Summary of Contents for Gibson Les Paul Standard 2010 LTD

  • Page 1 Gibson LP STD LTD Manual v1.0  Page 1 ...
  • Page 2: Important Safety Instructions

    Environmental Factors    Heat  and  moisture  can  harm  your  Gibson  Les  Paul  Standard  2010  Limited.  Please  do  not  install  or  operate  this  guitar  near  sources  of  moisture,  such  as  sinks,  damp  basements,  leaky  roofs,  etc.  and  never  store  it  near  heat  sources,  such  as  heaters  or  radiators.  Both  you  and  your  Les  Paul  Standard ...
  • Page 3: Warranty Protection

    You hear anything rattling around inside if you shake the Les Paul Standard 2010 Limited gently  Warranty Protection  It is extremely important to us that you are satisfied with Les Paul Standard 2010 Limited. Register it  and  activate  your  warranty  protection  by  mailing  the  warranty  card  included  with  Les  Paul  Standard  2010  Limited  to  Gibson  USA,  Department  W,  P.O.  Box  100087,  Nashville,  TN  37210‐0087.    If  you  encounter any kind of problem, contact us as soon as possible so we can make things right.    Once your warranty protection is active, the Les Paul Standard 2010 Limited's electronic components  are warranted to be free from defects in materials and workmanship for a period of one (1) year from  the date of original purchase. Your warranty covers the cost of both labor and materials on any repair  deemed  necessary  by  our  Customer  Service  Representative  for  the  warranty  period,  subject  to  the ...
  • Page 4 United  States,  contact  your  local  distributor  for  the  handling  and  resolution  of  all  warranty issues, as the warranty described here is not always applicable. And of course, Gibson shall  not be liable for any special, indirect, consequential, incidental or other similar damages to you or to  any  third  party,  including,  without  limitation,  damages  for  loss  of  profits  or  business,  or  damages  resulting  from  use  or  performance  of  the  product,  whether  in  contract  or  tort,  even  if  Gibson  or  its  authorized representative has been advised of the possibility of such damages, and Gibson shall not be  liable for any expenses, claims or suits arising from or relating to any of the foregoing.   ...
  • Page 5 Introduction: Welcome to the Les Paul Standard 2010 Limited    The  Les  Paul  Standard  2010  Limited  is  Gibson's  (fourth)  generation  “Robot”  guitar.  Building  on  the  success of the original Robot Guitar, the groundbreaking Dark Fire, and its predecessor the Dusk Tiger,  the Les Paul Standard 2010 Limited represents the apex of today's technology matched with the Les  Paul tradition of finely‐crafted guitars. Some of the Les Paul Standard 2010 Limited's standout features  include:    Third‐generation Robot Tuning Technology for automatic, accurate tuning  TM  Instantly selectable choice of tunings (standard and alternate tunings)  Chameleon Tone Technology delivers iconic guitar sounds without digital modeling  TM  The  Les  Paul  Standard  2010  Limited  is  equally  at  home  in  live  performance  or  recording ...
  • Page 6: Chapter 1: Les Paul Standard 2010 Limited Essentials

