AOC 931Fwa User Manual

AOC 931Fwa User Manual

481mm tft color lcd monitor
Hide thumbs

Advertisement

Quick Links

AOC MONITOR
USER`S GUIDE
931Fwa
SAFETY INTRODUCTION......................................................................2
SETUP.................................................................................................4
ADJUSTING...........................................................................................7
DRIVER INSTALLATION GUIDE...........................................................23
PRODUCT INFORMATION...................................................................25
TROUBLESHOOT.................................................................................28
١
|
P a g e

Advertisement

loading
Need help?

Need help?

Do you have a question about the 931Fwa and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AOC 931Fwa

Summary of Contents for AOC 931Fwa

  • Page 1: Table Of Contents

    AOC MONITOR USER`S GUIDE 931Fwa SAFETY INTRODUCTION…………………………………………………………….2 SETUP…………………………………………………………………………………….4 ADJUSTING…………….…………………………………………………...…………...7 DRIVER INSTALLATION GUIDE…………………….….…………………………23 PRODUCT INFORMATION………………………………………………………….25 TROUBLESHOOT……...………………………………………………………….…..28 ١ P a g e...

  • Page 2: Safety Introduction

    SAFETY INTRODUCTION FCC Notice FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3 PRECAUTIONS • Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement. • Do not place the monitor on an unstable cart, stand, or table. If the monitor falls, it can injure a person and cause serious damage to the appliance.

  • Page 4: Setup

    SETUP Setup the stand and base Please setup or remove the base following below steps. Adjusting Viewing Angle • For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor's angle to your own preference.
  • Page 5 Attaching the Cables Cable Connections On Back of Monitor and Computer 1. Power 2. Audio 3. Analog Turn off your computer before performing the procedure below. Connect the power cable to the AC port on the back of the monitor. Connect one end of the 15-pin D-Sub cable to the back of the monitor and connect the other end to the computer's D-Sub port.
  • Page 6 Reconnect the cables. Refer to the user's manual that came with the optional wall mounting arm for instructions on attaching it to the wall. Noted : VESA mounting screw holes are not available for all models, please check with the dealer or official department of AOC. ۶ P a g e...

  • Page 7: Adjusting

    Adjusting Setting the Optimal Resolution The recommended resolution for this monitor is 1440 by 900. To setup the monitor to this resolution, follow the steps below. Click START. Click SETTINGS. Click CONTROL PANEL. Double click DISPLAY. Click SETTINGS. Set the resolution SLIDE-BAR to 1440 by 900. External Controls Press the power button to turn the monitor on or off.
  • Page 8 • Eco Mode hot key : Press the Eco key continuously to select the Eco mode of brightness when there is no OSD ( Eco mode hot key may not be available in all models). • Volume adjustment hot key : When there is no OSD , press Volume (+) to active volume adjustment bar, press - or + to adjust volume ( Only for the models with speakers).
  • Page 9 What is DCB? Dynamic Color Boost (DCB) is an advanced color adjustment technology. Through analyzing RGB signals, DCB creates more vivid and natural images to suit various color environment needs. DCB has two types of color enhancers: “Color Boost” and “Picture Boost” . DCC: Dynamic color control ICM: Intelligent color management 1) How to use Color Boost?
  • Page 10 Nature Skin: When "Natural Skin" is turned on, the red and yellow colors are enriched automatically, thus presents human skin with more natural and truer colors. "Natural Skin" setting is ideal for viewing human portrait and detailed skin texture. Green Field: When "Green Field" is turned on, the green color is enriched so that football field and mountain landscape would look more natural and fresh.
  • Page 11 Sky Blue: When"Sky Blue" is turned on, the color blue is being fine-tuned so that the sky or ocean landscape will look more vivid and in-depth. "Sky Blue" setting is ideal for viewing sky and ocean images. Auto Detect: When “Auto Detect” is turned on, every pigment will be detected and self-adjusted to render a lively picture. Demo: Screen divided into two for demonstration purposes.
  • Page 12 DCR Adjustment What is DCR? Dynamic Contrast Ratio (DCR) auto adjusts the brightness of the screen so users can see the darker areas of the displayed content in more depths. By increasing the darkness of the dark areas and the brightness of the bright areas, contrast ratio is uplifted to exceed 60000:1.
  • Page 13 Function Control Illustration Luminance Adjust Range Description Brightness 0-100 Backlight Adjustment Contrast 0-100 Contrast from Digital-register. Standard Mode Standard Text Mode Text Internet Mode Eco mode Internet Game Mode Game Movie Mode Movie Sports Mode Sports Gamma1 Adjust to Gamma1 Gamma Gamma2 Adjust to Gamma 2...
  • Page 14 Red Gain from Digital-register User Green Green Gain Digital-register. Blue Blue Gain from Digital-register Color Boost Disable or Enable Full Enhance Full Enhance on or off Mode Disable or Enable Nature Skin Nature Skin on or off Mode Disable or Enable Green Field Green Field on or off Mode...
  • Page 15 Orange or red How to use i-menu software Installation Welcome to use “i-menu” software by AOC. i-menu makes it easy to adjust your monitor display setting by menus on the screen instead of OSD button on the monitor. Please click here to setup the software.
  • Page 16 Luminance Adjust Range Description Contrast 0-100 Contrast from Digital-register. Brightness 0-100 Backlight Adjustment Standard Mode Standard Text Mode Text Internet Mode Eco mode Internet Game Mode Game Movie Mode Movie Sports Mode Sports Gamma1 Adjust to Gamma1 Gamma Gamma2 Adjust to Gamma 2 Gamma3 Adjust to Gamma 3 Disable dynamic contrast ratio...
  • Page 17 2. Image setup Image Setup Adjust Range Description Adjust picture Clock to reduce Vertical- Clock 0-100 Line noise. Adjust Picture Phase to reduce Horizontal- Phase 0-100 Line noise H.Position 0-100 Adjust the verticalposition of the picture. V.Position 0-100 Adjust the horizontal position of the picture. Reset Reset the current page ١٧...
  • Page 18 3. Color Temperature Color Temp. Adjust Range Description Recall Warm Color Temperature from Warm EEPROM. Recall Normal Color Temperature from Normal EEPROM. Preset Recall Cool Color Temperature from Cool EEPROM. Recall SRGB Color Temperature from sRGB EEPROM. Red Gain from Digital-register User Green Green Gain Digital-register.
  • Page 19 4. Color Boost Color Boost Adjust Range Description Full Enhance on or off Disable or Enable Full Enhance Mode Nature Skin on or off Disable or Enable Nature Skin Mode Green Field on or off Disable or Enable Green Field Mode Sky-blue on or off Disable or Enable Sky-blue Mode...
  • Page 20 5. Picture Boost Picture Boost Adjust Range Description Bright Frame on or off Disable or Enable Bright Frame Frame Size 14-100 Adjust Frame Size Brightness 0-100 Adjust Frame Brightness Contrast 0-100 Adjust Frame Contrast H. position Adjust Frame horizontal Position 0-100 V.position 0-100...
  • Page 21 6. Setting ٢١ P a g e...
  • Page 22 7. Extra ٢٢ P a g e...

