Nvidia Quadro FX 540 Specification

QuickSpecs
Overview
Models Models Models Models
NVIDIA Quadro FX 540 PCI-Express graphics card kit.
Includes: PCA with ATX bracket, DVI to VGA converter, CD and manual.
Introduction Introduction Introduction Introduction
Designed for entry level professional 3D applications, the NVIDIA Quadro FX 540 delivers on value without compromising on
quality, precision, performance, and programmability. The Quadro FX 540 provides all the Quadro FX family's advanced features,
benefits and certifications on a wide set of CAD, DCC, and scientific visualization applications, plus support for HD component
output. The NVIDIA Quadro FX 540 features 128 MB DDR memory, 128-bit memory interface and 8.8 GB/s memory bandwidth.
Performance & Features Performance & Features Performance & Features Performance & Features
Features include a unified memory architecture, which dynamically allocates memory between graphics subsystems. Lightspeed
Memory Architecture (LMA) II optimally load balances across NVIDIA's patented crossbar memory controller, resulting in maximum
memory bandwidth utilization. Other features include:
128 MB DDR
Single DVI, single VGA, and HD component output
Third-generation pixel and vertex programmability
128-bit IEEE floating-point precision graphics pipeline
128-bit color precision
12-bit sub-pixel precision
65,536 fragment instruction/65,536 vertex instruction
3D volumetric textures
Hardware OpenGL overlays
Hardware accelerated antialiased points and lines
Hardware accelerated two-sided lighting
Hardware accelerated clipping planes
3rd generation occlusion culling
Rotated Grid full-scene antialiasing (4x)
Optimized and certified for OpenGL 1.5 and DirectX 9.0c applications
Multi-display productivity
PCIe x16 BUS
Compatibility Compatibility Compatibility Compatibility
The NVIDIA Quadro FX 540 is supported on HP xw4200, xw4300, xw6200, xw8200 and xw9300 Workstations.
Service and Support Service and Support Service and Support Service and Support
The NVIDIA Quadro FX 540 has a one-year limited warranty or the remainder of the warranty of the HP product in which it is
installed. Technical support is available seven days a week, 24 hours a day by phone, as well as online support forums. Parts and
labor are available on-site within the next business day. Telephone support is available for parts diagnosis and installation. Certain
restrictions and exclusions apply.
DA - 12116 North America — Version 5 — August 15, 2005
NVIDIA Quadro FX 540 Graphics Card NVIDIA Quadro FX 540 Graphics Card NVIDIA Quadro FX 540 Graphics Card NVIDIA Quadro FX 540 Graphics Card
PH791A
Page 1
