Related Manuals for Clarion VRX6570Rz
Summary of Contents for Clarion VRX6570Rz
- Page 1 RADIO mode display COLOR LCD DISPLAY INFORMATION PANEL MAIN RDS mode display COLOR LCD DISPLAY INFORMATION PANEL VRX6570Rz...
- Page 2 CD/MD Changer mode display COLOR LCD DISPLAY INFORMATION PANEL MAIN TV mode display COLOR LCD DISPLAY INFORMATION PANEL MAIN VRX6570Rz...
- Page 3 DAB mode display COLOR LCD DISPLAY INFORMATION PANEL VRX6570Rz...
-
Page 4: Remote Control
Take note of the following points: • When replacing batteries, replace both batteries with new ones. • Do not short-circuit, disassemble or heat batteries. • Do not dispose of batteries into fire or flames. • Dispose of spent batteries properly. VRX6570Rz... -
Page 5: Functions Of Remote Control Unit Buttons
No function. No function. Switches the TV mode. Notes: • The remote control unit does not work when the panel is closed. • Some of the corresponding buttons on the main unit and remote control unit have different functions. VRX6570Rz... - Page 6 DCP/Operation Panel Attaching the DCP 1. Hold the DCP/Operation Panel with its rear side facing the main unit and, as shown in the figure below, put the lower edge of the panel onto the corresponding edge of the main unit. VRX6570Rz...
-
Page 7: Cautions On Handling
Do not use benzene, thinner, car cleaner, etc., as these substances may damage the cabinet or cause the paint to peel. Also, leaving rubber or plastic products in contact with the cabinet for long periods of time may cause stains. VRX6570Rz... -
Page 8: Adjusting The Volume
➜ MD changer mode ➜ TV mode ➜ switches to that function’s display, then returns back to the preferred display several seconds af- Radio mode... ter the adjustment. ∗ External equipment not connected with CeNET is not selected. VRX6570Rz... -
Page 9: Basic Operations
• Incapable of operation when connecting DSP CAUTION (DPH7500Z). Do not turn the display unless it is completely open. When adjusting the angle of the display be careful no to let your fingers get caught by the panel or instrument panel of the vehicle. VRX6570Rz... -
Page 10: Adjusting The Bass And Treble
±2. 4. When the adjustment is finished, operate the JOYSTICK § rightward or leftward to move the cursor to “MENU”. Then press the ENT at the center of the JOYSTICK § to return to the AUDIO-MODE display. VRX6570Rz... - Page 11 DISP button @ to switch to CT display. ∗ If CT is not being received, “CT--:--” appears in the display. Note: • CT data is not transmitted in some countries and by some broadcast stations. Also, in some areas, the CT may not be displayed accurately. VRX6570Rz...
-
Page 12: Radio Operations
Broadcast stations # for 2 seconds or longer to store the cur- with good reception condition are selected. rent station into preset memory. ∗ When local seeking starts, “LO SEEK” appears in the display. VRX6570Rz... -
Page 13: Auto Store
This function is useful when searching for desired station in memory. 1. Press the PS/AS button 5. 2. When the desired station is tuned in, press the PS/AS button 5 again to continue receiv- ing that station. VRX6570Rz... -
Page 14: Rds Operations
3. Each time you press the same PRESET but- ton #, the unit switches from a local station ∗ This function only operates when the DAH9500z DAB unit, sold separately, is connected. to the other on the same network. VRX6570Rz... -
Page 15: Selecting Pty
2. If you press the right side, the unit ∗ Even if you select FM1 or FM2, a TP station is seeks a PTY broadcast moving up the fre- stored into memory for FM3. quencies; if you press the left side, it seeks moving down the frequencies. VRX6570Rz... - Page 16 PHONE IN Phone in ● Cancelling an emergency broadcast TRAVEL Travel If you press the AF Button 7, emergency broad- cast reception is cancelled. HOBBIES Hobbies JAZZ Jazz COUNTRY Country NATIONAL National OLDIES Oldies FOLK M Folk music DOCUMENT Documentaries VRX6570Rz...
- Page 17 VOLUME button 2 upward or downward to set the volume to the desired level (00 to 33). ∗ When the TA, ALARM or PTY interrupt ends, the volume returns to the level it had before the inter- rupt. VRX6570Rz...