                                The MCK is a sophisticated “push‐pull” knob with an illuminated interactive display called the Display  Matrix. The display shows Les Paul Standard 2010 Limited's status as you select tunings, sounds, and  more  with  the  knob.  It  is  your  primary  way  of  interacting  with  Les  Paul  Standard  2010  Limited's  operating system.     Pulling the MCK up (furthest from the guitar body) activates it and applies power to Les Paul Standard  2010 Limited.     Gibson LP STD LTD Manual v1.0  Page 6 ...
  • Page 7                     • Position/String  LEDs.  These  10  LEDs  surround  the  MCK's  edge.  After  pulling  the  MCK  out,  rotating the knob to a particular LED chooses a specific sound, function, or string.  • b#  symbol.  Rotating the MCK fully counter‐clockwise to accesses this position, which is used    often with Red Bank operations.  • Rotating Arrow symbol. The text refers to this symbol as the “Rotating Arrow.”  • Guitar symbol. Shows the status of the Piezo pickup, e.g., whether it's available to be blended  in with the magnetic pickup and whether its companion onboard EQ is on or off. This is set in  the accompanying Gibson Chameleon Editor software.  Gibson LP STD LTD Manual v1.0  Page 7 ...
  • Page 8 EQ  section  is  on  or  off.  This  is  set  in  the  accompanying Gibson Chameleon Editor software.  • Variable color Display Matrix. This provides feedback on several aspects of Les Paul Standard  2010  Limited:  For  example,  it  changes  color  to  indicate  which  Bank  is  selected,  identifies ...
  • Page 9 Les  Paul  Standard  2010  Limited.  You  can  think  of  the  88  presets as a “playlist” taken from your master library of presets.    Red (Function) Bank. The Red bank is for configuring Les Paul Standard 2010 Limited, intonating the  guitar, doing advanced tuning functions, and more.    1.3 Switching Among Les Paul Standard 2010 Limited Banks    Switching between the Blue and Green Banks: As these are the most often‐ used Banks, it's easy to  switch between them. Pushing Enter briefly on the MCK while in the Green Bank switches to the Blue  Bank, and pushing Enter briefly on the MCK while in the Blue Bank switches to the Green Bank.    Switching among all Banks: With Les Paul Standard 2010 Limited powered‐on, push Enter on the MCK  briefly, then push Enter again within half a second. This takes you to the next Bank. A series of quick  presses, with each press within half a second of the next one, cycles through the various Banks. The  order of Bank selection is Green – Blue – Yellow – Red. This “wraps around,” so if Les Paul Standard  2010 Limited is in the Red Bank, pushing Enter on the MCK takes you to the Green Bank.   ...
  • Page 10 1. Use a standard guitar cord to connect Les Paul Standard 2010 Limited to your amplifier.  2. Pull the MCK out, tune Les Paul Standard 2010 Limited, and select a sound, as described in the Quick  Start guide.  3. When powered‐on, Les Paul Standard 2010 Limited's output carries a mix of the magnetic and Piezo  pickup  signals,  with  the  balance  determined  by  the  blend  control  (pickup  switch  toggle).  Turn  the  toggle clockwise for more Piezo sound, or counter‐clockwise for more magnetic sound.    Note:    There is an option to determine if the Piezo out appears on the tip and/or ring of the stereo cable or  neither. See Section 6.2, Functions 2 and 3.     1.4.3 Using the Gibson LP‐Z Low Impedance Output Circuit    Les Paul Standard 2010  Limited's output jack is a “combo” type that provides a standard 1/4”  guitar  output or Gibson's exclusive low‐impedance, balanced output LP‐Z circuit. To activate the LP‐Z output,  set the switch (to the left of the output jack) in the down position. The green LED next to the switch  will illuminate.    Plug the appropriate plug into the Les Paul Standard 2010 Limited's output. For driving a standard amp,  use a 1/4” stereo or mono guitar cable. For the LP‐Z output, you will need either a custom length XLR  male‐to‐male XLR cable, or use a standard XLR male‐XLR‐female mic cables in conjunction with an XLR  male‐to‐male adapter (e.g. Radio Shack part #274‐015).   Caution: When plugging the LP‐Z output into a mic input, never turn on the input's phantom power. ...
  • Page 11 2010 Limited along with mono or stereo outputs for your mixer, PA, or active speakers.  • For a computer‐based live performance setup that takes advantage of Les Paul Standard 2010  Limited's eight outputs and individual string processing possibilities, load Ableton Live Lite 8  Gibson Studio Edition into a laptop or other computer. Again, the *RIP provides physical inputs  and outputs for the “virtual rack.” All eight Les Paul Standard 2010 Limited signals are available  in  Ableton  Live's  eight  channels,  and  you  can  load  plug‐ins  like  Guitar  Rig  4,  or  the  plug‐ins  included in Ableton Live, to process these signals (e.g., octave dividers on only the lower strings  with  magnetic  pickups  going  through  an  amp  emulation,  etc.).  Live  provides  the  routing  and  mixing  for  all  these  signals,  which  then  go  to  your  amplification  system  via  the  *RIP's  stereo ...
  • Page 12 RoboHeads  will  tune  Les  Paul  Standard  2010  Limited  to  the  pitches  required  for  the  selected  alternate tuning.  4. The string colors indicate the tuning status, as described in the previous section.  5. When Les Paul Standard 2010 Limited is tuned, the string LEDs will all light solid green, then  Les Paul Standard 2010 Limited will switch automatically to the Green Bank.     MCK position  Name  Tuning (low string to high)  Peg  Standard Tuning  E A D G B e  i  Dropped D  D A D G B e  C  Double Dropped D  D A D G B D  E  Open E Major  E B E G# B e  A  Open A Major  E A E A C# e  Gibson LP STD LTD Manual v1.0  Page 12 ...
  • Page 13 Either  one  of  these  operations  can  permanently  damage the RoboHeads.    Unlike conventional tuning keys, RoboHeads all turn in the same direction. The RoboHead tuner posts  have locking nuts to secure the end of each string during tuning operations.    Robot technology includes special options for changing strings (see Sections 5.6, 5.7, and 5.8), as this is  much  faster  than  changing  strings  manually.  Gibson  strongly  advises  using  these  functions  when  changing  strings  not  only  because  it's  faster  and  more  convenient,  but  because  they  minimize  RoboHead wear.    Chapter 3: Les Paul Standard 2010 Limited Chameleon Tone    Technology ...
  • Page 14: Battery Charge Indicator

