Summary of Contents for SVAT VISS7500
- Page 1 SVAT ELECTRONICS now you can see COLOR 5" TFT-LCD 2 WIRE VIDEO INTERCOM SYSTEM COMPLETE SYSTEM Instruction Manual Model # VISS7500 www.svat.com...
- Page 2 Website: www.svat.com Warranty Terms SVAT products are guaranteed for a period of one year from the date of purchase against defects in workmanship and materials. This warranty is limited to the repair, replacement or refund of the purchase price at SVAT's option.
-
Page 3: Table Of Contents
1 Camera 60’ Extension Wire 1 RCA Output 1 Metal Mounting 1 Power Adapter Bracket Converter WHAT IS COMPATIBLE The VISS7500 is compatible with TVs, VCRs, DVRs, computers and other SVAT systems including: VISS7500M ClearVu DVRs Any TV or VCR VISS7500... -
Page 4: Important Safety Precautions
SVAT ELECTRONICS now you can see IMPORTANT SAFETY PRECAUTIONS PLEASE READ BEFORE INSTALLING • Keep the camera, monitor and AC/DC adapter cords out of reach of children. • Do not place the camera, monitor and AC/DC adapter cords in a crib or playpen. -
Page 5: Features
SVAT ELECTRONICS now you can see FEATURES • Sleek and ultra thin monitor design • Two wire connection allows you to use the existing wire from your doorbell for easy installation • 5" TFT-LCD color screen • Two way communication •... -
Page 6: Things To Consider
SVAT ELECTRONICS now you can see THINGS TO CONSIDER BEFORE INSTALLATION • Do not place the intercom system near strong magnetic fields, such as televisions and video recorders. • Turn off the video intercom system power if not in use for extended periods of more than two days;... -
Page 7: Wiring Diagram
SVAT ELECTRONICS now you can see WIRING DIAGRAM DISCONNECT THE POWER BEFORE CONNECTING/DISCONNECTING THE WIRES. FAILING TO DO SO COULD RESULT IN PERSONAL INJURY OR PERMANENT DAMAGE TO YOUR INTERCOM SYSTEM. Monitor Camera Doorstrike (Not Included) Important Notes • Wires are color coded and are NOT interchangeable. -
Page 8: Monitor Installation & Operation
SVAT ELECTRONICS now you can see MONITOR INSTALLATION & OPERATION AC: 110 ~ 240V The optimum height of the monitor for installation is Take two screws and fix the support of 145cm ~160cm from the center of the pick-up tube of the wall-mount on the wall and then the monitor to the ground. -
Page 9: Camera Installation & Operation
SVAT ELECTRONICS now you can see CAMERA INSTALLATION & OPERATION POSITIONING Standard Height Move it up of Camera Horizontal angle Move it down of the camera LOCATION Keep the camera away from direct sunlight or any other bright light sources. -
Page 10: Specifications
SVAT ELECTRONICS now you can see SPECIFICATIONS SYSTEM Number of Wires ......2 Max. Number of Doorstations ..1 Max. Number of Monitors ....1 Communication ........Full Duplex Image Memory ........No Door Chime........Ding Dong Sound, 2 times Door Strike ........12V for 5 seconds Maximum Wiring Distance ....300ft... - Page 11 SVAT ELECTRONICS now you can see MONITOR Screen Size........5 Inch Screen Type ........LCD Resolution ........960 x 234 Speaker..........Yes Input Terminal ........Wire Type A/V Out Terminal......Yes, Composite Video On/Off Button? ......Yes Adjustable Contrast......Yes Adjustable Brightness ......Yes Operating Temperature ....5ºF ~ 122ºF Operating Humidity ......80%...
- Page 12 SVAT ELECTRONICS now you can see T SUPPORTS CRIME ST OPPERS T SUPPORTS CRIME ST OPPERS Crime Stoppers programs are operated as non-profit charities and are managed by a volunteer board of directors who raise funds and pay rewards to individuals who anonymously call with information that helps solve crime.
- Page 13 SVAT ELECTRONICS now you can see T SUPPORTS CRIME ST OPPERS T SUPPORTS CRIME ST OPPERS To receive more information about Crime Stoppers or to make a charitable donation please fill in the fields below, cut on the dotted line and mail in.
- Page 14 SVAT ELECTRONICS now you can see w w w. s v a t . c o m D i s c l a i m e r S VAT d o e s n o t e n d o r s e a n y o f S VAT p r o d u c ts f o r a n y i l l e g a l a c t i v i t i e s .
