  • Page 1 VideoBridge ™ 6000 Series Hardware Guide VideoBridge 6000 (1-port version) VideoBridge 6000 (4-port version) VideoBridge 6000 (1-port rack-mounted)
  • Page 2: Table Of Contents

    The document is intended for anyone involved in using and configuring the products. It provides introductory information as well as instructions on how to connect the VideoBridge 6000 Series to your network. Any changes or alterations to this document will be posted on the IndigoVision web site at www.indigovision.com.
  • Page 3: Product Overview

    VideoBridge Software Development Kit (version 2.6 or higher), or applications supplied or developed by IndigoVision. Model Naming Conventions This guide describes the VideoBridge 6000 Series models. For the purposes of this document, the models are described as follows: Model Document Naming Convention...
  • Page 4: Initial Ip Settings

    BNC, 75ž terminated Video Input/Output Before connecting any VideoBridge 6000 series devices to your network, you may need to alter the Table 2: Video I/O IP address of the unit to avoid possible conflicts. It is highly recommended that the initial setting of the network properties of the device is carried out via the serial port.
  • Page 5: Videobridge 6000-4 & 6000-4Rm - Connector Specification (Rear)

    Serial 2 on the VideoBridge 6000 device is a standard RS 232 serial connection with pin outs as shown in Table 8. Figure 4: VideoBridge 6000-4 Rear Panel Network Port CAUTION! Off the shelf serial and null-modem cables may not be compatible with the VideoBridge 6000 series devices. Name Type Description NETWORK RJ-45...
  • Page 6 VideoBridge 6000 Series VideoBridge 6000 Series PLEASE NOTE The +5V DC connection on the connector block is directly connected to the DC PLEASE NOTE The value of R should be rounded down to the nearest available value to ensure input socket on the device. DC power can be supplied to the device via this that the recommended current of 10mA is available.
  • Page 7: Videobridge 6000-1

    VideoBridge 6000 Series VideoBridge 6000 Series VideoBridge 6000-1 Connector Specification (Front) The ‘FD’ (Factory Default) switch on the front panel of the VideoBridge 6000 device resets the factory default IP, Subnet and Gateway settings of the device. The default position for this switch is ‘In’.
  • Page 8 Serial Port 2 on the VideoBridge 6000 device is a standard RS232 serial connection with pin outs as shown in Table 17. CAUTION! Off the shelf serial and null-modem cables may not be compatible with the VideoBridge 6000 series devices. PLEASE NOTE Compatible null modem cable available from: Company...
  • Page 9 VideoBridge 6000 Series VideoBridge 6000 Series Input Power Connector The Binary inputs on the VideoBridge 6000 device allow the user to connect external trigger sources Name Type Description to the unit. A typical example application is shown in Figure 9.
  • Page 10: Hardware Specifications

    • “4:2:0” YUV color space • “4:2:0” YUV color space • 24-bit color depth Power • 24-bit color depth 6000 Series Rack Mount Metrics • Choice of resolutions • Operating voltage: 5V DC @ 1.2A • Choice of resolutions CIF: 352 x 288 pixels Dimensions •...
  • Page 11 Ikegami Electronics (USA) Inc. •[ www.ikegami.com ] 37 Brook Avenue, Maywood, NJ 07607 USA•Tel: 1-201-368-9171•Fax: 1-201-569-1626•...
