TruePower Inverter Series
200 - 400 Watt Portable Models
Model
Part Number
200 Watt
05020
12 VDC Input / 200 Watt 110 VAC Output Inverter
400 Watt
05040
12 VDC Input / 400 Watt 110 VAC Output Inverter
Your Satisfaction is Important to us. Do Not return this Product to the Retailer or
Dealer for any service or warranty requirements. Please call our Customer Care
Department line at 1-800-824-0524 from 8 am to 5 pm (Eastern Time) for warranty,
service or installation assistance you may need. Thank you.
IMPORTANT SAFETY NOTICE - SAVE THESE INSTRUCTIONS
Please save and read all safety, operating and installation instructions before
installing or applying DC power to your TruePower Inverter.
On Board
Solutions
A ProMariner Company
Heavy Duty Marine / Industrial Grade
Owner Manual & Installation Guide
Description
Advertisement
Table of Contents
Related Manuals for ProMariner TruePower Inverter Series
Summary of Contents for ProMariner TruePower Inverter Series
- Page 1 ® A ProMariner Company A ProMariner Company Heavy Duty Marine / Industrial Grade Visit ProMariner Online at www.promariner.com, for a Complete Selection of Quality Marine Products... TruePower Inverter Series Here are just a few: 200 - 400 Watt Portable Models ProMite Series - Standard Edition Waterproof Marine Battery Chargers ProSport Series - Recreational Sport Fishing &...
- Page 2 Customer Service & Warranty... page 16 Introduction Thank you from all of us at On Board Solutions, A ProMariner Company. Congratulations on your recent purchase of a TruePower Inverter! Leading the Marine industry in Power Conversion for over 30 years, ProMariner’s On Board Solutions division has designed a complete line of Power Inverters ranging from 200 to 3,000 watts specifically for Marine / Industrial use.
-
Page 3: General Safety Instructions
S a f e t y & P r e c a u t i o n s Notes General Safety Instructions Before installing and using your new inverter, read all appropriate sections of this guide and any cautionary markings on the inverter, batteries and on your appliances. 1. -
Page 4: Preparing For Installation
WARNING: Do not mount the inverter above or below your batteries. WARNING: Electrical shock and fire hazards On Board Solutions, a ProMariner Company recommends all wiring be done by qualified personnel. Disconnect all AC and DC power sources to prevent accidental shock. -
Page 5: Guide To Operation
The GFCI is a standard off the shelf serviceable / replaceable Install your TruePower Inverter to the guidelines recommended in this manual. The component in the TruePower Inverter Series. Please contact Customer Service for additional assistance. TruePower Inverter is designed to meet UL 458, CE and ABYC standards. -
Page 6: Specifications
IMPORTANT: ALWAYS PLACE THE INVERTER IN AN ENVIRONMENT WHICH IS: for 200w for 400w AGU Fuse Holder (A) WELL VENTILATED ProMariner Part No. for Recommended 88103 88530 88540 (B) NOT EXPOSED TO DIRECT SUNLIGHT OR HEAT SOURCE User Supplied ABYC E-11 Compliant Fuse... - Page 7 I n s t a l l a t i o n G u i d e l i n e s Tr o u b l e s h o o t i n g Mounting your Inverter Continued Power tool operates at incorrect speed Possible Cause: Fuses:...
-
Page 8: Battery Operating Time
Tr o u b l e s h o o t i n g I n s t a l l a t i o n G u i d e l i n e s Mounting your Inverter with Optional Brackets Fan does not turn on. -
Page 9: Dc Wiring Options
I n s t a l l a t i o n G u i d e l i n e s Tr o u b l e s h o o t i n g DC Wiring Options No AC output voltage. Red Fault LED light is illuminated. Figure 1) Possible Cause: TruePower... -
Page 10: Troubleshooting
Tr o u b l e s h o o t i n g I n s t a l l a t i o n G u i d e l i n e s / Te s t i n g Yo u r I n v e r t e r Troubleshooting DC Wiring Options Continued 11. -
Page 11: Operation
I n s t a l l a t i o n G u i d e l i n e s / O p e r a t i o n O p e r a t i o n Testing of the GFCI Operation Continued Light...
