad
AT -8600 Series Switch Seguridad ADVERTENCIA: en un entorno doméstico, este producto puede causar radiointerferencias, en cuyo caso, puede requerirse del usuario que tome las medidas que sean convenientes al respecto. ¡ADVERTENCIA! Producto láser Clase 1. ¡ADVERTENCIA! No mirat fijamente el haz. AVISOS ELECTRICOS ADVERTENCIA: PELIGRO DE ELECTROCHOQUE Para evitar un ELECTROCHOQUE, no quite la tapa. -
Page 34: Säkerhet
