WHAT'S IN THE BOX

The package includes:
• Lantronix UBox USB Device Server
• Power Supply
• Quick Start Guide
• CD with software and User Guide
The Lantronix UBox USB Device Server makes it possible for computers on a Local
Area Network (LAN) to connect and share USB devices such as printers, scanners,
and storage drives. This Quick Start will get you up and running with your new
UBox. For more detailed instructions, please refer to the UBox USB Device Server
User Guide on the product CD or the Lantronix web site.
2
Q u i c k S t a r t G u i d e
U B o x 2 1 0 0 / 4 1 0 0

GETTING STARTED

STEP 1: INSTALL THE HARDWARE
1. Connect the UBox to your network using an RJ45 Ethernet cable.
2. Connect the power supply included in the package to the UBox.
You should now see lights on your UBox.When the
left-most (green) SYSTEM light starts blinking slowly (once every 3 seconds), you are
ready
to install the UBox software.
If you do not see the left-most green SYSTEM light (UBox4100) or SYSTEM 4 LED
(UBox 2100) blinking slowly, please read the detailed troubleshooting
instructions in the User Guide.
Note: Do not connect USB Devices to the UBox until after UBox hardware and
software have been installed.
UBox 2100
Network Power
Connection Supply
W W W . L A N T R O N I X . C O M
UBox 4100
Network
Connection
Power Supply
