ATC Group SCM200 User Manual page 8

S p e c i f i c a t i o n s
Drivers:
HF
MF
LF
Amplitude Linearity ±2dB
Cut-off Frequencies
(-6dB free standing)
Cut-off Frequencies
(-6dB soffit mounted)
Dispersion:
Horizontal
Vertical
Max Continuous SPL
Cabinet Dimensions (HxWxD)
Overall Weight
Cabinet Finishes
Amplifier Output:
LF1
LF2
MF
HF
Input Connector
Input Sensitivity
Input Impedance
Amplitude response
Signal/Noise Ratio
Crosstalk
Crossover Frequency
Filters
Overload Protection
Power Requirements:
Voltage
Frequency
Power Consumption
Dimensions
Overall depth
Front panel & handles
Rear handles
Amplifier body
Overall Weight
SCM200ASL
25mm (1")
75mm (3")
2 x 314mm (12")
60Hz - 12kHz
32Hz & 20kHz
25Hz & 20kHz
±80° Coherent
±10° Coherent
118dB SPL @ 1 metre
830 x 730 x 440mm
116kg (255.2lb)
Standard real wood veneers are available in Black Ash, Mahogany, Cherry and
Natural Oak. Other veneers and finishes can be supplied to special order.
P4
275 Watts RMS into 8 Ohms
275 Watts RMS into 8 Ohms
200 Watts RMS into 16 Ohms
100 Watts RMS into 6 Ohms
Male XLR
1.0V Balanced
>10k Ohms
5Hz - 20kHz ±0.1dB
Better than 105dB
Better than 90dB
380Hz and 3.5kHz
Even order critically damped
Active FET Momentary Gain Reduction on all amplifiers
100, 115, 230V (factory set)
50/60Hz
150VA (standby minimum) 1200VA (maximum)
19 inch rack mountable (5U high)
545mm
75mm
40mm
430mm
40kg (88.2lb)
SCM300ASL
25mm (1")
75mm (3")
2 x 375mm (15")
50Hz - 12kHz
25Hz & 20kHz
20Hz & 20kHz
±80° Coherent
±10° Coherent
121dB SPL @ 1 metre
884 x 925 x 460mm
140kg (308lb)
SCM200/300ASL/P4
Specifications comply with the following standards: Australian Standard
Specification No 1127 "Sound System Loudspeakers" Part 5, IEFE Specification
Standard No 219-1975
ATC reserves the right to vary products and specifications without prior notice.
Acoustic Transducer Co. is a trading name and ATC is the registered trade mark
of Loudspeaker Technology Ltd.