    BM  ’55 Les Paul character with Bridge or Middle pickup  4  LP Rhythm  B  ‘58/’60 Les Paul character, good for ‘80s heavy rhythm 5  335  N  Also try middle position; good 335 character  6  Funky  N  “Stratified” funky sound  7  Funky  B  “Stratified” sharp rhythm sound  8  Twang  B  Twangy “Telecasted” sound  9  Twang  N  Carved midrange, smooth and transparent highs  A  Acoustic  N  Set piezo level 25‐30%, neck volume to taste  Circle  Battery  ‐  Green = full, yellow = mid, red = low    MCK Pos Tone PU Comments  3.2 Battery Charge Indicator    Gibson LP STD LTD Manual v1.0  Page 14 ...
  • Page 15 The  volume  controls  in  a  classic  Les  Paul  interact  with  each  other  when  the  pickup  toggle  is  in  the  middle  position  (i.e.,  selecting  both  pickups).  Due  to  this  interaction,  if  either  the  neck  or  bridge  volume control is at “0” (all the way down), the signal is grounded and you will not hear any output—  regardless of the other control's setting. If you want to change the mix of the magnetic pickups with  the pickup toggle in the middle position, start with both magnetic pickup volume controls on “5” (up  halfway), then adjust to taste.    3.4 Other Factors Affecting Chameleon Tone    There are very significant differences in each Les Paul Standard 2010 Limited Chameleon Tone setting.  The tones were worked on for some time in studio settings to match vintage guitars.  However, note that a guitar's tone results from a combination of factors. For example, putting a single  coil in a guitar does not necessarily make it sound like the classic guitars that use single coil pickups.  The four main factors influencing tone are:  Gibson LP STD LTD Manual v1.0  Page 15 ...
  • Page 16: Chapter 4: The Yellow Bank, User Banks, And User Presets

    You can combine a custom sound and tuning within a single preset.  ●    The Gibson Chameleon Editor makes it easy to create, store, back up, and share custom presets for the  Yellow Bank (as well as the Blue and Green Banks). If you don't have access to a computer, it is possible  to  create  presets  for  the  Yellow  Bank  (see  Section  5.4)  but  the  process  is  more  tedious,  and  doesn't  allow access to several useful functions.  Conceptually,  many  Les  Paul  Standard  2010  Limited  owners  treat  the  Yellow  Bank  as  a  “playlist”  of ...
  • Page 17 Comments  position  Peg  LP, Comp  NH  Good for clear chords, defined and transparent  character  i  LP, Solo  NH  Also try middle position; mid‐range character, full and  warm  C  LP, lowmid, Solo  B  Les Paul '58/'60 character with bridge or middle  pickup  E  LP, Solo  B  '58/'60 Les Paul character, middle position gives fat  tones  A  Gent  all  N: Rockabilly, M: Daytripper sound (also try adding  about 20%‐30% piezo sound for “big Who riffs”), M:  Vary volume control blend for funky sounds  D  Jazzy, P10  B  Also try NH and M with 20% piezo added  G  Funky, P30  M  N = single coil, B = out of phase; with M, set N volume  on 8 and B higher than 8, add piezo to taste (e.g.,  15%). Turn B down for thicker sound, up for thinner  Gibson LP STD LTD Manual v1.0  Page 17 ...
  • Page 18 M  B up full, N volume 5, adjust B level for desired  character.      4.2 Factory Default Sounds for User Bank 2    MCK position  Tone  Comments  Peg  LS  Original Dark Fire sound  i  Metal  Original Dark Fire sound  C  Funky  Original Dark Fire sound  E  Gibson  Original Dark Fire sound  A  Twang  Original Dark Fire sound  D  Rock  Original Dark Fire sound  G  Acoustic  Original Dark Fire sound  B  Blues  Original Dark Fire sound  e  Gibson  Original Dark Fire sound  Arrow  Gibson  Original Dark Fire sound ...
  • Page 19: General Functions

