Summary of Contents for MYE MWC2-9
-
Page 1: Operation Manual
MWC2-9 MWC2-9 900MHz Receiver Radio with FM Radio Option Operation Manual manMWC29_V7 www.myeclubtv.com... -
Page 2: Table Of Contents
CONTENTS FCC Compliance Statement…………………..…………. Canada Compliance Statement………………………….. Specifications………………………………………….… Receiver Orientation (Front / Rear)…………………… Keypad – Key Identification………………………….… Main Features…………………………………………… Display and Icon Identification…………….…………… Programming - Near / Far Reception Setting…………… Programming the Receiver (Auto Programming)………. Programming the Receiver (Manual) ………………… FM Radio, FM Radio Disable…………………………..…... -
Page 3: Fcc Compliance Statement
Product Description The MYE MWC2-9 Receiver allows the user to listen to a TV or other audio source connected to a compatible 900MHz transmitter. It can also be used as an FM radio receiver. The MWC2-9 is powered by using a MYE Entertainment CSAFE cable plugged directly into any standard cardio CSAFE port or MYE 9 Volt AC Adapter. -
Page 4: Receiver Orientation (Front / Rear)
RECEIVER ASSEMBLY - FRONT VIEW LCD DISPLAY FRONT MOUNTING SCREWS UNSCREW TO RELEASE the MOUNTING BASE ASSEMBLY. (PLEASE READ “ATTACHING FRONT FLANGE THE RECEIVER” PGS. 8/9) KEYPAD HEADPHONE JACK CABLE EXIT HOLES RECEIVER ASSEMBLY & MOUNTING - REAR VIEW BAR CODE SERIAL NUMBER AND RATING LABEL FRONT MOUNTING SCREWS... -
Page 5: Keypad - Key Identification
Model: MWC2-9 The MYE MWC2-9 Receiver allows the user to listen to a TV or other audio source connected to a compatible 900MHz transmitter. It can also be used as an FM radio receiver. The MWC2-9 is powered by using a MYE Entertainment CSAFE cable plugged directly into any standard cardio CSAFE port or MYE 9 Volt AC Adapter. -
Page 6: Display And Icon Identification
Far Mode: (Default): The far mode is the most widely used and will accommodate the majority of installations. Near Mode: The near mode is used primarily in situations where the MWC2-9 receiver is positioned very close to one or more transmitters. The Near Mode is recommended when receivers are installed between 1 and 5 feet from a transmitter. -
Page 7: Programming The Receiver (Auto Programming)
Programming The MYE MWC2-9 receiver must be programmed to detect and lock in the MYE Entertainment transmitters as well as the other brands of transmitters listed below. The MWC2-9 features both “auto” and “manual” program modes. In the auto mode the MWC2-9 will automatically search for and program in your transmitters. -
Page 8: Fm Radio, Fm Radio Disable
FM RADIO Pressing the “FM” key switches the audio reception mode from 900MHz to FM. The FM Radio option is set to receive US FM radio broadcasts from 87.5 to 107.9. Use the SCAN key to scan automatically up to next available FM channel. Use the channel UP / Down keys to move up / down one FM frequency at a time. -
Page 9: Attaching The Receiver
Atta ching the Receiver The MWC2-9 receiver uses the MYE Entertainment Secure Grip Mounting Band. Mounting the MWC2-9 is now quick, secure and discrete. It is required that the Secure Grip Mounting Band always be used when installing MYE Entertainment MWC2 receivers. - Page 10 *USE only MYE Entertainment CSAFE cables with all MYE Entertainment receivers (900MHz, 800MHz or FM). MYE Entertainment will not be responsible for damage to receivers or cardio equipment when alternate or other cables are used.
-
Page 11: Intellijack
1. Loosen the two screws evenly on the bottom of the IntelliJack module and remove. 2. Carefully insert new IntelliJack module without bending contact pins. 3. Reset the Icon. Turn MYE Receiver OFF then press and hold the “Power” button for 3-4 seconds. When the “headphone” icon appears again release the Power button. -
Page 12: Warranty Information
FOLLOWING WARRANTY TERMS AND CONDITIONS. LIMITED WARRANTY MYE ENTERTAINMENT (MYE) WARRANTS ALL NEW MYE PRODUCTS TO BE FREE FROM DEFECTS IN MATERIALS AND MANUFACTURERS FOR THE WARRANTY PERIODS SET FORTH BELOW. THE WARRANTY PERIODS COMMENCE ON THE INVOICE DATE OF THE ORIGINAL PURCHASE. THIS WARRANTY APPLIES ONLY AGAINST DEFECTS DISCOVERED WITHIN THE WARRANTY PERIOD AND EXTENDS ONLY TO THE ORIGINAL PURCHASER OF THE PRODUCT. - Page 13 THOSE WARRANTIES THEREAFTER. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. MYE ENTERTAINMENT ALSO HEREBY DISCLAIMS AND EXCLUDES ALL OTHER OBLIGATIONS OR LIABILITIES, EXPRESS OR IMPLIED, ARISING BY LAW...
