TV BUTTONS & THEIR FUNCTIONS

TOP PANEL BUTTONS

1
Displays the input source menu
2
Displays Menu/OSD
3
Program/Channel down and menu down
4
Program/Channel up and menu up
5
Volume down and menu left
6
Volume up and menu right
7
DVD - Play/Pause
8
DVD - Eject
9
Standby On/Off

Choosing Mode/Source

To switch between the different connections
is very easy.
1) Press [SOURCE] - The following will appear
2) Press [\/] or [/\] to select the input you
require.
3) Press [OK]
Connecting HD Ready Devices
There are two options for HD.
1) By connecting via HDMI cable (not included)
– this provides both HD picture and sound.
2) By connecting via Component (YPbPr)
cable (not included) – this provides
HD picture. Source should be set to YPbPr.
For Sound, connect in to the 3.5mm audio input
YPbPr/AV (not included)
12
1
2
3
4
5
6
SOURCE MENU
CH-
CH+
VOL-
VOL+
7
8
9
STANDBY
