MERIT INDUSTRIES Megatouch XL Owner's Manual

Megatouch xl
Hide thumbs Also See for Megatouch XL:
Table of Contents

Advertisement

Quick Links

OWNER'S MANUAL
FOR TECHNICAL ASSISTANCE
CONTACT:
Merit Industries, Inc. Customer Service Department
USA and Canada call toll-free:
1-800-445-9353
(215) 639-4700
Outside the USA and Canada call:
FAX: (215) 639-5346
2525 State Rd., P.O. Box 5004, Bensalem, PA 19020-8529
merit industries, inc.
PM0109-0D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Megatouch XL and is the answer not in the manual?

Questions and answers

Related Manuals for MERIT INDUSTRIES Megatouch XL

Summary of Contents for MERIT INDUSTRIES Megatouch XL

  • Page 1 OWNER’S MANUAL FOR TECHNICAL ASSISTANCE CONTACT: Merit Industries, Inc. Customer Service Department USA and Canada call toll-free: 1-800-445-9353 (215) 639-4700 Outside the USA and Canada call: FAX: (215) 639-5346 2525 State Rd., P.O. Box 5004, Bensalem, PA 19020-8529 merit industries, inc.

  • Page 2: Site Preparation

    CPU and CRT-500 I/O boards, the power supply and the main harness; in the upright and cabaret In determining the location for your Megatouch XL versions, the CPU section houses the CPU and video game, consideration must be given to a CRT-500 I/O boards, the power supply, the main suitable, grounded electrical outlet.

  • Page 3: Screen Calibration

    COPYRIGHT 1997 MERIT INDUSTRIES, INC. Screen Calibration Follow the instructions below for degaussing a monitor. The machine must be in the idle mode or game 1. Plug in your degaussing coil. select mode to calibrate the touchscreen. 2. Hold the coil about three feet from the monitor, press the trigger to activate the magnetic field Find the “CALIBRATE”...

  • Page 4: Troubleshooting

    COPYRIGHT 1997 MERIT INDUSTRIES, INC. 4. Exit Run 21 and enter the Hoop Jones game the plastic tubing and ground strap attached to the screen. Make sure that the court surface is lid. Press up on the spring-loaded levers located on greenish in color and look for a clean, white each side of the lid.