-
Page 18: Cd Changer Operations
● Scrolling a CD-text title When a CD-text title is longer than 16 charac- ters (8 characters when the panel is closed), you can scroll the display as follows. VRX6570Rz... -
Page 19: Repeat Play
Normal disc play continues on the 2. To cancel disc random play, press the RDM current track. button 8 again. “D-RDM” goes off from the display and the unit returns to normal play from the track being played. VRX6570Rz... -
Page 20: Md Changer Operations
1. Press the TITLE button ¢ for 1 second or longer to scroll through the disc title. 2. To scroll the track title, press for 1 second or longer the TITLE button ¢ within 30 seconds after scrolling the disc title. VRX6570Rz... - Page 21 “D-RPT” lights in the display. 2. To cancel disc repeat play, press the RPT button 7 again. “D-RPT” goes off from the display and the unit returns to normal play from the track being played. VRX6570Rz...
-
Page 22: Watching A Video
Watching TV the left side to automatically tune down. Notes: • For your safety, the VRX6570Rz has a safety func- Manual tuning tion which turns off the picture when the car is There are 2 ways available: Quick tuning and step moving, so only the audio can be heard. -
Page 23: Manual Memory
“VTR N/P”. 3. Operate the JOYSTICK § rightward or left- ward to move the cursor to select “NTSC” or “PAL”. 4. Press the ENT at the center of the JOYSTICK § to set the selected VTR mode. VRX6570Rz... - Page 24 In deference to the intention of producer, an origi- the center of the JOYSTICK § to return to nal image can be viewed in a normal mode. the adjustment selection display. • During superimposed display, it becomes a full- wide mode. VRX6570Rz...
-
Page 25: Manual Tuning
2. Press and hold right or left for 1 second or longer using the SEARCH button 2. rent station into preset memory. ∗ The unit stops the seek tuning when it cannot find a DAB station. The display returns to the previous mode. VRX6570Rz... - Page 26 Traffic programme (TP) automatic tuning is also possible. ∗ RDS interrupt does not function during AM radio reception or in TV mode. VRX6570Rz...
- Page 27 1. When you press the PTY button 8, the unit goes into PTY select mode. 2. Press any one of the PRESET buttons # to select the desired PTY. Alternatively, when the panel is closed, operate the SEARCH button 2 upward or downward to select a desired PTY. VRX6570Rz...
- Page 28 ∗ When the TA, ALARM, information or PTY inter- rupt ends, the volume returns to the level it had Operate the JOYSTICK § rightward or left- before the interrupt. ward to select “PTY ITEM” or “PRESET” (by moving the cursor). VRX6570Rz...
-
Page 29: Dynamic Label Function
DLS character string is displayed (manual call- ing). With the DLS memory being called, move the cursor to “UPDATE” and press the ENT at the center of the JOYSTICK § . The display is changed into the DLS display being received. VRX6570Rz... - Page 30 NVG/AV button ! . ward to select “INPUT”. A menu bar is shown to the right to select the following items: ● “NAVI”: Setting when Clarion NAVI is con- nected; ● “CCD”: Setting when Clarion CCD cam- era is connected to this unit;...
- Page 31 Be sure to perform this setting after connecting to the right to select the following items: the CCD. ● “NAVI”: Setting when Clarion NAVI is con- 1. When the panel is open, press the ADJ but- nected; ton £ to show the adjustment selection dis- ●...
-
Page 32: Other Functions
7 to 12. 3. If you press and hold the TITLE button ¢ for 3. Press the TITLE button ¢ again to return to 1 second or longer, the display switches to the STANDARD display. the title input mode display. VRX6570Rz... - Page 33 “TEL SP”. “LEFT” and “RIGHT” are displayed in the menu bar. ● LEFT: Telephone calls can be heard on the left speaker connected to this unit. ● RIGHT: Telephone calls can be heard on the right speaker connected to this unit. VRX6570Rz...
-
Page 34: Dsp Operations
● Test Tone Output Select Test Tone Output Operate the JOYSTICK § upward or down- ward to select a desired item, and then press the ENT at the center of the JOYSTICK § to produce a test tone. VRX6570Rz... - Page 35 § to return to the AUDIO-MODE display. 6. Operate the JOYSTICK § rightward or left- ward to move the cursor to “MENU”, and press the ENT at the center of the JOYSTICK § to return to the AUDIO-MODE display. VRX6570Rz...
- Page 36 “EDIT”, and press the ENT at the cen- Title Input display. ter of the JOYSTICK § to show G.EQ adjust- ∗For title inputting method, refer to the section ing display, in which the properties of currently “Entering titles”. selected pattern can be adjusted. VRX6570Rz...
- Page 37 JOYSTICK § to show DSP seconds or longer in the DSP adjusting display, the adjusting display, in which the properties of cur- DSP pattern can be stored in the USER memory. rently selected pattern can be adjusted. VRX6570Rz...
- Page 38 BASIC/USER pattern selection/memory JOYSTICK § rightward or leftward to select display to select USER memory P1 to P6 to be P1 to P6, and press the ENT at the center of stored, and press the ENT at the center of the VRX6570Rz...
