Crystal Mountain GLACIER User Manual

Bottled water dispenser
Hide thumbs Also See for GLACIER:

Advertisement

Table of Contents

GLACIER
Bottled Water Dispenser User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GLACIER and is the answer not in the manual?

Questions and answers

Related Manuals for Crystal Mountain GLACIER

Summary of Contents for Crystal Mountain GLACIER

  • Page 1 GLACIER Bottled Water Dispenser User Manual...
  • Page 2 1、Hot Water Faucet (with Child Safety Feature) 2、Cold Water Faucet 3、Cook Water Faucet (Room Temperature Water) 4、Drip Tray Parts may not appear exactly as shown...
  • Page 3 THANK YOU FOR BUYING A CRYSTAL MOUNTAIN WATER COOLER! RECEIVING Inspect the cooler box immediately and carefully for any evidence of shipping or handing damage before signing to receive goods. In case of shipping damage, claims should be filed immediately with the carrier. Please note that the carrier will not accept claims for any damage discovered after the signing for UNINSPECTED GOODS.
  • Page 4 5. Ensure the following when cooler is to be serviced: 5.1 Turn off Hot Tank Switch (Hot & Cold models only) and disconnect power supply cord. (Figure 7 and Figure 8) 5.2 Remove bottle from reservoir. (Figure 9) Figure 7 Figure 8 Figure 9 5.3 Use a bucket to drain water from the cold water reservoir through faucets.
  • Page 5 3. Remove the locking pin from the Crystal Guard (Figure 18), which may be stiff, requiring a tool. Use the fingertips of both hands to press on the Crystal Guard and turn counter clockwise till it is free from the cooler opening (Figure 19 and Figure 20). Note: If the cooler is equipped with a DryGuard , see the DryGuard removal section of the instructions.
  • Page 6 R, P, & G Series On Cook & Cold and Hot & Cold models the reservoir can be removed easily by following the steps given below. 1. Unplug (Figure 28) and approach the cooler from the front. 2. Remove the water bottle (Figure 29) and drain water from the reservoir and hot tank, remembering to cool and drain hot tank.
  • Page 7 DryGuard Installation (See Figure 49) 1. Place the Inner DryGuard Cone assembly onto the center of the cold water reservoir; make sure the words "LIFT THIS SIDE TO REMOVE" is aligned with the sides of the cooler and that the filter cap is positioned towards the rear of the cooler (Figure 39).
  • Page 8 Outer DryGuard Cover Removal and Installation Cover Figure 49 Note: The product you have purchased may look different than the model shown in (Figure 50). Figure 50...
  • Page 9 Standup Series Bracket Installation Instructions INSTALLATION 1. Remove the two mounting screws that secure the Bottom Plate to the outer enclosure. 2. While holding the "S" shaped bracket against the cooler (refer to diagram) reinstall and tighten the bottom plate/outer enclosure screws securely. 3.
  • Page 10 WARNING: The warranty and Underwriters’ Laboratory and CE listings for the coolers are invalidated if any alteration, modification, or use or misuse in combination with any other machine or devices is deemed to be the source of any claim. The manufacturer accepts no liability (including for bodily injury) resulting from any alteration, misuse, neglect, accidents, improper installations or repairs.
