- Page 1 1080P ® Wireless for HDMI In-Room Solution GTV-WHD-1080P-SR User Manual gefentv.com...
- Page 3 Chatsworth, CA 91311 www.gefentv.com support@gefentv.com Notice Gefen LLC reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. Wireless for HDMI In-Room Solution is a trademark of Gefen LLC © 2014 Gefen, LLC. All rights reserved.
-
Page 4: Table Of Contents
CONTENTS Introduction FCC Statement Operation Notes Features Panel Layout Sender Unit Receiver Unit Panel Descriptions Sender Unit Receiver Unit IR Remote Control Unit Layout and Descriptions 10 Connecting the Wireless for HDMI Wiring Diagram 11 Operating the Wireless for HDMI The Linking Process Using Multiple Sender Units Adding a New Video Source... -
Page 5: Introduction
We invite you to explore our distinct product line. Please visit http://www.gefen.com for the latest offerings in High-Definition signal solutions or call us between the hours of 8:00 am and 5:00 pm Monday-Friday, Pacific Standard Time for assistance with your A/V needs. -
Page 6: Fcc Statement
FCC STATEMENT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation INSTRUCTION TO THE USER This equipment has been tested and found to comply with the limits for a class... -
Page 7: Operation Notes
• DVI-D Support • Gefen recommends placing both units into the provided stands, with the Gefen logo pointing down, to help maintain the strongest possible transmission signal. • Interference caused by other RF products may reduce performance and reception distance. - Page 8 » IR devices may be compatible with the IR Back Channel of the Wireless for HDMI. The following brands have been tested by Gefen: Panasonic, Sony, and Samsung. • Operational Limitations: Regarding US and EU models, note that all RF devices are designed »...
-
Page 9: Features
FEATURES HDMI Features Supported • Resolutions up to 1080p Full HD • 12-bit Deep Color • Linear PCM digital audio up to 7.1 channels • Dolby® TrueHD, Dolby® Digital Plus, and DTS-HD Master Audio™ up to 5.1 channels • 3DTV pass-through •... -
Page 10: Panel Layout
PANEL LAYOUT Sender unit... -
Page 11: Receiver Unit
PANEL LAYOUT Receiver unit... -
Page 12: Panel Descriptions
PANEL DESCRIPTIONS Sender Unit Video This LED indicator will glow bright blue once a video link is established between the Sender unit and the Receiver unit. Pairing button Press and hold this button for 3 seconds to pair the Sender unit with the Receiver unit. -
Page 13: Ir Remote Control Unit
IR REMOTE CONTROL UNIT Layout and Descriptions Menu Press this button to display the Setup menu. Cursor buttons Used to control Left, Up, Right, and Down cursor motion within a menu system. Press this button to accept the current operation or menu selection. Delete When using multiple Sender units, press this button to delete a Sender unit from the wireless network. -
Page 14: Connecting The Wireless For Hdmi
Sender and Receiver unit. Ordinarily, no pairing is required out of the box. However, the Sender and Receiver can also be paired manually if needed. Wiring Diagram for the Wireless for HDMI In-Room Solution HDMI CABLE ® USB POWER GTV-WHD-1080P-SR... -
Page 15: Operating The Wireless For Hdmi
OPERATING THE WIRELESS FOR HDMI The Linking Process After all the connections have made (see page 10) to the Wireless for HDMI, the Receiver unit will attempt to negotiate with the Sender unit. Status Message Provides information on the current status of the Wireless for HDMI Connecting to Sender... -
Page 16: Using Multiple Sender Units
OPERATING THE WIRELESS FOR HDMI Using Multiple Sender Units The Wireless for HDMI can be used with multiple Sender units to provide switching capability between up to eight Sender units. Figure 1: Receiver unit shown with multiple Sender units To source To source Adding a new Video Source Before adding a secondary Sender unit to the Wireless for HDMI network, make... - Page 17 OPERATING THE WIRELESS FOR HDMI Use the cursor buttons on the IR Remote Control to select Add new Video Source from the Setup menu. Press the OK button. The following message will be displayed: Press and hold the Link button on Sender until Link LED stops blinking Press and hold down the Pairing button (see pages 6 - 8) on the Sender unit for about 5 seconds.
- Page 18 OPERATING THE WIRELESS FOR HDMI As the Sender unit is added to the Wireless for HDMI network, a progress bar will be displayed: Adding Sender After a few moments the source signal connected to the additional Sender unit will be displayed: Connected to Sender If desired, repeat steps 1 - 7 to add another Sender unit to the Wireless for HDMI network.
