- Page 1 S O N A R R AY S R 1 S Y S T E M I N S T R U C T I O N M A N UA L...
-
Page 2: Box Contents
Satellite Speaker In-Ground Subwoofer Speaker Layout Planning The SONARRAY SR1 SYSTEM is designed to deliver a seamless, The satellites in the SONARRAY SR1 SYSTEM individually present evenly dispersed sound field in an ‘open air’ environment. An a 30 ohm load to the amplifier. When 4 of them are connected... -
Page 3: Speaker Installation
DISTANCE Connecting the Speakers 18 Gauge Up to 100 feet (30 meters) The SONARRAY SR1 SYSTEM allows the satellite speakers to 16 Gauge Up to 150 feet (45 meters) be wired together in a parallel-daisy chain configuration. In a typical system with one zone of audio, simply run a 4 conductor... - Page 4 S O N A R R AY S R 1 S Y S T E M I N S T R U C T I O N M A N UA L Recommended tools you will need Satellite Wire Connection Wire Strippers that will accommodate up to Connecting the speakers using 14/4 direct burial 12 gauge wire.
- Page 5 Use a wire tie to keep the wire loop intact and act as a Strip off 1 inch (25.4mm) of insulation on Red and Black wires strain relief. to expose the copper conductor. Combine and twist the Red wires from the amplifier, the first satellite and the wire run running to the next speaker in a clock-wise motion.
- Page 6 S O N A R R AY S R 1 S Y S T E M I N S T R U C T I O N M A N UA L Repeat steps 6 & 7 for the black wires. Cut the wire at the last speaker location in the daisy-chain.
-
Page 7: Subwoofer Wire Connection
Subwoofer Wire Connection After all satellites and subwoofer connections are completed, connect the wires to your receiver or amplifier. See Figure 2 (on The subwoofer features a dual voice coil driver with 4 wires, one page 3) & Figure 4 for reference. pair for each of the amplifier channels. - Page 8 (e.g. overdriving the amplifier or speaker, excessive heat or cold or humidity, outdoor installation), or from service or repair which has not been authorized by Sonance. Obtaining Authorized Service: To qualify for the warranty, you must...
