Summary of Contents for Audio Technica SpectraPulse chg004
- Page 1 SpectraPulse ® Ultra Wideband Wireless Microphone System Charger for SpectraPulse Transmitters chg004 ®...
- Page 2 DANGER - This charger is designed only for NiMH rechargeable batteries. To avoid personal injury and damage, do not attempt to charge alkaline batteries or any other rechargeable batteries besides NiMH. WARNING - To prevent fire or shock hazard, do not expose this product to drips or splashes. - To prevent fire, do not place any naked flame sources (such as lighted candles) on the product.
- Page 3 ® Metal Hydride (NiMH) batteries. The 4 charging bays hold either mtu101 Microphone Transmitters or mtu201 XLR Desk Stand Transmitters. The chg004 can also charge up to two mtu301 units. Charger features • Batteries are charged within the SpectraPulse Transmitters.
- Page 4 2. Install the included NiMH AA batteries in each transmitter, observing correct polarity as marked inside the transmitter. 3. Plug the DC cable from the included wall-adapter power supply into the rear of the chg004; plug the other end of the power cord into a standard wall outlet.
- Page 5 For installation instructions, see the mtu301 operation manual. 3. Plug the DC cable from the included wall-adapter power supply into the rear of the chg004; plug the other end of the power cord into a standard wall outlet.
- Page 6 Charger 1. Power Supply The chg004 Charger operates via the included safety-approved IEC power supply for connection to 110/240V AC 50/60Hz power. You must change to an approved power supply for operation in non-U.S. locations. 2. Recharging Stations All four bays in the chg004 function as recharging stations.
-
Page 7: Specifications
Specifications Input rating 12 VDC, 5A (max) Charging time Approx. 4 hours (2700 mAh Ni-MH) Dimensions 416.05 mm (16.38") W x 196.85 mm (7.75") D x 40.64 mm (1.60") H Weight 1.02 kg (2.25 lbs) Included accessories 8 - 2700 mAh NiMH AA batteries * Specifications are subject to change without notice. - Page 8 Audio-Technica U.S., Inc. 1221 Commerce Drive, Stow, Ohio 44224 (330) 686-2600 www.audio-technica.com P13491 ©2013 Audio-Technica U.S., Inc.
