Page 9
Starter System™. Air tubing is not
included with the Humidifier.
2. Place the PAP device into the
corresponding slots located at the
top of the Humidifier; then slide
the device forward until it snaps
into place (Image 6).
Note: The Transcend PAP device
has arm bars which help to guide
it into the Humidifier port. You will hear an audible click and feel it lock into
place when the PAP device is seated correctly.
3. Power the Transcend PAP device as described in the Transcend Sleep Apnea
System User Manual. The PAP device may be powered via wall (main) power,
Transcend battery, or Transcend Mobile Power Adaptor as appropriate.
4. Initiate therapy by pressing the power button
from the PAP device will turn on the Humidifier automatically and it will begin
warming the Water Reservoir. The middle LED on the back of the humidifier will
turn solid green to indicate that the Humidifier is heating the Water Reservoir
and is delivering humidification
(Image 7).
Note: The Humidifier temperature
setting must be in the range of 1
to 5 to initiate warming. A
temperature setting of 0 will turn
off the heating function of the
Humidifier.
Note: The Humidifier will not begin
warming the Water Reservoir until the PAP device power button has been
pressed and the PAP device is in Therapy Mode. It may take up to 60 minutes to
reach the set Humidifier temperature depending upon the selected heat setting.
Note: If a fault has occurred with the humidifier all three LEDs will begin to
flash. Please refer to the troubleshooting section of this user manual for more
information.
Transcend Heated Humidifier
Image 6
on the PAP device. Air flow
Image 7