    REF  Sets reference pitch (e.g., A = 440)  A  Up arrow  UP  Tune replacement string(s) up to pitch  D  Down arrow   DWN  Tune string(s) down for removal  G  U  USR  Access user banks    The following describes the various functions.        5.2 Chromatic Tuner (Position = Peg, ID = T)    The  chromatic  tuner  detects  a  plucked  string  and  displays  the  nearest  note  and  frequency  offset  compared to that note.    Gibson LP STD LTD Manual v1.0  Page 19 ...
  • Page 20 (display  shows  (“S”).  This  preference  is  stored  when  you  turn  off  Les  Paul  Standard  2010  Limited.  4. Rotate the MCK fully counter‐clockwise.  5. Push Enter briefly to toggle between Note Mode (display shows “N”) or Frequency  Mode (display shows “F”). This setting is not stored; Note Name is the default.  6. Pluck a string (open or fretted) and observe the readout. Continue to pluck strings as needed.  7.  To  exit  tuner  mode,  rotate  the  MCK  to  any  position  other  than  fully  clockwise  or  fully  counter‐clockwise, and push Enter briefly.    5.3 Intonation (Position = I, ID = I)    When strings aren't properly intonated the octave (12 fret) is off‐pitch compared to the open string.  th  When correctly intonated, the octave is exactly one octave above the open string.  Les Paul Standard 2010 Limited's intonation function makes intonating guitar strings easy. Each string  has an intonation screw on the part of the bridge that faces away from the pickups. Adjusting these  screws clockwise or counterclockwise adjusts the intonation; Les Paul Standard 2010 Limited will tell  you exactly how much you need to turn these screws, and in which direction.    Notes:  Gibson LP STD LTD Manual v1.0  Page 20 ...
  • Page 21 This  is  normal,  as  Les  Paul  Standard 2010 Limited switches automatically to a special high‐accuracy mode.    5.3.1 Intonation Step‐by‐Step    1.  In  the  Blue  or  Yellow  Bank,  choose  a  tuning.  For  general  intonation,  Gibson  recommends  using  the  standard  tuning.  However,  using  alternate  tunings  can  throw  off  intonation.  If  you  want perfect intonation for an alternate tuning, select that tuning prior to doing intonation.  2. Choose the Red Bank by initiating a series of brief, successive pushes on Enter until the Red  Bank appears. ...
  • Page 22 Les  Paul  Standard  2010  Limited  to  tune  the  remaining  strings  relative  to  the  reference  string.        5.5.1 Setting a Reference Pitch Step‐by‐Step    1.  Choose  one  of  the  stored  tunings  (e.g.,  Standard  tuning)  and  tune  Les  Paul  Standard  2010  Limited to it.  Gibson LP STD LTD Manual v1.0  Page 22 ...
  • Page 23 During  pitch  detection,  Les  Paul  Standard  2010  Limited  checks  that  the  resulting  tuning  is  ●  within the allowed pitch ranges, as specified in section 5.4.1 on Custom Tuning Preset Creation.  If a reference tuning is still active when selecting the same tuning for retuning, the display will  ●  show the preset ID briefly in red when entering the tuning function, then change to blue. This  reminds you that Les Paul Standard 2010 Limited is set to a specific reference tuning.    5.6 Replacing Strings: General Guidelines    Because each key turns extremely slowly when tuned by hand, Les Paul Standard 2010 Limited's Red  Bank includes two modes to speed up, and automate, the string‐changing process. Reminder: Do not  use manual or mechanically‐powered “string winder” tools. The two modes are:  • Single String Up Mode (for replacing individual strings, or replacing strings one at a time after  removing all strings)  • String Down Mode (for removing all strings at the same time)     You may want to “break in” your strings by tugging gently on them, and also perform multiple tunings  until they've stabilized—just like changing strings on a conventional guitar. Also, use strings with ends  that fit completely within the bridge end holes and do not short out to the bridge. For best results  when changing strings, please follow these steps carefully.    1. Manually rotate each tuner until the hole in the string binding post provides a straight path  for threading each new string.  Gibson LP STD LTD Manual v1.0  Page 23 ...
  • Page 24 Two  or  at  most  three  presses  should  put  enough  tension  on  the  new  string  for  it  to  tune  with  standard  tuning  operations.  Also,  remember  that  no  tuning  functions  work  if  any  portion  of  the  string shorts to the bridge base or adjacent strings.    5.8.1 Tuning Up Strings Step‐by‐Step    1. Choose the Red Bank by initiating a series of brief, successive pushes on Enter until the Red  Bank appears.  Gibson LP STD LTD Manual v1.0  Page 24 ...
  • Page 25 5.9 Yellow Bank User Bank Selection (Position = G, ID = U)    The Yellow Bank has eight User Banks, each of which has 11 presets. When you select the Yellow Bank,  it defaults to whatever User Bank has been selected using this function (if no User Bank has ever been  selected, the Yellow Bank defaults to User Bank 1).    5.9.1 Selecting a Yellow Bank User Bank Step‐by‐Step    1. Choose the Red Bank by initiating a series of brief, successive pushes on Enter until the Red  Bank appears.  2. While in the Red Bank, rotate the MCK to the G position.  3. Push Enter for more than one second; the Display Matrix shows the currently selected User  Bank in yellow.  4. Rotate the MCK to select the desired User Bank (1‐8). The outer LED that corresponds to the  bank you've selected will shine blue. If you turn the MCK to an invalid position (i.e., above 8),  the Display Matrix shows “X.”  5. After selecting the desired User Bank, push Enter briefly to activate the User Bank. The  Display Matrix shows the User Bank number in green briefly before exiting to the Red Bank.  Now  when  you  select  the  Yellow  Bank,  the  outer  LED  that  corresponds  to  the  selected  User  Bank will shine yellow, and remain selected until you repeat the above procedure to select a  different User Bank.    Chapter 6: Red Bank Setup Functions  Gibson LP STD LTD Manual v1.0  Page 25 ...
  • Page 26: Selecting Setup Mode