-
Page 19: Renaming Sources
OPERATING THE WIRELESS FOR HDMI Renaming Sources By default, each Sender unit is assigned the name “Sender”. This can be confusing when multiple Sender unit are used. However, this identifier can be changed to reflect, for example, the source to which each Sender unit is connected. - Page 20 OPERATING THE WIRELESS FOR HDMI The Rename Video Source Name menu will be displayed, along with the selected Source. Use the ▲ and ▼ cursor keys to change the highlighted character. The ▲ key moves forward within the list of available characters and the ▼...
- Page 21 OPERATING THE WIRELESS FOR HDMI After the video source has been renamed, press the OK button to save the changes. Select Video Source Sender BluRay Setup...
-
Page 22: Switching Between Sources
OPERATING THE WIRELESS FOR HDMI Switching between Sources Once two or more Sender units have been connected to a Receiver unit, use the IR Remote Control unit to switch between each source. Point the IR Remote Control at the Receiver unit and press the Source button. - Page 23 OPERATING THE WIRELESS FOR HDMI Once the desired source has been selected, press the OK button. Select Video Source BluRay Setup The screen will go blank momentarily and the “Connecting to..” status message will be displayed, indicating that the Receiver unit is switching to the selected Sender unit (source).
-
Page 24: Deleting Sources
OPERATING THE WIRELESS FOR HDMI Deleting Sources If a Sender unit (source) will no longer be necessary, it can be removed from the Wireless for HDMI network. Point the IR Remote Control at the Receiver unit and press the MENU button. - Page 25 OPERATING THE WIRELESS FOR HDMI Click the OK button to confirm the selection. The Chose Source to Remote menu will be displayed. Select the source to be removed and press the OK button. Choose Source to Remove BluRay Press the OK button to confirm the removal of the selected device. Removing BluRay Press OK to continue or Exit to cancel After a few seconds, the screen will go blank.
- Page 26 OPERATING THE WIRELESS FOR HDMI Press the SOURCE button to display the Select Video Source menu. Select Video Source Setup Select the desired source using the cursor buttons. Then, press the OK button to confirm the selection. Select Video Source Setup TIP: Use the DELETE button on the IR Remote Control to jump directly to the Select Video Source menu, when deleting sources.
- Page 27 OPERATING THE WIRELESS FOR HDMI 10. The “Connecting to...” status message will be displayed: Connecting to DVR... 11. After a few moments, the selected source signal will be displayed. Connected to DVR NOTE: The video source will always need to be selected, even if the source currently being viewed is not deleted.
-
Page 28: Disconnecting The Wireless Link
OPERATING THE WIRELESS FOR HDMI Disconnecting the Wireless Link The Wireless for HDMI network can be completely disconnected, if necessary. This can be used in order to restrict the source from being viewed. Point the IR Remote Control at the Receiver unit and press the MENU button. -
Page 29: Reconnecting The Wireless Link
OPERATING THE WIRELESS FOR HDMI Reconnecting the Wireless Link Press the Source button on the IR Remote Control. The “Connecting to...” message will be displayed: Connecting to DVR... After a few seconds, the wireless link will be restored and the source signal will be displayed. -
Page 30: Power-Down Mode
OPERATING THE WIRELESS FOR HDMI Power-Down Mode The Wireless for HDMI can be powered-down when not in use. Point the IR Remote Control at the Receiver unit and press the GUEST button. After a few seconds, the screen Receiver and Sender unit(s) will power- down. -
Page 31: Powering-Up After A Power-Down
OPERATING THE WIRELESS FOR HDMI After the Wireless for HDMI has been successfully powered-down, the “Wireless Off” message will be displayed on the screen. Wireless Off Powering-Up after a Power-Down Point the IR Remote Control at the Receiver unit and press the GUEST button. -
Page 32: Specifications
SPECIFICATIONS Operating Frequency..................5 GHz Supported resolutions..............480p to 1080p Video Input Connector (Sender)......(1) HDMI Type A, 19-pin, male Video Output Connector (Receiver)..... (1) HDMI Type A, 19-pin, female USB Connector (Sender / Receiver)..(1) Mini-B (Receiver - factory use only) Power Supply (Sender)..........(1) 5V / 1A DC with USB jack (can also use powered USB port) Power Supply (Receiver).............. -
Page 33: Warranty
If equipment fails because of such defects and Gefen is notified within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifications. - Page 36 Rev A5 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefentv.com support@gefentv.com This product uses UL or CE listed power supplies.
