- Page 1 SVAT ELECTRONICS SVAT ELECTRONICS now you can see HANDS FREE 2-WIRE COLOR VIDEO INTERCOM SYSTEM w/ 7" LCD Monitor and Night Vision Security Camera COMPLETE SYSTEM Instruction Manual Model # VIS300-7M2 www.svat.com...
- Page 2 This warranty does not cover shipping costs, insurance, or any other incidental charges. You MUST call SVAT before sending any product back for repair. You will be sent a Return Authorization form with return instructions. When returning the product for warranty service, please pack it carefully in the original box with all supplied accessories, and enclose your original receipt or copy, and a brief explanation of the problem (include RA #).
-
Page 3: Table Of Contents
SVAT ELECTRONICS TABLE OF CONTENTS now you can see WHAT IS INCLUDED ........................2 IMPORTANT SAFETY PRECAUTIONS ....................3 FEATURES ..........................4 BUTTON FUNCTIONS AND CONNECTIONS ...................5 7" LCD MONITOR .....................5 CAMERA/DOORBELL ....................5 WIRING INSTRUCTIONS ......................6 CONNECTION 1 ......................6 CONNECTION 2 ......................7 MONITOR INSTALLATION ......................9 WALL MOUNTING ....................9... -
Page 4: Important Safety Precautions
IMPORTANT SAFETY PRECAUTIONS SVAT ELECTRONICS now you can see PLEASE READ BEFORE INSTALLING • When cleaning, use a DRY, lint-free cloth. Unplug the camera, monitor and AC/DC adapters before cleaning. NEVER immerse any components in water and do not spray cleaners or solvents on the units. Doing so may damage the units or cause electrical shock. -
Page 5: Features
FEATURES Fast & Hassle-Free Setup SVAT's video intercom system is incredibly easy to set up and use. It can work with your existing door bell wiring, so you can connect everything yourself within minutes (50ft cable included). See and Hear Everything with Audio & Video Enjoy the safety of monitoring your entrance and being able to carry on conversations without ever having to open the door to strangers. -
Page 6: Button Functions And Connections
BUTTONS AND CONNECTIONS SVAT ELECTRONICS now you can see 7" LCD Monitor 10. Volume – Controls the speaker volume Microphone on the monitor Power Supply Indicator LED 11. Chroma – Controls color of image 7"LCD Screen 12. Brightness – Controls brightness... -
Page 7: Wiring Instructions
SVAT ELECTRONICS WIRING INSTRUCTIONS now you can see Connection 1 (Recommended) Connecting the Camera – Note: You will need a philips head screwdriver • Loosen the screw to the camera’s positive connection (marked 1) by turning the screw counter clockwise. Note: Do not fully unscrew the screw, just loosen it enough to fit the horseshow end of the 50ft wires. -
Page 8: Connection 2
Connecting the electric Doorstrike to Monitor (Doorstrike and Wiring not Included) The VIS300-7M2 does not come with an electric door strike (lock), if you would like to connect a door strike. The door strike must run off a 8-16 VAC power supply to be compatible with the VIS300-7M2. - Page 9 WIRING INSTRUCTIONS CONT..SVAT ELECTRONICS now you can see Connecting the Camera – Note: You will need a philips head screwdriver • Unscrew the screw from the camera’s positive connection (marked 1). Note: Do not fully unscrew the screw, just loosen it enough to fit the horseshow end of the 50ft wires.
-
Page 10: Monitor Installation
MONITOR INSTALLATION AND OPERATION SVAT ELECTRONICS now you can see WALL MOUNTING Locate a desired mounting location for the camera/ doorbell station and fasten the mount using the included mounting hardware. - Make sure the mounting location is at an... -
Page 11: Camera Installation
Angled Camera Mount – Must be Mounted BEFORE Flat Mount The VIS300-7M2 has two identical angled mounts included with it so that you can place your camera on a twenty degree angle or a 40 degree angle. This will make the camera angled towards the door instead of straight ahead. -
Page 12: Flat Surface Mount
CAMERA INSTALLATION AND OPERATION CONT... SVAT ELECTRONICS now you can see Flat surface mount Lift up sticker located on the front of the camera on right side. 2. Completely remove the screw from the flat surface mount. Remove camera from mount (it is held in by plastic tabs, you may have to apply some force to separate the two pieces) Locate a desired mounting location. -
Page 13: General Information
BUTTON OPERATIONS CONT..SVAT ELECTRONICS now you can see Chroma: Adjusting the Chroma knob will allow you to adjust the intensity of the color in the picture on the monitor. The higher you adjust, the more intense the color will be. Brightness: Adjusting the brightness will make the picture brighter or darker on the monitor. The brighter it is where your camera is, the lower you should adjust the brightness. GENERAL INFORMATION To operate the camera, press and release the doorbell button on the camera. The chime will ring on the inside monitor and the monitor screen will display the audio and video from the camera. -
Page 14: Specifications
SVAT ELECTRONICS TROUBLESHOOTING CONT... now you can see Door Strike not Functioning • Door not unlocking – Make sure you have it wired to an electric door strike that will operate with 15 VAC (doorstrike NOT included) • Make sure that all the connections are secure and properly connected No one can hear me outside but I • Make sure all the connections are set up properly and securely can hear them • Make sure you are not pressing the ‘... - Page 15 SPECIFICATIONS CONT... SVAT ELECTRONICS now you can see LCD MONITOR Operating Humidity <80% Dimensions (with 6.5” x 3.9” x 0.3” Display 7" TFT LCD stand) Resolution 1440 x 86.58 mm Weight (with stand) 1. 25 Lbs Source of Light Door Strike Compatable Yes.
-
Page 16: Notes Area
NOTES AREA SVAT ELECTRONICS now you can see... - Page 17 NOTES AREA SVAT ELECTRONICS now you can see...
- Page 18 Disclaimer SVAT does not endorse any of SVAT products for any illegal activities. SVAT is not responsible or liable in any way shape or form for any damage, vandalism, theft or any other action that may occur while a SVAT product is in use by the purchaser.
