Page 1: Cover
I1000M Operation Manual IntraSonic Technology, Inc. | 610 Presidential Drive Ste 104 | Richardson, Texas 75081 | 877.435.0670 www.intrasonictechnology.com... -
Page 2: Table Of Contents
Table of Contents TOPIC Page Cover Table of Contents Safety Introduction System overview Operation controls Docking station K1/K2 buttons Volume up/down buttons Audio on/off button Up/down & left/right buttons Privacy Listen button Talk button Unlock the door Remote control Master Settings Clock Register all stations Assigning numbers to room, patio &... -
Page 3: Safety
Important Safety Instructions Please read all instructions carefully before installing the I1000 series music communication system. All components of the I1000 Series music communication system are permanent connection, and must be installed and disassembled by a qualified installer. Install in accordance with the manufacturer’s instructions. -
Page 4: Fcc
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions; (1) this devise may not cause harmful interference, and (2) this device must accept ant interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the users authority to operate the equipment. -
Page 5: Introduction
You can listen to your own home entertainment through the auxiliary input throughout your home. The I1000M not only allows you to use your portable hand held players throughout your home, but offers you the comfort and convenience of communication and room monitoring as well. -
Page 6: System Overview
Auxiliary input wall plate (maximum one per system) Master Unit The I1000M Master unit allows control of the music and intercom functions. It enables you to set the system music and intercom volume levels, bass and treble levels for the radio, clock settings, privacy settings and more. -
Page 7: Operation Controls
Operation Controls Integrated Docking Station Located on the left side of the master, behind the plastic door. Plug any hand help music device into master docking station by using a 3.5mm plug from the hand held device. The hand held device can also be charged by plugging it into the USB or firewire port provided in the docking station. -
Page 8: Master Settings
PREV ROOM PROG Register All Stations Before you can take advantage of all the features that the I1000M offers, you will need to register all units. Press K1 for MENU PROG Scroll through the system using the up/down arrow buttons and select... -
Page 9: Changing Numbers At The Room Station
ROOM 3396 NO. PREV 0001 ENTER Changing Numbers at the Room Stations MENU At the master, press K1 SYSTEM, PROG Scroll the up/down arrow buttons to press K2 Scroll the up/down arrow buttons to EN.SET NO , press K2 PROG ENTER Scroll to , press K2 to... -
Page 10: Door Volume
SPEAKER VOL PREV ENTER Door Volume MENU Press K1 for DOOR UNIT PROG Scroll to option using the up/down arrow buttons, select with theK2 button Using the up/down arrow buttons scroll to the door station and select PROG with the K2 button SET VOL PROG Using the up/down arrow buttons scroll to... -
Page 11: Mode
MODE The mode will tell the master, room or patio what functions to activate. There are six (6) mode settings that may be chosen. Normal mode is considered the standard setup. Normal – Intercom with music Intercom Only – Intercom only with no music Music Only –... -
Page 12: Setting Radio Presets
CHANNEL STORING EXIT PRESET NO 01 ENTER Setting Radio Presets Press left/right arrow buttons until the desired station has been reached SAVE Press K2 to this station ENTER Select the preset number with the up/down arrow buttons and select with the K2 button PM 03:30:50 VOL25 FM 92.5 MHz... -
Page 13: Set Treble And Bass
SET BASS PREV + 01 ENTER Set Bass and Treble Press K1 Button for MENU SYSTEM PROG Scroll to the using the up/down arrow buttons and select with the K2 button RADIO TONE PROG Using the up/down arrow buttons scroll to and select with the K2 button Using the up/down arrow buttons scroll to... - Page 14 Room Station Speaker LCD display Listen button Talk button Volume up and down buttons Source selection button Set and door release button 3.5mm local music input jack (on bottom of station) Page 14 of 20 IntraSonic Technology, Inc. | 610 Presidential Drive Ste 104 | Richardson, Texas 75081 | 877.435.0670 www.intrasonictechnology.com...
- Page 15 Remote Control Door release button Mute button Line in (source) Local input select AM radio select FM radio select Volume up Listen button Talk button 10. Monitor 11. Volume down 12. Radio preset select 13. Privacy 14. Station number select 0-9 15.
-
Page 16: Room And Patio Operation
ROOM AND PATIO OPERATION SOURCE This enables you to change the source for each room separately. There are RADIO, LINE IN and LOCL to choose between. Radio – AM/FM radio is distributed from the master Line In – Line in is distributed from the Auxiliary Input Unit (AUXWP) LOCL –... -
Page 17: Hands Free Listening
Hands Free Listening Press and hold the listen button to activate the hands free operation. By holding the listen button the second party does not need to press their talk button. Hold the listen button until the conversation has ended Unlock Door From Master (Optional feature) Once the door chime has been activated, UNLOCK DOOR will be on display Press the K1 button to unlock the door. -
Page 18: Remote Control
Remote Control (continued) Monitor Point the remote at the room station then press the monitor button for all monitor or select a room station by pressing the number of the room station and then monitor. Press the monitor button again to cancel room monitoring. If the patio station is desired, press the patio button and then the patio station number on the remote and then press the listen button. -
Page 19: Trouble Shooting
What happens if the power goes off? Like most electronic devices, when the power is off the equipment will not operate. The I1000M has a battery backup that should keep the owner selected settings during most power outages. Where is the battery backup and how do I The battery backup is located behind the master front panel. -
Page 20: Warranty
Intrasonic Technology, Inc. 2 Year Limited Warranty Intrasonic Technology warrants its products to be free of manufacturing defects for two years from the date of closing or actual installation. This warranty only applies to products purchased from authorized dealers or distributors. If proof of installation can not be supplied, the manufacturing date code may be substituted.
