Page 1: Operation Manual
AudiaVOIP Operation Manual July 2012 Biamp Systems, 9300 SW Gemini Drive, Beaverton, Oregon 97008 U.S.A. (503) 641-7287 www.biamp.com... -
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 10) Protect the power cord from being walked on or pinched particularly at plugs, 2) Keep these instructions. convenience receptacles, and the point 3) Heed all warnings. where they exit from the product. 4) Follow all instructions. -
Page 3: Table Of Contents
AUDIAVOIP SPECIFICATIONS . . . . . . . . . . . . . . . . . . . -
Page 4: Audiavoip
AudiaVOIP AudiaVOIP AudiaVOIP is a dedicated version of AudiaFLEX NC, the benchmark in digital audio systems for demanding professional sound installations. AudiaVOIP provides the same easy- to- use software and functional algorithms, available in AudiaFLEX with the added ease of a predefined fixed I/O configuration and factory loaded DAP file optimized for VoIP teleconferencing. -
Page 5: Rear Panel
ORANGE connectors = AEC INPUTS GREEN connectors = INPUTS AudiaVOIP comes preconfigured with 4 mic/line inputs, 12 AEC inputs, 4 line outputs, 2 amplified outputs and 2 VoIP lines. The device comes preloaded with a default software configuration file that is able to be customized to meet a wide range of applications. -
Page 6: Example Configuration
Audio outputs to video codecs interface (Sona AEC Processing removes all echo • Interface to external from audio delivered to far end) control systems • Interface to Biamp controllers, daVinci, RED-1 Audio outputs to recorders, or iPad Dialer App external amplifiers, etc. RED-1 Control Network Two 30W speaker circuits. -
Page 7: Connecting To A Networked System
3 . Assign an IP address to the PC. The PC must have a unique IP address before it can communicate with an Audia device. Please note that AudiaVOIP does not support DHCP or Zero Conf (Link Local) addressing. Windows XP users: Go to Control Panel >... - Page 8 CONNECTING TO A NETWORKED SYSTEM The Local Area Connection Status Dialog will open. Select Properties. The Local Area Connection Properties Dialog will open. Double-Click Internet Protocol Version 4 (TCP/IPv4).
- Page 9 CONNECTING TO A NETWORKED SYSTEM The Internet Protocol Version 4 (TCP/IPv4) Properties will open. Update the IP address and Subnet mask to the same range as the AudiaVOIP default. The IP address should be 192.168.1.x (x=1-254). Subnet mask should be 255.255.255.0.
- Page 10 6. Connect the Audia device to the network. Direct connection: Attach a “crossover” Ethernet cable from the PC’s 10/100 Base-T network card to the AudiaVOIP Ethernet port. You can easily determine if an Ethernet cable is a “crossover” by looking at the conductors on the RJ-45 connectors.
- Page 11 CONNECTING TO A NETWORKED SYSTEM 8. Connect to the network with Audia software. Open the Audia software. Connect to the network by going to File > Network > Connect to network. Select the required device listed in the System List and press Connect to System. The software will connect and allow real time user control.
-
Page 12: Assigning Different Ip Addresses
IP address. Audia device IP addresses must be different from any IP address that will be used in this system. AudiaVOIP does not support DHCP or Zero Conf (Link Local) addressing. -
Page 13: Audiavoip Specifications
Compliance: 8kΩ AES48-2005 Grounding & EMC practices EU Directive 2002/95/EC, RoHS directive Maximum Output (balanced): +24dBu CE marked UL / C-UL listed Maximum Input (mic/line): +24dBu AudiaVOIP BLOCK DIAGRAM AudiaFLEX BLOCK DIAGRAM TCP/IP Remote Control Control RS-232 Comms MicroProcessor CobraNet... -
Page 14: Warranty
9. Biamp systems shall not be liable for special, indirect, incidental, or consequential damages, including lost profits or loss of use arising out of the purchase, sale, or use of the products, even if BIAMP Systems was advised of the possibility of such damages. -
Page 15: Fcc Compliance
FCC COMPLIANCE FCC NOTICE - CLASS B DIGITAL DEVICE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in either a residential or commercial installation. -
Page 16: Ec Declaration
DIRECTIVES below except as noted herein. Any alterations to the product not agreed upon and directed by Biamp Systems Corporation will invalidate this declaration. ®... -
Page 17: Eu Rohs Compliance
COMPLIANCE RoHS COMPLIANT This Biamp product, including all attendant cables and accessories supplied by Biamp, meets all requirements of EU Directives 2002/95/EC of January 27, 2003, and 2005/618/EC of August 18, 2005, the EU RoHS Directives. An EU RoHS Materials Content Declaration document may be obtained at www.biamp.com...
