Hardware Installation
Enclosure Sleeve
Front
Back
FireWire/USB2.0
Encrypt Drive
PHR-100ACE
Back Panel
Front Panel
1. Unscrew to loosen the Back Panel and remove the Back Panel from
the Enclosure.
2. Use your thumb to push the Base Plate out.