  • Page 23: Driver Installation Guide

    8. Help On this page, you can find the information of the monitor . Welcome to link our website and send email to us if you have any problem. Compatibility : i-menu supports major graphic cards of ATI, Nvidia, Intel, VIA(S3). Please contact with us if your graphic card was not supported i-menu software.
  • Page 24 Windows ME 1. Start Windows® Me 2. Click on the 'Start' button, point to 'Settings', and then click on 'Control Panel'. 3. Double click on the 'Display' Icon. 4. Select the 'Settings' tab then click on 'Advanced...'. 5. Select the 'Monitor' button, then click on 'Change...' button. 6.

  • Page 25: Product Information

    0~ 5000m (0~ 15000 ft ) EPA ENERGY STAR ® ENERGY STAR® is a U.S. registered mark. As an ENERGY STAR® Partner, AOC International (Europe) GmbH has determined that this product meets the ENERGY STAR® guidelines for energy efficiency. ٢۵...
  • Page 26 Preset Display Modes HORIZONTAL VERTICAL STAND RESOLUTION FREQUENCY(kHz) FREQUENCY(Hz) ۴٠٠ ‫،ء‬ Dos-mode 31.47 ۴٨٠ ‫،ء‬ 31.47 ۴٨٠ ‫،ء‬ 37.5 ۶٠٠ ‫،ء‬ SVGA 37.879 ۶٠٠ ‫،ء‬ SVGA 46.875 ٧۶٨ ‫،ء‬ 1024 48.363 ٧۶٨ ‫،ء‬ 1024 56.476 ٧۶٨ ‫،ء‬ 1024 60.02 ٧۶٨ ‫،ء‬...
  • Page 27 Pin No. Signal Name Pin No. Signal Name Pin No. Signal Name TMDS Data 2- TMDS Data 1- TMDS Data 0- TMDS Data 2+ TMDS Data 1+ TMDS Data 0+ TMDS Data 2/4 Shield TMDS Data 1/3 Shield TMDS Data 0/5 Shield TMDS Data 4- TMDS Data 3- TMDS Data 5-...

  • Page 28: Troubleshoot

    Also check the monitor's video cable and make sure none of the pins are bent. No Plug & Play • Make sure the AOC Monitor Drivers are installed (AOC Monitor Drivers are available at : http://www.aoc.com) • Adjust the Contrast and Brightness Controls.