    7.  After  entering  the  value,  turn  the  MCK  fully  counter‐clockwise  to  the  Enter  position  (cyan  arrow  with  right‐angle  tail)  and  push  Enter  briefly.  The  Display  Matrix  will  show  the  entered  parameter value, then flash all outer LEDs green to confirm that the value has been accepted.  8. Exit the Setup menu by pushing Enter for more than one second.    The following set of tables shows the various user‐editable Functions available in Function Mode, but  please notes the following important points.  Note 1: The function's “clickstream” shown in each chart abbreviates the MCK operations needed to  edit the function. To save space and text:  It's assumed you've already completed steps 1‐3 under Selecting Setup Mode.  ●  The § symbol means, “rotate the MCK fully counter‐clockwise then push Enter briefly.”  ●  Gibson LP STD LTD Manual v1.0  Page 26 ...
  • Page 27 Note: This relates only to Piezo Out Mono where all six strings are mixed. Piezo Out Hex is never routed to the tip.   Function 4  Inactivity timeout: Determines required inactivity time before shutdown Default = 10 Value  Result  Clickstream 1 through 255  Sets required inactvity time before shutdown (in minutes) 4 § 1‐255 §   Function 10  Tuning precision: Sets up tuning precision and performance Default = 5 Value  Result  Clickstream 0 to 8  Trades off tuning speed for accuracy. 0 = least accurate, 8 = most accurate 10 § 0‐9 § Note: 0 gives fastest tuning with 2.5 cent accuracy, 8 gives slowest tuning with 0.2 cent accuracy      Function 11  Runtime correction: Set up RoboHead runtime correction Default = 1 Value  Result  Clickstream 0  Turns off runtime correction (not recommended) 11 § 0 § 1  Monitoring RoboHeads generates correction data for different string gauges  11 § 1 § Note: It takes up to 10 tunings to match the RoboHead movement to a specific string gauge Gibson LP STD LTD Manual v1.0  Page 27 ...
  • Page 28   Function 17  Clipping correction  Default = 1 Value  Result  Clickstream 0  Clipping correction is disabled (not recommended) 17 § 0 § 1  Enables clipping correction to improve E‐function correction accuracy 17 § 1 § Note: Deviations in the signal strength of individual piezo pickups can influence the precision of the E‐function correction. Enabling clipping correction minimizes this error by monitoring the signal strength over time (specifically the time a string  is clipping), then using the results to improve the E‐function correction.    Function 18  Neck tension correction  Default = 1 Value  Result  Clickstream 0  Neck tension correction is turned off 17 § 0 § 1  Neck tension correction is turned on 17 § 1 § Note: Changing a single string's pitch will alter the neck tension, and thus influence the pitch of other strings. With this  option activated, the expected influence of changing the pitch of one string is calculated for all other strings. If the  accumulated changes for a string already considered in tune exceed a certain threshold (1 cent with highest sensitivity),  the tuning process for this string restarts. Example: Retuning all strings in most cases will result in changes equal to or less  than 1 cent per string. This will not have a noticeable effect on neck tension, so all strings will only be tuned once. If  changing from normal tuning to dropped D, the low E string will be detuned 200 cents. This will have a noticeable influence  on the other strings; so after the low E string has been tuned, all other strings are marked as out‐of‐tune again. This option  will increase the tuning accuracy, but might have a slight impact on the tuning performance, depending on the order in  which the strings are tuned. In the worst case, it will behave like “TuneCount = 2.”  Gibson LP STD LTD Manual v1.0  Page 28 ...
  • Page 29     Function 24  Preset bank mode  Default = 0 Value  Result  Clickstream 0  Loads sound and tuning in Preset Mode (Yellow Bank) 24 § 0 § 1  Loads sound only in Preset Mode (Yellow Bank) 24 § 1 § Note: This switch determines how a preset is loaded in Preset Mode (Yellow Bank). If value = 0, both the preset tuning and  sound are activated. This causes the system to start the tuning process on preset activation. If value = 1, only the preset's  sound is loaded. Activating the tuning is still possible by pushing Enter for more than one second.    Following  are  additional  setup  mode  functions  for  doing  a  variety  of  system  resets;  these  follow  the  same basic procedures as the previous setup functions.    Gibson LP STD LTD Manual v1.0  Page 29 ...
  • Page 30 Caution: The following setup functions are servicing procedures, and are included for completeness.  Be  aware  that  resetting  sounds,  tunings,  or  user  banks  will  delete  any  custom  sounds,  tunings,  or  user bank settings you've created. Before doing any resets, Gibson advises saving all custom sounds  using the Gibson Chameleon Editor software.    Function 99  Display software version: Shows Dusk Tiger's current software     Result  Clickstream   Show current Dusk Tiger software version 99 § Note: There is no default as this is a read‐only parameter   Function 101  Reset tuning config data: Resets to standard tuning, default precision, etc.      Result  Clickstream Step 1  Do the clickstream on the right, then rotate the MCK fully counter‐clockwise  101 §...
  • Page 31: Appendix A: Les Paul Standard 2010 Limited Electronics Block Diagram