- Page 39 USER pattern selection/memory display. center of the JOYSTICK § for 2 seconds or 4. In the pattern selecting display, operate the longer to store the adjusted P .EQ pattern to JOYSTICK § rightward or leftward to select the USER memory. VRX6570Rz...
- Page 40 ∗For title inputting method, refer to the section “Entering titles”. 8. Operate the JOYSTICK § rightward or left- ward to select “MENU” and press the ENT at the center of the JOYSTICK § to change into the AUDIO-MODE display. VRX6570Rz...
-
Page 41: In Case Of Difficulty
The color of the The color is not adjusted display is light or adequately. a shade of color is not good. Set the NTSC/PAL properly according to the VTR. When the VTR is Improper NTSC/PAL setting connected, the image is disturbed. VRX6570Rz... - Page 42 (The LCD panel is produced points in the according to technology with very high precision. display. Note that, though there are effective pixels of 99.99% or more, pixel missing or normally lit pixels account for 0.01%). VRX6570Rz...
-
Page 43: Error Displays
Load a pre-recorded MD in the MD loaded in the MD changer. changer. If an error display other than the ones described above appears, press the RESET button. If the problem persists, turn off the power and consult your store of purchase. VRX6570Rz... -
Page 44: Specifications
Display method: Transmission type TN liquid Notes: crystal display • Specifications comply with EIAJ Standards. Drive method: TFT (thin-film transistor) active • Specifications and design are subject to change matrix driving without notice for further immprovement. Pixels: 280,800 (1200 × 234) VRX6570Rz... -
Page 45: Table Of Contents
VRX6570Rz Installation and Wire connection manual ■ Contents BEFORE STARTING..........53 PACKAGE CONTENTS..........53 GENERAL CAUTIONS..........54 CAUTIONS ON INSTALLATION.........54 INSTALLING THE MAIN UNIT........55 REMOVING THE MAIN UNIT.........57 CAUTIONS ON WIRING..........58 WIRE CONNECTION..........59 SAMPLE SYSTEMS...........61 BEFORE STARTING 1. This set is exclusively for use in cars with a negative ground 12 V power supply. -
Page 46: General Cautions
For tough dirt, apply a little cold or dealer or an authorized CLARION service warm water to a soft cloth and wipe off the centre. -
Page 47: Installing The Main Unit
3. Insert the main unit into the universal mount- 1) Some car models require special mounting kits ing bracket until it locks. for proper installation. Consult your Clarion dealer for details. 4. Mount the outer escutcheon so that all the 2) Fasten the front stopper securely to prevent hooks are locked. - Page 48 Note 1: In some cases, the centre panel may re- Note 2: If a hook on the installation bracket inter- quire some modification (trimming, filling, feres with the unit, bend and flatten it with etc.). a nipper or a similar tool. VRX6570Rz...
-
Page 49: Removing The Main Unit
(Figure 9) 2. Remove the outer escutcheon. 3. Insert the hook plate between the spring and Note: Keep the hook plate. You cannot remove the the universal mounting bracket, fit tab main unit without disengaging the hook plate. VRX6570Rz... -
Page 50: Cautions On Wiring
If it is, replace the fuse with a new one with the same amperage rating as the original. 4. When any fuse is to be replaced, pull out the fuse (15A) at the rear of the main unit and put in a new one (Fig.10). Figure 10 VRX6570Rz... -
Page 51: Wire Connection
The lead included with the unit must be connected to the specified position of the vehicle’s ISO connector in order to use the “triggered audio mute for cellular telephones” function. ∗4:Use the attached extension lead when necessary. Note : Before making any installation, disconnect the car battery - (negative) cable. VRX6570Rz... - Page 52 NAVI) and the RGB terminal of the main unit. For detailed information, refer to the operating in- structions provided with car navigation equipment. When the NAVI is connected, the CCD camera cannot be connected. When the Clarion NAVI is to be connected, set the INPUT to the NAVI posi- tion.
-
Page 53: Sample Systems
∗ To enable the correct input, it is necessary to con- figure the VRX6570Rz as described on page 39. ∗ When the navigation is connected, the CCD can- not be connected. When the navigation is not con- nected, the CCD is connected to the VRX6570Rz. - Page 54 ∗ When a video composite source is used, connect it to the 8-pin Mini-DIN video jack. When a RGB source is used, connect it to the 8-pin DIN RGB jack. In case a CLARION navigation system is used, connect it to both in- put.
- Page 55 ∗ The VTR cannot be connected to the VRX6570Rz. The VTR is connected to the TTX7502z. ∗ When DSP is connected, external amplifier is re- quired. On the other hand, when external ampli- fier is connected, the DSP is required.
- Page 56 Memo VRX6570Rz...
