Instructions
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
Frame, Roller
- For application of architectural paints and coatings -
Model 244278, Series A
•
9 inch (23 cm) length
•
7/8 inch inlet with 1/2 inch (13 mm) nap roller cover
3000 psi (24.8 MPa, 248 bar) Maximum Working Pressure*
*The best operating pressure is the lowest pressure that pro-
vides an even paint supply to the roller and typically does not
exceed 300 psi (2.1 MPa, 21 bar).
311141A
ti6623ab
Advertisement
Table of Contents
Related Manuals for ASM 244278
Summary of Contents for ASM 244278
- Page 1 Read all warnings and instructions in this manual. Save these instructions. Frame, Roller - For application of architectural paints and coatings - Model 244278, Series A • 9 inch (23 cm) length • 7/8 inch inlet with 1/2 inch (13 mm) nap roller cover 3000 psi (24.8 MPa, 248 bar) Maximum Working Pressure*...
- Page 2 Warnings The following warnings are for the safe setup, use, grounding, maintenance and repair of this equipment. The excla- mation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. Refer back to these Warnings. Additional, product-specific warnings may be found throughout the body of this manual where applicable.
- Page 3 Pressure Relief Procedure Follow this Pressure Relief Procedure when you stop spraying and before cleaning, checking, servicing, or transporting equipment. 1. Turn power switch OFF and unplug sprayer power cord. 2. Turn spray/prime valve to PRIME to relieve pressure. 3. Hold metal part of gun firmly to side of a grounded metal pail.
- Page 4 Cleaning This is the procedure for flushing/cleaning the pressure roller. The sprayer and gun you are using may have ad- ditional flushing/cleaning instructions; such as cleaning filters and screens. See sprayer and gun operation man- uals. • Leave pressure roller attached to gun for this procedure.
- Page 5 Parts Ref. Part No. Description 15B052 FRAME, roller 245999 CAP, end (includes seal and retainer) 246277 CAP, end (includes seal, retainer, and o-ring) 197106 CLIP, roller 197118 FITTING, swivel 197117 NUT, retaining 7722 ROLLER, cover, 9-inch, 1/2 inch (13mm) nap 115524 GASKET 15B065 DIFFUSER ▲...
- Page 6 ASM Standard Warranty Standard Warranty ASM warrants all equipment referenced in this document which is manufactured by ASM and bearing its name to be free from defects in material and workmanship on the date of sale by an authorized ASM distributor to the original purchaser for use. With the exception of any special, extended, or limited warranty published by ASM, ASM will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by ASM to be defective.