    Result  Clickstream Step 1  Do the clickstream on the right, then rotate the MCK fully counter‐clockwise  109 § Step 2  Press the Display Matrix momentarily, then wait for the red “?” to appear   Step 3  Rotate MCK to the cyan “Y” (“Yes”), then press the Display Matrix momentarily    Step 4  Rotate MCK to the “Enter” sign, then press the Display Matrix momentarily   Step 5  To exit, push Enter for more than one second.   Note: If you change your mind about resetting, in Step 3, choose “N” (“No”) instead of “Y.”                                 Appendix A: Les Paul Standard 2010 Limited Electronics Block Diagram     Gibson LP STD LTD Manual v1.0  Page 31 ...
  • Page 32: Appendix B: Alternate Tuning Tricks

    This  diagram  indicates signal  flow  within  Les  Paul  Standard  2010  Limited's  electronics.  Note  that  the  magnetic pickups and Piezo pickup have their own equalizers, and that the Piezo blend circuit is post‐ equalizer.    In  Hex  Mode,  the  *RIP  Computer  Interface  does  sophisticated  analog  signal  multiplexing  in  order  to  have the Piezo pickup and the individual hex pickups available on a single conductor (i.e., the stereo  cable's ring connection).                                Appendix B:  Alternate Tuning Tricks    Gibson LP STD LTD Manual v1.0  Page 32 ...
  • Page 33: Appendix C: Battery And Power Management

