3. There is a switch on the bottom panel, next to the RCA cables,
that selects between PHONO/LINE. Use PHONO level for
plugging into a turntable input on a home stereo. Use the LINE
level for plugging into CD/AUX/TAPE inputs. WARNING: You
may damage your receiver if you plug in a LINE level
into a PHONO input.
4. Gain: This knob can be used to adjust the gain level of the
audio signal from the turntable. If the audio from the
turntable is too quiet or too loud, use this knob to adjust the
volume setting.
5. USB Audio Output: Use the included USB Cable to connect
your turntable to your computer. Refer to the software
instruction guide before plugging in your turntable.
6. Power Button: Use this button to power the turntable on and
off
7. Platter: This platter must be securely fastened to the
turntable prior to operation. The Motor Drive Belt can be found
on the drive ring underneath the platter. See SETUP
INSTRUCTIONS for detailed information on installing the Motor
Drive Belt.
8. Start/Stop Button: This button starts and stops the turntable
motor. If the button seems not to be functioning, check to
make sure that the Motor Drive Belt is properly installed in the
SETUP INSTRUCTIONS.
9. 1/8" Stereo Line Input: Connect Tape Players, Reel to Reel,
or any other audio source here. This signal is sent to the
computer through the USB connection. Make sure that your
phono cartridge is installed while using this input for
maximum sound quality. Also make sure that your RCA
jacks are either plugged into an input device or not in contact
with metal.
Note: The 1/8" audio input is not routed to the turntable's RCA
output jacks, only to your computer via USB.
10. 33 and 45 RPM Buttons: These buttons control the RPM of
the turntable platter. A red LED indicates which RPM mode has
been selected.
NOTE: If the turntable is powered down while in the 45 RPM
setting, it will return to 33 RPM when it is powered up.
Note: You can record your 78RPM records by recording them
at 33 or 45rpm, then changing them to 78 in the Audacity
software.
11. 45 RPM Adapter Holder: You may place the 45 adapter here
when not in use.
iTTUSB10 Owner's Manual V1.0 - Page 3