  • Page 5: Dip Switch Settings

    *NOTE: The soft DIP switch settings displayed on your by the soft DIP switches (accessed by touching the game will depend on which games are selected as “OPTIONS” icon on the Megatouch XL Setup active in the Game Menu screen, as well as the screen. See Figure 1).
  • Page 6 COPYRIGHT 1997 MERIT INDUSTRIES, INC. To Enter This Screen, Touch The “Setup” Button In The Coin Mech Section MEGATOUCH XL SETUP COIN-IN GAME DISPLAY MENU MENU BOOKS TOUCH VIDEO OPTIONS SCREEN TEST TEST HIGH CLEAR FREE SCORES CREDITS CREDITS SYSTEM...
  • Page 7 COPYRIGHT 1997 MERIT INDUSTRIES, INC. *Six Stars Enabled This feature allows the access to the Clear High Scores, Volume Control and Video Billboard, without having to remove the coin box. If the Six Stars Enabled dip switch is set to “YES,” touching the screen during the idle mode will cause six numbered stars to appear on the screen.
  • Page 8 COPYRIGHT 1997 MERIT INDUSTRIES, INC. To Enter This Screen, Touch “Game Menu” In The Setup Screen MEGATOUCH XL EXIT GAME MENU SETUP CARD QUIZ SPORT & STRATEGY EROTIC GAMES GAMES SKILL GAMES 1 Solitaire 2 Power Sol 3 Tritowers 4 Eleven Up...
  • Page 9 COPYRIGHT 1997 MERIT INDUSTRIES, INC. To Enter This Screen, Touch “Coin-In Menu” In The Setup Screen MEGATOUCH XL SETUP COIN/CREDIT SETUP COIN INPUT COINS CREDITS & METER PULSES Figure 3 - Coin-In Menu Screen The coin/credit ratios of the game may be adjusted to meet any application. The CPU board supports up to four coin inputs, mechanical or electronic.
  • Page 10 COPYRIGHT 1997 MERIT INDUSTRIES, INC. Megatouch™ XL Video Billboard Operating Instructions The Megatouch™ XL Video Billboard allows for six, separate advertising screens. Two of the screens can only be accessed using “Six Stars” (and are intended for use by the location owner), the other four screens are accessed using the Video Billboard icon located on the System Settings screen.
  • Page 11 COPYRIGHT 1997 MERIT INDUSTRIES, INC. increments. (Setting the timer to zero (0) will prevent the screen from being displayed. This can be used to design a screen that the user does not want to display, but does want to store it in the game’s memory for use at a later time or date.) The timer can only be set at the Primary Video Billboard screen.
  • Page 12 COPYRIGHT 1997 MERIT INDUSTRIES, INC. SELECT SELECT TYPE SELECT SIZE SELECT COLOR ALIGNMENT WHITE BLUE _____ _____ STYLE A _______ _______ _____ _____ 67</(% GREEN _____ BLACK PURPLE STYLE C _______ _____ YELLOW BROWN 67</(' DONE Figure 5 - Video Billboard Font Formatting Screen...
  • Page 13 COPYRIGHT 1997 MERIT INDUSTRIES, INC. FIGURE 4 - 13” COUNTERTOP PM0109-0D MEGATOUCH™ XL MANUAL...
  • Page 14 COPYRIGHT 1997 MERIT INDUSTRIES, INC. FIGURE 5 - 19” UPRIGHT (FRONT VIEW) FIGURE 6 - 19” UPRIGHT (REAR VIEW) PM0109-0D MEGATOUCH™ XL MANUAL...
  • Page 15 COPYRIGHT 1997 MERIT INDUSTRIES, INC. FIGURE 7 - 19” CABARET (FRONT VIEW) FIGURE 8 - 19” CABARET (REAR VIEW) PM0109-0D MEGATOUCH™ XL MANUAL...
  • Page 16 COPYRIGHT 1997 MERIT INDUSTRIES, INC. MEGATOUCH XL PARTS LISTS Megatouch XL COP Part List CALLOUT # PART # DESCRIPTION SA0100-01 ASSY, MEGATOUCH XL, CTOP MW0009-01 CHASSIS, CTOP, XL MW0015-01 BRACKET, LOCK, CTOP XL HW8741 LOCK, CIRC, BNT, DIFF, 1/2” SA4084-02 SPEAKER ASSY, 4”, W/6-PIN CONN...
  • Page 17 DECALS AND SIGNS GL3100-01 DECAL, SIDE PANEL, XL, CTOP GL3101-01 DECAL, FRONT, XL, CTOP SA7297-06 SIGN HOLDER, MEGATOUCH XL (HOLDER & SIGN ASSEMBLY) HW9461-03 SIGN HOLDER, PETG, 4 X 12, CTOP PM8928-09 SIGN, MEGATOUCH XL, CTOP COIN MECHS/BILL ACCEPTORS 25¢ USA HW8249 FR/PLATE, SINGLE, M, .25, ROLL DOWN...
  • Page 18 COPYRIGHT 1997 MERIT INDUSTRIES, INC. 19” Upright Parts List CALLOUT # PART # DESCRIPTION EC2001 POWER CORD, 120V HW8711 ANCHOR PLATE FOR CAM LOCK HW8716 LOCK, FLAT, STR, #564, 1-7/16” (REAR DOOR) HW8960 LEG LEVELER, 2”, 3/8-16THD MW5001-01 STAY LID, URTS, 19”...
  • Page 19 COPYRIGHT 1997 MERIT INDUSTRIES, INC. 19” Cabaret Parts List CALLOUT # PART # DESCRIPTiON EC2001 POWER CORD, 120V MW1672-01 CONTROL PANEL, 19” CABARET MW1671-01 BRKT, GLASS, UPPER, 19” CABARET MW1670-01 SPEAKER, MTG BRKT, 19” CAB HW8951-01 BEZEL, MONITOR, 19” CABARET WD5060-01 WOOD CABINET, URTS, 19”...
  • Page 20 1997 MERIT INDUSTRIES, INC. Merit Video Limited Warranty Merit Industries, Inc. warrants it’s video countertop and In certain instances, due to geographical or other upright machines to be free from defects in material considerations, Merit may offer PCB warranty service...