    You  may  use  this  technique  for  all  tunings  /  strings  that  are  at  lower  pitch  than  the  tuning  you  are  using.    Tuning Multiple Strings Down    If you want  to tune more than one  string down to a certain pitch, you may fret and strum string by  string. Let´s do an Eb (Hendrix tuning) with this technique.    1. Activate Les Paul Standard 2010 Limited's standard EADGBe tuning but don't strum yet.  2. Fret the low E at the 1st fret and pluck only that string. Les Paul Standard 2010 Limited will  tune the low E string to Eb.  3. Fret the A string at the 1st fret and pluck only that string. Les Paul Standard 2010 Limited will  tune the A string to Ab.  4. Fret the D string at the 1st fret and pluck only that string. Les Paul Standard 2010 Limited will  tune the D string to Db.  5. Continue fretting strings at the 1st fret and plucking individual strings.  Appendix C: Battery and Power Management                          Appendix C:  Battery and Power  Management    Gibson LP STD LTD Manual v1.0  Page 33 ...
  • Page 34: Low Battery Warning Indicator

    • Caution:  Do  not  use  any  charger  other  than  the  one  supplied  with  Les  Paul  Standard  2010  Limited. Li‐Ion batteries require specific charge rates.  • Avoid full discharges that drain the battery completely. Li‐Ion batteries like to be discharged  somewhat,  then  recharged  back  to  full  capacity.  Les  Paul  Standard  2010  Limited  provides  a  good environment for Li‐Ion batteries, as you’ll typically discharge it about halfway during the  length  of  a  concert.  Charging  the  battery  back  to  full  charge  after  playing  provides  optimum  battery life.  Gibson LP STD LTD Manual v1.0  Page 34 ...
  • Page 35: Appendix D: Troubleshooting

    If you play Les Paul Standard 2010 Limited and discharge it 50% during a concert, then charge it to full  capacity, that is only half of a charge/discharge cycle. If you play Les Paul Standard 2010 Limited every  day and discharge it to 75% of capacity then charge it back to 100%, it would take four days before the  battery would experience a full charge/discharge cycle.    However,  a  battery  has  a  finite  life  regardless  of  whether  you’ve  used  up  the  full  number  of  charge/discharge cycles—after about 2‐3 years its internal resistance rises to the point where it can no  longer deliver its rated voltage.     It’s important to remember that Li‐Ion batteries like “exercise.” Leaving a battery on a charger all the  time will lead to lower performance than doing some degree of charging and discharging.  Appendix D: Troubleshooting                    Appendix D:  Troubleshooting  Gibson LP STD LTD Manual v1.0  Page 35 ...
  • Page 36   If you encounter problems with Les Paul Standard 2010 Limited, Gibson recommends that you take it  to an authorized service center. Although there are some procedures you can try yourself, be careful— if you have any doubt about your ability to do any of these fixes, please consult Gibson tech support.    One or more strings don't seem to tune correctly, but the rest do.    There can be several possible reasons for this problem:    • The nut slot too high and there's too much friction  • The lock nut on the string post is not tight enough  • The string was strummed too hard, causing it to go sharp  • A sticky string bar in the saddle causes pitch detection to fail  • The accuracy setting needs to be higher; the accuracy setting is too low (Section 6.2, Function  10)  • E‐Function Correction is enabled (refer to Section 6.2, Function 12)  • The tailpiece is set too low, so the string touches the bridge base and shorts out to it.    Observe what happens when you try to tune the problematic string. Here's what should happen:    • You strum, the respective string LED should start flashing red to indicate that pitch detection is  active.  • After 1 second, the LED should start flashing yellow (information is being sent to the neck CPU,  and the RoboHead starts to move).  • After tuning the string, the string's LED turns green to indicate the string is in tune.    If not, try these fixes:    • Remove the problematic string and make sure the string bar is not inclined in the saddle, and ...
  • Page 37   The  gear  ratio  in  the  RoboHeads  is  24:1,  so  you  need  to  turn  the  tuning  peg  24  times  to  get  one  complete  rotation  of  the  string  post.  This  is  one  reason  why  Gibson  recommends  using  the  Robot  tuning options, especially when re‐stringing. Please see Sections 5.6, 5.7, and 5.8 for more information.  Gibson LP STD LTD Manual v1.0 ...
