Summary of Contents for Sealife Sea Dragon 2000 Light
-
Page 2: Table Of Contents
X. Expanding your Flex-Connect™ Lighting System ..13-14 XI. Recommended Camera Settings ........15 XII. Great pictures made easy ........16-19 XIII. Advanced Settings .............20 XV. Troubleshooting Guide ..........21 XVI. Specifications ............22 XVII. Parts and Service ............23 www.sealife-cameras.com/service/manuals.html Español - Deutsch - Français - Italiano - Nederlands... -
Page 3: Safety Warnings
Replace the o-rings and apply lube. Install new, fully-charged battery and test light. If light does not operate properly, please contact your local SeaLife dealer or the SeaLife service center in your country. -
Page 4: I. Safety Warnings
Only use the specified battery and battery charger approved by SeaLife. Using any other battery or charger may cause fire, injury and permanently damage the light. -
Page 5: Check What You Got
II. Check What You Got Sea Dragon 2000 Light (with grip and standard tray) -OR- Sea Dragon 1200 Light (with grip and micro tray) Li-ion Battery (SL9831) w/protective cover O-ring Lube (SL9807) Charging tray (SL98311) Sea Dragon Case (Small SL941 or Large SL942) -
Page 6: Product View With Call-Outs
III. Product view with call-outs Major parts 1 – Light head 2 – Metal cooling bezel 3 – Release buttons 4 – Flex-Connect grip 5 – Tray 6 – Mounting screw 7 – Rubber friction pad 8 – Power button / Brightness adjust 9 –... -
Page 7: Charging And Loading The Battery
IV. Charging and Loading the Battery 1) Charge battery (green light = fully charged) 2) Unscrew the battery cap 3) Insert fully charged battery. Important: Make sure O-ring and sealing surfaces are perfectly clean and undamaged. 4) Screw on battery cap. (Do not overtighten or use tools.) -
Page 8: Operating The Light
V. Operating the light 1) Push and hold the power button for 1 second to power ON the light. 2) Push the power button to change between the following light modes: 100% § 50% § 25% § 100%..3) Push and hold the mode button for 2 seconds to power OFF the light. -
Page 9: Maintaining A Waterproof Seal (Before Your Dive)
O-rings. Wipe off excess lubricant. The o-ring surface should have shiny, wet appearance. Important: Replace O-rings every year if damaged or not. Visit your local SeaLife dealer or www.sealife-cameras.com for information on ordering spare o-rings. -
Page 10: Care And Maintenance (After Your Dive)
VIII. Care and maintenance (After your dive) 1) After each dive, soak the sealed light in fresh water for about 15 minutes to remove any residual salt, sand and dirt. Never allow the saltwater to dry on the light. 2) Push the power button about 10 times to clean any saltwater or sand trapped under the button. -
Page 11: Replacing The O-Rings
IX. Replacing the O-rings Replace the two O-rings if damaged or at least once per year. 1) Use the O-ring Remover tool provided to lift and remove the O-rings. 2) Carefully clean O-ring grooves and O-rings before installation 3) Install O-rings by stretching and lifting O-ring into the groove. -
Page 12: Attaching Light To Underwater Camera
X. Attaching light to underwater camera Important: Only attach the light to cameras/housings with minimum thread depth of 0.28" and using standard 1/4-20 tripod type thread. Don’t over-tighten screw or you may damage the housing and threads. Align the underwater camera to the light’s mounting screw and hand-tighten. -
Page 13: Expanding Your Flex-Connect™ Lighting System
XI. Expanding your Flex-Connect™ Lighting System Get brighter, more colorful results by expanding your Sea Dragon underwater camera system. The modular Flex-Connect arms, grips and trays easily clicks together to create these popular configurations: Pro Set Pro Duo Maxx Duo w/ single flash w/ light, flash and w/ light, flash, 2 flex... - Page 14 Cold Shoe – Mount a light or flash over the camera for the most compact lighting solution available. Or use it to add a third light when using a dual tray. Easily slides on to cold shoe of SeaLife and most other underwater housings. (SL991).
-
Page 15: Recommended Camera Settings
XII. Recommended Camera Settings For SeaLife camera with external light accessory (No external flash): 1) Set the camera’s scene mode to Sea mode or Snorkel mode 2) Change camera’s PHOTO and VIDEO White Balance settings to DAYLIGHT. For SeaLife camera with external light and flash accessories: 1) Set the scene mode to Ext. -
Page 16: Great Pictures Made Easy
XIII. Great pictures made easy There are plenty of challenges that photographers face in the underwater world. Please take some time to review SeaLife’s online guide called Great Pictures Made Easy by visiting www.sealife-cameras.com. The guide is located under the Technical Support menu. - Page 17 SeaLife underwater light in combination with the SeaLife flash, limit your shooting distance to 6 ft (1.8m). 4 ft (1.2m) is ideal. If you are using the SeaLife light only, limit your shooting distance to 2 ft (60cm) to 3ft . Closer shooting distances result in better pictures and video.
- Page 18 Control your buoyancy Get your buoyancy under control and set yourself up in the ideal position before taking a picture or shooting video. This allows you to hold the camera steady and control your shooting distance. Good buoyancy control will help you avoid stirring up the sandy bottom which will cloud-up the water and cause backscatter.
- Page 19 Compose a good picture Avoid shooting down on the subject from above. Shooting down usually results in a poor contrast because the subject blends into the background. Try and shoot upwards from below the subject so you get a blue water background and better contrast. Get the entire subject into your picture frame.
-
Page 20: Advanced Settings
XIV. Advanced Settings Auto Flash Detect The light includes a flash sensor that will turn off the light for 2 seconds if it detects an external flash firing. This feature helps reduce backscatter. You may disable the auto flash detect as follows: 1) With light in the OFF state, push and hold the power button for 3 seconds. -
Page 21: Troubleshooting Guide
The camera’s white balance setting is not set correctly. Refer to page 15 of this manual for information on camera settings. For updated information and advice, please refer to the SeaLife website at www.sealife-cameras.com or contact your local SeaLife dealer or service center for help. -
Page 22: Specifications
XVI. Specifications Sea Dragon 1200 (item SL983) Light source/ Bulb type: 6 x 3W LED Light (CREE XPG LEDs) Brightness: 1200 lumens Effective Range: 3 ft / 1m (depend on camera model, water visibility and battery condition) Run [Burn] time: 75 minutes at full power/150 min at half power/300 min at quarter power Sea Dragon 2000... -
Page 23: Parts And Service
XVII. Parts and Service SeaLife guarantees the original purchaser of this product, for a period of one (1) year from the date of purchase, that the product is free from defects in workmanship and materials. For a detailed warranty statement, please refer to the warranty information included with the product.
